Overland Storage NEO S-Series Manuale utente

Overland

Storage

NEO®S-Series Tape Library

Service Manual

January 2015

10400666-001

NEO S-Series User Guide

Overland®, Overland Storage®, ARCvault®, DynamicRAID®, GuardianOS®, NEO®, NEO Series®, PowerLoader®, Protection OS®, RAINcloud®, REO®, REO 4000®, REO

Series®, Snap Appliance®, Snap Care® (EU only), SnapSAN®, SnapScale®, SnapScale X2®, SnapServer®, StorAssure®, Ultamus®, VR2®, and XchangeNOW®are registered

trademarks of Overland Storage, Inc.

Tandberg Data®, AccuGuard®, AccuVault®, DPS1000 Series®, DPS1100®, DPS1200®, DPS2000®, Magnum®, QuikStation®, QuikStor®, RDX®, RDXPRO®, StorageLibrary®,

StorageLoader®, Tandberg SecureService®, Tandberg StorageLibrary®, and VXA®are registered trademarks of Tandberg Data, Inc.

RapidRebuild™, SnapExpansion XSR™, SnapScale X4™, SnapServer DX Series™, SnapServer XSD Series™, SnapServer XSD 40™, SnapServer XSR Series™,

SnapServer XSR 40™, SnapServer XSR 120™, and SnapServer Manager™ are trademarks of Overland Storage, Inc.

BizNAS™ and QuadPak™ are trademarks of Tandberg Data, Inc.

All other brand names or trademarks are the property of their respective owners.

The names of companies and individuals used in examples are fictitious and intended to illustrate the use of the software. Any resemblance to actual companies or

individuals, whether past or present, is coincidental.

PROPRIETARY NOTICE

All information contained in or disclosed by this document is considered proprietary by Overland Storage. By accepting this material the recipient agrees that this

material and the information contained therein are held in confidence and in trust and will not be used, reproduced in whole or in part, nor its contents revealed to

others, except to meet the purpose for which it was delivered. It is understood that no right is conveyed to reproduce or have reproduced any item herein disclosed

without express permission from Overland Storage.

Overland Storage provides this manual as is, without warranty of any kind, either expressed or implied, including, but not limited to, the implied warranties of

merchantability and fitness for a particular purpose. Overland Storage may make improvements or changes in the product(s) or programs described in this manual at

any time. These changes will be incorporated in new editions of this publication.

Overland Storage assumes no responsibility for the accuracy, completeness, sufficiency, or usefulness of this manual, nor for any problem that might arise from the use

of the information in this manual.

NEO S-Series User Guide

Contents

1Introduction ................................................................................................................................... 5

Document Purpose.....................................................................................................................................51.1

Product Warranty Caution ..........................................................................................................................51.2

2General Warnings.......................................................................................................................... 6

Document Conventions: .............................................................................................................................62.1

General Product Warnings .........................................................................................................................62.2

3Troubleshooting............................................................................................................................ 8

Installation problems...................................................................................................................................83.1

SCSI ID ..........................................................................................................................................83.1.1

SCSI host adapter installation ...........................................................................................................83.1.2

LUN scanning .................................................................................................................................83.1.3

SCSI cabling ...................................................................................................................................83.1.4

Termination.....................................................................................................................................83.1.5

Compatibility ..................................................................................................................................93.1.6

Backup application installation..........................................................................................................93.1.7

Device driver installation..................................................................................................................93.1.8

Troubleshooting table...............................................................................................................................103.2

Removing stuck tape cartridges from the library......................................................................................143.3

Emergency release...................................................................................................................................153.4

Upgrade the library firmware ....................................................................................................................153.5

General diagnostic....................................................................................................................................163.6

1.6.1 System test..................................................................................................................................16

Slot-to-Slot test............................................................................................................................163.6.1

Library verify test.........................................................................................................................163.6.2

Error codes ...............................................................................................................................................173.7

1.7.4 Error messaging..........................................................................................................................17

Error structure .............................................................................................................................173.7.1

OCP error reporting.....................................................................................................................173.7.2

RMU error reporting ....................................................................................................................183.7.3

Main error codes .........................................................................................................................193.7.4

Sub error codes related to the robotic.........................................................................................273.7.5

Sub error codes related to the library..........................................................................................293.7.6

4Servicing...................................................................................................................................... 30

Possible tools needed...............................................................................................................................304.1

Electrostatic discharge..............................................................................................................................304.2

Removing a tape drive..............................................................................................................................314.3

NEO S-Series User Guide

Replacing a tape drive..............................................................................................................................314.4

Removing the library controller.................................................................................................................324.5

Replacing the library controller.................................................................................................................324.6

Removing a power supply ........................................................................................................................334.7

Replacing the power supply .....................................................................................................................334.8

Servicing a magazine ...............................................................................................................................344.9

Removing the base chassis......................................................................................................................344.10

Preparing to remove the base chassis........................................................................................344.10.1

Removing the base chassis from the rack..................................................................................354.10.2

Replacing the base chassis......................................................................................................................354.11

5Packaging before transportation................................................................................................ 36

6Technical specifications............................................................................................................. 39

Hardware specifications............................................................................................................................396.1

Operating environment.............................................................................................................................406.2

Maximum storage capacity and data transfer rate ...................................................................................416.3

7Agency Certifications.................................................................................................................. 43

Recycling and disposal.............................................................................................................................437.1

Device standards......................................................................................................................................447.2

CE mark....................................................................................................................................................447.3

ETL mark ..................................................................................................................................................447.4

FCC (United States) .................................................................................................................................457.5

Canadian verification................................................................................................................................457.6

NEO S-Series User Guide

1 Introduction

Document Purpose1.1

This document provides information to install, operate, and upgrade the NEO S-Series Scalable Tape Library.

The instructions are intended for the trained System Administrators and technicians who need physical and

functional knowledge of the S-Series library.

The main components are:

Base library

Expansion module

Product Warranty Caution1.2

The customer should only perform the service and repair actions on the tape library components listed in this

document. Any other actions needed should only be performed by an authorized service center.

The warranty for the tape library shall not apply to failures of any unit when:

The tape library is repaired or modified by anyone other than the manufacturer’s personnel or approved

agent.

The tape library is physically abused or used in a manner that is inconsistent with the operating

instructions or product specification defined by the manufacturer.

The tape library fails because of accident, misuse, abuse, neglect, mishandling, misapplication, alteration,

faulty installation, modification, or service by anyone other than the factory service center or its approved

agent.

The tape library is repaired by anyone, including an approved agent, in a manner that is contrary to the

maintenance or installation instructions supplied by the manufacturer.

The manufacturer's serial number tag is removed.

The tape library is damaged because of improper packaging on return.

Warranty will become immediately void in the event of unauthorized repairs or modifications.

NEO S-Series User Guide

2 General Warnings

Document Conventions:2.1

WARNING

Indicates that failure to follow directions could result in bodily harm or

death.

CAUTION

Indicates that failure to follow directions could result in damage to

equipment or data.

IMPORTANT

Provides clarifying information or specific instructions.

NOTE

Provides additional information.

TIP

Provides helpful hints and shortcuts.

General Product Warnings2.2

DANGER

High voltage

Risk of electric shock

Do not remove covers (top, bottom or rear). No user-serviceable

parts are inside.

Refer servicing to qualified service personnel.

WARNING

Product Weight

Risk of personal injury

Before lifting a library:

Observe local health and safety requirements and guidelines for

manual material handling.

Remove all tapes to reduce the weight.

Remove all tape drives to reduce the weight.

Obtain adequate assistance to lift and stabilize the library during

installation or removal.

Risk of damage to devices

When placing a library into or removing the library from a rack:

Extend the rack’s leveling jacks to the floor.

Ensure that the full weight of the rack rests on the leveling jacks.

Install stabilizing feet on the rack.

Extend only one rack component at a time.

NEO S-Series User Guide

CAUTION

Static Sensitive

Risk of damage to devices

A discharge of static electricity damages static-sensitive devices or

micro circuitry.

Proper packaging and grounding techniques are necessary

precautions to prevent damage.

NOTE



Ventilation – Place the product in a location that does not interfere with

proper ventilation.

Heat – Place the product in a location away from heat sources.

Power sources – Connect the product to a power source only of the type

directed in the operating instructions or as marked on the product.

Power cord protection – Place the AC line cord so that it is not possible to be

walked on or pinched by items placed upon or against it.

Object and liquid entry – Insure that objects do not fall onto and that liquids

are not spilled into the product’s enclosure.

NEO S-Series User Guide

3 Troubleshooting

This chapter provides information for verifying correct installation and troubleshooting the library.

Installation problems3.1

Problems encountered during the installation of the library are usually caused by improper SCSI bus configuration,

application software configuration errors, or an incorrectly configured operating system.

If the used application software is not communicating with the library after installation, check the following:

SCSI ID3.1.1

The library uses a single SCSI ID. Depending on other devices attached to the same SCSI bus and their SCSI IDs,

change the SCSI ID of the library or tape drive before use the library.

Review the manuals for the other devices on the SCSI bus or the operating system to determine which SCSI IDs are

currently in use.

SCSI host adapter installation3.1.2

1. Verify that the SCSI host adapter is installed correctly.

Refer to the manual that came with the SCSI host adapter for installation and troubleshooting instructions.

2. Pay particular attention to any steps describing the settings of various jumpers and/or switches on the host adapter,

if applicable.

3. Make sure that the host adapter is properly seated in the motherboard slot and the operating system correctly detects

the host adapter.

4. Make sure that the proper device driver is installed for the SCSI host adapter.

LUN scanning3.1.3

Use dual LUNs to control the tape drive (LUN 0) and library robotic (LUN 1). These models require an HBA that

supports LUN scanning and LUN scanning must be enabled.

SCSI cabling3.1.4

1. Verify that all SCSI cables are securely connected at both ends.

2. Check the length and integrity of the SCSI cabling.

3. Check the SCSI connector for bent pins.

The length of the internal SCSI cabling inside the library is 2 feet (60 cm). This length must be included in any

calculations of cable length.

•For LVD SCSI the maximum length for a single device is 82 feet (25 meters).

•For multiple devices, the maximum combined internal/external length is 40 feet (12 meters).

•If you have a combination of LVD and SE devices on the bus, the maximum cable length reverts to the SE

specification, which for ultra devices is 10 feet (3 meters) for four or fewer devices, and 5 feet (1.5 meters) for

more than four devices.

Termination3.1.5

If the library is the only SCSI device — other than the SCSI host adapter — on the selected SCSI bus, it must be

terminated. Likewise, if the library is physically the last SCSI device on the SCSI bus, it must be terminated.

Only the devices physically located at the beginning and end of the SCSI bus should be terminated.

Refer to the manuals supplied with other devices on the SCSI bus for information on enabling or disabling termination

on those devices.

NEO S-Series User Guide

If available, take the terminator from the accessories bag. The supplied terminator is “dual mode” and will work on both

Low-Voltage Differential (LVD) and Single Ended (SE) SCSI buses.

To terminate the library, see Chapter Connecting the parallel SCSI cable, Page Error! Bookmark not defined..

Check all SCSI and power connections and confirm that the library is attached to a valid SCSI SE or LVDS bus.

Compatibility3.1.6

Ensure that the library is compatible with the SCSI host adapter and backup application you plan to use. For a list of

compatible SCSI adapters and application software, check with your SCSI host adapter manufacturer or backup

application vendor.

NOTE

The host bus adapter for the library should be SCSI-3 LVDs. A

single-ended SCSI host bus adapter will severely degrade

performance. Also, if there is any SE devices on the same SCSI bus,

the entire SCSI bus will negotiate down to SE speed and severely

degrade performance

Backup application installation3.1.7

Refer to the documentation included with your backup application for instructions on how to verify proper installation.

Some backup software packages require an additional module to communicate with the library robotics.

Device driver installation3.1.8

Make sure that the proper device driver, if applicable, is installed for the library. Contact your support representative for

more information

NOTE

Many backup applications use their own drivers for the library and

tape drive. Before installing a driver, make sure it will not be in

conflict with the software.

NEO S-Series User Guide

Troubleshooting table3.2

Problem

Solution

Poor throughput performance

•Try a new tape. A marginal tape can cause performance problems due to

bad spots on the tape requiring retries.

•Backing up data that compresses poorly or is already compressed will

lower performance.

•Check the size of the files. Small file size can impact performance.

•Confirm that the backup application is utilizing block sizes of at least

32KB, preferably 64KB. Refer to the backup application documentation

for details.

•Check the network bandwidth from the host computer. If you are backing

up data over a network, consider comparing to a local-only backup.

•Make sure the backup server has enough memory to handle the bandwidth

of the backup or restore.

•Clean the tape drive with:

OCP, see Chapter Cleaning tape drives, Page Error! Bookmark not

defined..

RMU, see Chapter Cleaning tape drive(s), Page Error! Bookmark not

defined..

Cleaning

Cannot load the cleaning

cartridge •Make sure you are using an Ultrium universal cleaning cartridge.

See Chapter Tape cartridge type, Page Error! Bookmark not defined..

•Contact your service representative.

Device Not Detected on SCSI Bus

Connected to a high voltage

differential SCSI bus/host

adapter

•Attach device to a LVDS SCSI host adapter/bus.

•SCSI cable length exceeded, use shorter cable, or removes other devices

from the bus.

•Check for conflicting SCSI IDs.

•Check that the HBA supports LUN scanning and this feature is enabled.

•Device not properly terminated. See Chapter Termination, Page 8.

•Power up device before powering up the host computer.

•Check that the device has been powered up and is not in an error state.

•Check the SCSI connector for bent pins.

Altri manuali per NEO S-Series

Indice

Altri manuali Overland Storage Magazzinaggio

Overland Storage

Overland Storage SnapServer XSD 40 Manuale utente

Overland Storage

Overland Storage NEOs StorageLoader Manuale utente

Overland Storage

Overland Storage LoaderXpress Guida

Overland Storage

Overland Storage Snap Server 210 Manuale utente

Overland Storage

Overland Storage SnapServer DX2 Manuale utente

Overland Storage

Overland Storage SnapServer XSR 120 Manuale utente

Overland Storage

Overland Storage NEO S-Series Manuale utente

Overland Storage

Overland Storage SnapSAN S2000 Manuale utente

Overland Storage

Overland Storage NEO 8000 Manuale utente

Overland Storage

Overland Storage NEO 2000e Manuale elenco delle parti

Overland Storage

Overland Storage NEO 400S Manuale utente

Overland Storage

Overland Storage SnapServer Manuale di servizio

Overland Storage

Overland Storage NEO XL Series Manuale utente

Overland Storage

Overland Storage SnapServer DX2 Manuale utente

Overland Storage

Overland Storage SnapSAN S3000 Manuale utente

Overland Storage

Overland Storage NEOxl 40 Manuale utente

Overland Storage

Overland Storage NEO XL Series Manuale

Overland Storage

Overland Storage NEO 4000e Manuale utente

Overland Storage

Overland Storage NEO 8000E Manuale utente

Overland Storage

Overland Storage REO Series Manuale utente

Overland Storage

Overland Storage NEO 8000E Manuale utente

Overland Storage

Overland Storage NEO 2000e Manuale utente

Overland Storage

Overland Storage NEO 200S Manuale utente

Overland Storage

Overland Storage NEO 8000 Manuale utente

Manuali Magazzinaggio popolari di altre marche

QNAP

QNAP TS 32PXU Series Manuale utente

LaCie

LaCie RUGGED RAID Manuale utente

Freecom

Freecom CLS DOCK Manuale utente

PNY

PNY Attache P-FD64MBATT3 Manuale utente

HP StorageWorks MSL2024 Manuale utente

OLT

OLT 6x6 Maximizer Manuale utente

Transcend

Transcend JetFlash 160 Manuale utente

LaCie

LaCie RUGGED MINI Manuale utente

Thunderbolt

Thunderbolt 600 Manuale utente

Panasonic

Panasonic LB-DH8 series Manuale

Intel

Intel RAID High Availability Manuale utente

LaCie

LaCie 12big Thunderbolt 3 Manuale utente

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuale utente

Panasonic

Panasonic LKM-F931-1 Manuale utente

Tabernus

Tabernus Enterprise Erase E2400 Manuale utente

Rocstor

Rocstor COMMANDER 3F series Manuale utente

HP P9000 Manuale utente

Western Digital

Western Digital Ultrastar Data60 Manuale utente
