oticon Ino Manuale utente
INSTRUCTIONS FOR USE BTE
Thank you
Thank you for choosing our product as your means to better hearing.
To support your efforts, we have put great care and attention into making sure that
your new hearing instruments are of the highest quality and that they are easy to
use and maintain.
We recommend that you read this manual carefully to achieve the maximum benefit
of your new hearing instruments.
Congratulations on your decision to actively improve your hearing with today’s most
advanced hearing technology in the market.
Contents
Instrument View BTE 13 and BTE Power 5a
Instrument View BTE 13 with Corda
2 5b
Changing batteries 7
Turning your instrument ON and OFF 9
Left/Right ear marking 10
Putting on your instrument with earmould 11
Putting on your hearing instruments with a Corda
2 (thin tube) 12
Push-button 13
Programs (Optional) 15
Volume Control (Optional) 17
Stand-by (Optional) 18
Tamper-resistant battery door (Optional) 20
Telecoil (Optional) 21
Auto Phone (Optional) 22
DAI (Direct Audio Input) 24
FM 26
5a
IMPORTANT NOTICE
Please familiarise yourself with the entire contents of this booklet before using your
hearing instru ments. It contains instructions and important informa tion about the use
and handling of your hearing instru ments and batteries.
CAUTION
The BTE Power is a powerful hearing instrument. In case you are fitted with BTE Power,
never allow others to wear your hearing instruments as incorrect or wrongful usage
could cause permanent damage to their hearing.
Caring for your hearing instrument 28
How to change Corda
2 (thin tube) 33
Cleaning your hearing instrument with Corda2 (thin tube) 34
Daily maintenance with Corda
2 (thin tube) Domes 35
Changing the Corda2 Dome 36
Using your hearing instrument 39
Common problems and their solutions 44
Warnings Yellow Pages
Instrument View BTE 13 and BTE Power
Battery size: 13
Microphone
openings
Push-button/
Volume Control
(Optional) Earmould
Battery door
Sound hook Plastic tube
Sound outlet
Ventilation
opening
Your ear piece:
Custom Mould
Plus dome
Open dome:
Small
Medium
Large
Battery size 13
5b
Instrument View BTE 13 with Corda
2
Not available for BTE Power
Thin tube
Dome
Ear grip
Microphone
openings
Battery door
Push-button/
Volume Control
(Optional)
7
Changing batteries
Your hearing instrument battery size is 13. Batteries per form
differently. Ask your hearing care professionalfor help
choosing a high quality battery for your hearing instrument.
A worn out battery should be removed immediately
and disposed of according to local regulations.
When the battery power is low, you will hear 2 beeps.
This pre-warning starts when the battery has only a few
hours of operation left. The pre-warning will be repeated
in moderate intervals to indicate it is time to change the
battery.
If the battery runs out the instrument turns off. When
that happens, 4 beeps are played to indicate that the
instrument is no longer operating.
This is not an indication of a malfunction.
98
To replace the battery, follow these instructions:
• Open the battery door completely by pushing the raised edge in the bottom of
the instrument. Remove the old battery.
• Remove the sticky label from the + side of the new battery.
• Insert the new battery so that its + marking faces the + sign printed on the
battery door. Close the battery door.
Any moisture on the battery surface should be wiped
off before use.
When you change battery, it will take a few seconds
before the battery works to full capacity.
To assist the handling of the batteries, the magnet
placed at the end of the tool can be used.
MultiTool
Turning your instrument ON and OFF
Turn ON your hearing instrument by closing the battery door completely with the battery
in place. When the battery door is closed the instrument will start up by playing a jingle.
This indicates that the battery is working and the instrument is operating.
Turn OFF your hearing instrument by opening the battery door slightly until a “click” is felt.
To preserve the battery, make sure your hearing instrument is switched off when
you are not wearing it.
IMPORTANT NOTICE
Open the battery compartment
fully to allow air to circu late
whenever you are not using
your hearing instrument,
especially at night!
Click
ON OFF
Click
1110
Left/Right ear marking
Hearing instruments are fitted to the uniqueness of each ear, which means if you have
two instruments then your left hearing instrument is programmed differently from your
right. That is why it is important to distinguish between the left hearing instrument and
the right.
In order to easily identify whether it is the left ear or right ear instrument, colour markings
may be applied inside the battery door.
Blue marks the LEFT instrument.
Red marks the RIGHT instrument.
Putting on your instrument
with earmould
Place the tip of the earmould in your ear canal,
twisting slightly, making sure that the top part of the
earmould (A) is pushed behind and under the fold (B)
of your ear.
Gently pull up your ear and press the earmould in the
direction of the ear canal.
With the earmould positioned correctly in your ear,
place the hearing instrument behind your ear by lifting
its lower part and sliding it over the top of your ear.
A
B
1312
Push-button
Your hearing instrument has an ergonomic designed push-button for volume adjustment
and switching between different programs.
The push-button can be activated by pressing either the upper part (UP) or the lower
part (DOWN).
UP
DOWN
Putting on your hearing instruments
with a Corda
2 (thin tube)
Not available for BTE Power
Putting on your hearing instrument with a thin tube correctly
every time, takes practice:
1. Place the hearing instrument behind your ear.
2. Hold the bend of the tube between your thumb and index finger.
The dome should point towards the ear canal opening.
Gently push the dome into your earcanal until the sound tube
sits close against the side of your head.
3. Position the ear grip in concha using your index finger. Look in
a mirror. If the sound tube is sticking out from your ear, the dome
has not been placed correctly in the ear canal. If the ear grip is
visibly sticking out from your ear it has not been positioned
correctly. To remove the instrument pull the bend of the tube.
Dome
Concha
1
2
3
1514
The push-button on your hearing instrument can be programmed to one of 3 functionalities.
Left Right
Program shift:
Press shortly to change program.
Volume control:
Press shortly to adjust the volume.
Both volume control and program shift:
Press shortly to adjust the volume and press long (about 2 seconds)
to shift program.
Binaural Coordination enabled (see “Using 2 instruments”).
To be filled out by your Hearing Care Professional!
Programs (Optional)
Your hearing instrument can have up to 4 different programs.
When switching between the different programs, your hearing instrument will beep.
The number of beeps will indicate which program you are using.
One beep, when you switch to program 1
Two beeps, when you switch to program 2
Three beeps, when you switch to program 3
Four beeps, when you switch to program 4
Press the upper part to go forwards in the program cycle e.g from P1-P2.
Press the lower part to go backwards in the program cycle e.g from P3-P2.
1716
Below you can see a description of the programs available in your hearing instrument.
Prg. 1:
Prg. 2:
Prg. 3:
Prg. 4:
Using 2 instruments
If you have two Ino Pro instruments the push-button on one instrument can be pro-
grammed to change the program on both hearing instruments (Binaural Coordination).
This means, when you adjust the program for one instrument, it automatically adjusts
the other.
Volume Control (Optional)
A volume control may be activated. The volume control allows you to adjust the volume in
specific listening situations to the level you feel comfortable with.
To increase volume, shortly press the upper part of the push-button.
To decrease volume, shortly press the lower part of the push-button.
You hear a beep when you increase or decrease the volume.
When the hearing instrument is turned on, it starts up at a preferred volume level.
When adjusting the volume control to the preferred level, this is indicated by a beep.
Using 2 Instruments
If you have two Ino Pro instruments the push-button on one instrument can be pro-
grammed to adjust the volume on both hearing instruments (Binaural Coordination).
This means, when you adjust the volume for one instrument, it automatically adjusts
the other.
