Addendum

SnapServer®DX2 Rail Kit Change

Overview

Some versions of the SnapServer DX2 appliance’s rail kit come with bar nuts in place of the

clip nuts shown in the Quick Start Guide. This addendum provides the instructions necessary

to install the rail kit using the bar nuts.

Procedure

Use these steps to attach the rack rails in place the ones in Step 3 of the Quick Start Guide:

Size the Outer Rails to Rack

WARNING: It is recommended that a mechanical lifter (or at least two people) be used to raise and align

the unit to prevent injury during installation. Use care when inserting or removing a unit into or out of a

rack to prevent the accidental tipping of the rack, causing damage or personal injury.

AVERTISSEMENT: Afin d’éviter des blessures pendant l’installation, il est recommande d’utiliser un monte-

charge (ou au moins deux personnes) pour élever ou aligner l’appareil. Faites attention lorsque vous insérez ou

retirez l’appareil d’un support, pour empêcher le déversement accidentel de la crémaillère causant des

dommages et des blessures.

1. Measure the distance between the inside edges of the

front and rear vertical rails on the rack.

2. Check that the outside distance between the slide rail

front and rear flanges is slightly less than the rack

internal dimensions.

3. If necessary, remove the four bolts holding the outer

rail rear component, slide it out the needed

distance, and loosely reinstall the nuts and bolts.

NOTE: For some racks, only two bolts can be used with the rear component due to the location

of the slots. This does not impact the stability of the rails.

4. Repeat Step 3 for the other rail.

Attach Outer Rails

1. At the front, determine the 2U area where the DX2 is to be

mounted, and mark the second and fourth holes from the

top on both sides.

NOTE: The bottom rail hole is used by the captive screw on the unit

to secure the DX2.

2. Position a slide rail between the front and rear rack rails

with the rail kit flanges on the inside of the rack rails and

pointing outward.

3. At the front, use two 10-32 screws to secure the front of the

slide rail:

a. Align the top rail hole with the second (marked)

rack hole and insert the screw.

Nuts & Bolts

Rear

Component

DX2 2U

Mark #2

Mark #4

Rack

Slide Rail

Bar Nut

(Top View)

(Front View)

*10400379001*

Addendum

b. Align the bar nut top hole with the screw and loosely secure the slide rail to the

rack.

c. Repeat Steps a–b for the fourth hole in the rack.

5. At the rear, use a bar nut and two screws in the top and bottom rail flange holes to

loosely secure the rear of the slide rail to the rack.

6. For the other rail, repeat Steps 2–5.

7. Verify both rails are level and tighten all screws.

Continue with “Install the Unit” in the SnapServer DX2 Quick Start Guide.

Additional Help

For help with your SnapServer DX2 appliance, search at:

http://support.overlandstorage.com/kb

You can email our technical support staff at techsupport@overlandstorage.com

or get additional technical support information on the Contact Us web page:

http://docs.overlandstorage.com/support

For a complete list of support times depending on the type of coverage, visit our website at:

http://docs.overlandstorage.com/care
