Oxygen X-Air V500E Manuale utente
Rev 1.1 2021.04
INSTALLATION AND OPERATION MANUAL
Heat Recovery Unit
OXYGEN X-Air V400E, V500E
enthalpy exchanger
1
2
TABLE OF CONTENTS
1. TRANSPORTATION AND STORAGE OF EQUIPEMENT ................................................................................................. 3
2. UNIT PACKAGE ........................................................................................................................................................... 4
3. SAFETY REQUIREMENTS ............................................................................................................................................. 5
4. EU DECLARATION OF CONFORMITY........................................................................................................................... 6
5. TECHNICAL DATA ....................................................................................................................................................... 7
5.1. Product information sheet. Delegated Regulation (EU) 1254/2014 ............................................................. 7
5.2. Performance curves ...................................................................................................................................... 8
5.3. Performance and power consumption ......................................................................................................... 8
5.4. Sound characteristics .................................................................................................................................. 10
9.2. Dimensions and weight ............................................................................................................................... 11
6. FUNCTIONALITY ....................................................................................................................................................... 12
7. INSTALLATION OF THE UNIT .................................................................................................................................... 13
7.1. Selecting the mounting location ................................................................................................................. 13
7.2. Connecting ducts ........................................................................................................................................ 13
7.3. Maintenance space ..................................................................................................................................... 14
7.4. Ventilation system balancing ...................................................................................................................... 15
8. CONNECTION OF THE UNIT ...................................................................................................................................... 16
8.1. Connecting electric circuit .......................................................................................................................... 17
8.2. Installation of the control panel ................................................................................................................. 17
8.3. Connector of comfort functions ................................................................................................................. 18
8.4. Control board electrical wiring diagram ..................................................................................................... 20
8.5. Description of control board contacts ........................................................................................................ 21
9. OPERATION OF THE UNIT ......................................................................................................................................... 22
9.1. WiFi controller ............................................................................................................................................ 22
9.1.1. Downloading the app ............................................................................................................................. 22
9.1.2. WiFi connection set-up ........................................................................................................................... 23
9.1.3. App home screen .................................................................................................................................... 25
9.1.4. Setting up weekly operation program .................................................................................................... 25
9.1.5. Ventilation boost activation ................................................................................................................... 26
9.1.6. Away ....................................................................................................................................................... 26
9.1.7. Filter menu ............................................................................................................................................. 27
9.1.8. Resetting WiFi controller to factory defaults ......................................................................................... 27
9.2. Control panel with touchscreen display ..................................................................................................... 28
9.2.1. Standby mode......................................................................................................................................... 28
9.2.2. Main screen ............................................................................................................................................ 29
9.2.3. Settings menu ......................................................................................................................................... 30
9.2.4. Setting up weekly operation program .................................................................................................... 31
9.2.5. Failure indication .................................................................................................................................... 31
9.3. Control panel with a knob ........................................................................................................................... 32
9.3.1. Operating state indicator ....................................................................................................................... 32
9.3.2. Air filter replacing / anti-frost protection indicator ............................................................................... 33
9.3.3. Failure indicator ...................................................................................................................................... 33
9.3.4. RESET procedure .................................................................................................................................... 34
9.3.5. Resetting the filter lifetime meter .......................................................................................................... 34
9.3.6. Additional system settings ..................................................................................................................... 35
9.4. Replacing air filters ..................................................................................................................................... 36
10. MAINTEINANCE AND WARRANTY ............................................................................................................................ 38
11. CONTACTS ................................................................................................................................................................ 39
3
1. TRANSPORTATION AND STORAGE OF EQUIPEMENT
Heat Recovery Unit (hereinafter – the Unit) is prepared for transportation and storage. Packaging
materials ensure protection against exposure to environment, dust and humidity. The Unit must be
properly secured during transportation to protect it against possible housing deformation or other
mechanical damage.
Transportation conditions:
-20oC - +40oC.
Long-term storage conditions:
+5oC - +40oC, relative air humidity <= 50%.
CONSIGNMENT ACCEPTANCE:
Carefully check the received consignment – make sure that the number of packages matches
with the consignment documentation. Upon noticing any non-conformity or damage of the
package (tears, dents or compressed box, detached or reattached packaging tape), inform the
courier immediately and indicate the disrepancies or damages in the consignment document.
Verify if the right product was delivered. Upon noticing any non-conformity, inform the Sender
immediately.
Verify if all the supplementary parts listed were delivered. In case of any doubt, contact the
Sender immediately.
Do not attempt to repair the Unit, damaged during the transportation by yourself!
IMPORTANT! Sender does not assume any obligations towards damage or loss of the Unit or its part,
if there is no a corresponding record in the consignment document!
4
2. UNIT PACKAGE
Heat Recovery Unit OXYGEN X-Air V400E 1 pc
Control panel (10m connection cable included) or WiFi adapter 1 pc
Fastening elements:
Mounting bracket 1 pc
Installation manual 1 pc
5
3. SAFETY REQUIREMENTS
Carefully read and follow safety requirements provided below before installing and while operating
the Unit:
Do not discard the Installation and operation manual, keep it for future reference.
The Unit should be installed and operated in compliance with this Installation and operation
manual, following the requirements of effective legislation and standards.
When connecting the Unit to mains supply, grounding must be installed in compliance with
requirements of effective legislation and standards.
To prevent accidents and potential damage to the Unit it should be installed, connected,
maintained and repaired only by qualified technician. Never attempt to do this by yourself!
Turn off the Unit by using Control panel and wait for fans to stop completely before replacing
air filters.
Turn off the Unit by using Control panel, wait for fans to stop completely and disconnect the
Unit from mains supply before performing any maintenance.
Disconnect the Unit from mains supply before disconnecting or reconnecting the control
panel.
Before connecting the Unit make sure that no items will get sucked into the its air intake
openings!
The Unit is not intended to be used by persons (including children) with reduced physical,
sensory or mental capabilities, unless they have been instructed to use the Unit and under
constant supervision of person held responsible for their safety.
Children may only use the Unit under adult supervision.
Only original supplementary parts and consumables, certified by manufacturer should be
used.
The Unit package (cardboard, plastic, foam polystyrene) can pose hazard to children. Dispose
or recycle the package elements!
Disused Unit should be disposed in accordance with requirements of legislation on handling
of waste electrical and electronic equipment.
IT IS PROHIBITED to operate the Unit with damaged mains supply cable! Switch off the power
circuit-breaker to disconnect mains supply and contact a qualified technician or manufacturer
service centre immediately upon noticing such damage.
IT IS PROHIBITED to attempt the repair of the damaged Unit or its part, to open its cover!
Contact a qualified technician or manufacturer service centre.
IT IS PROHIBITED to operate the Unit while construction works are still in progress to remove
dust or excess moisture. Fine dust of building materials, used in construction, can irreversibly
change characteristics of the heat exchanger or cause damage to sensitive electronic
components. Failure of the Unit caused by such operation will void the warranty.
6
4. EU DECLARATION OF CONFORMITY
We, undersigned below, representing the manufacturer of ventilation equipment:
Sviezias oras, JSC
Birzelio 23-osios g. 23G
50220 Kaunas
LITHUANIA
confirm, that heat recovery ventilation device OXYGEN X-Air V400E conforms to Europe Union
standarts, directives and regulations:
2009/125/EC – eco-design requirements for energy-related products
ES 1253/2014
ES 1254/2014
ES 2017/1369
EN 13141-7:2010
2010/30/EU – labelling and standard product information of the consumption of energy and other
resources by energy-related products
ES 1254/2014
2011/65/EU – restriction of the use of certain hazardous substances in electrical and electronic
equipment (RoHS)
EN 50581(2012)
2014/35/EU – harmonization of the laws of the Member States relating to the making available on
the market of electrical equipment designed for use within certain voltage limits
EN 60335-1:2012
EN 60335-1:2012/A11:2014
CEO Zilvinas Salialionis
01.02.2021, Kaunas
7
5. TECHNICAL DATA
5.1. Product information sheet. Delegated Regulation (EU) 1254/2014
a) Supplier's name or trade mark OXYGEN
b) Model identifier X-Air V400E
c) Specific energy consumption (SEC), SEC class A
Cold climate kWh/m
2
.a -82.9
Average climate kWh/m
2
.a -40.9
Warm climate kWh/m
2
.a -16.9
d) Declared typology Bi-directional,
residential ventilation
e) Type of drive installed or intended to be Multi-speed drive
f) Type of heat recovery system Recuperative
g) Thermal efficiency of heat recovery % 75.0
h) Maximum flow rate m
3
/h 400
i) Electric power input of the fan drive, including W 167
j) Sound power level (L
WA
) 51
k) Reference flow rate m
3
/s 0.078
l) Reference pressure difference Pa 50
m) Specific power input (SPI) W/(m3/h) 0.22
n) Control factor 0.65
Control typology Local demand control
o) Declared maximum leakage rate:
internal % 1.2
external % 1.1
q) Position and description of visual filter warning Refer to installation
and operation manual
s) Internet address for pre-/dis-assembly www.oxygenvent.com
v) The annual electricity consumption (AEC) kWh/m
2
.a
1.2
w) The annual heating saved (AHS)
Cold climate kWh/a 85.7
Average climate kWh/a 43.8
Warm climate kWh/a 19.8
8
5.2. Performance curves
Graph. 1. Ventilation power dependence on the resistance of installed ventilation system
5.3. Performance and power consumption
Power setting Resistance, Pa Air flow, m3/h El. consumption, W
100%
100 400 166.9
150 381 166.0
200 356 165.1
250 329 164.0
300 300 162.3
350 266 159.1
400 224 157.6
450 179 156.2
70%
50 284 76.6
75 269 76.4
100 254 76.2
125 238 75.7
150 221 75.2
175 201 73.0
200 179 71.8
225 154 70.9
0
50
100
150
200
250
300
350
400
450
500
100 150 200 250 300 350 400 450
Resistance, Pa
Air flow, m3/h
Performance curves
50%
70%
100%
9
50%
20 204 39.0
30 196 39.0
40 188 38.9
50 179 38.7
60 171 38.4
70 162 38.2
80 153 38.0
90 142 38.0
Measured with M5 class filters installed.
