Panasonic WV-LFY3C3 Manuale utente

Cautions:

• This lens cannot be used with some color

CCTV cameras.

Please contact your sales company for

details.

• If the lens is very dirty, wipe it with a soft

and dry cloth or a cloth moistened with a

solution of water and normal kitchen

detergent.

Please wipe carefully not to scratch the

plastic lens surface.

Do not use chemicals for cleaning the

cover as it may damage the surface.

• Always turn the Flange-back Adjusting

Ring clockwise by loosing the screws on

the ring before mounting the lens.

Otherwise the inner glass and CCD

image sensor could be damaged by the

lens.

Note: When the super wide lens (WV-

LFY3C3) is used with the camera (WV-

CPR650, WV-CP650, WV-CP450, WV-

CP150, WV-BP550, etc.), the edge of the

picture may appear darker. In this case,

adjust the brightness of the monitor.

Installations

1. Set the lens type selector to the ELC

position.

2. Mount the lens by turning it clockwise on

the lens mount of the camera.

3. Loosen screws on the Flange-back

Adjusting Ring of the camera, then turn

this ring to bring the object into focus.

N0598-2078 YWV8QA4985CN Printed in Japan

N 30

Focus adjustment

for CS-mount lens Screws Flange-back

Adjusting Ring

Caution:

Do not turn this ring excessively

counter-clockwise as this could

damage the inner glass and CCD

image sensor.

4. Tighten the screws on the Flange-back

Adjusting Ring carefully.

Before attempting to connect or operate this product,

please read these instructions completely.

Fixed Iris Lens

WV-LFY3C3

WV-LFY45C3

WV-LFY9C3

WV-CP150 series

WV-CP450 series

WV-CP650 series

WV-CPR650

series

WV-LFY9C3

(Standard)

Models

Specifications

Serial No.

Model

Specifications

Addendum

This lens is adaptable to B/W CCTV camera, and color CCTV camera shown below.

75****** 76****** 77****** 78****** 79****** 7X****** 7Y****** 7Z****** 81****** 82******

WV-CP120 series

WV-CP220 series

WV-CP410 series

WV-CP610 series NO Yes

Yes

WV-LFY3C3

(Wide Angle) WV-LFY45C3

(Wide Angle)

Focal Length 3mm 4.5 mm 9 mm

Angular Field of View 99.9° 60.6° 29.9°

78.2°

V 44.8° 22.6°

Adjusted by CameraFocusing Range

CS-mount, 1”-32UNMount

NoneFilter Size

Ambient Operating

Temperature

φ38.4 x 18.5 mm φ33.4 x 31.6 mm φ33.4 x 32.8 mm

Dimensions

15g (0.5 oz) 20g(0.7 oz) 20g(0.7 oz)

Weight

Maximum Aperture Ratio 1 : 2.8

Image Size φ6 mm [4.8 (H) x 3.6 (V) mm]

Dimensions and weight indicated are approximate.

Specifications are subject to change without notice.

−30°C - +60°C (−22°F - +140°F)

Video Imaging Systems Company

A Division of Panasonic Broadcast & Television Systems Company

A Unit of Matsushita Electric Corporation of America

Executive Office: One Panasonic Way 4H-2, Secaucus, New Jersey 07094
