Panasonic DVD-S35GD Manuale utente

Navigator
Table Of Contents
COVER
SAFETY PRECAUTIONS
1 GENERAL GUIDELINES
1.1 LEAKAGE CURRENT COLD CHECK
1.2 LEAKAGE CURRENT HOT CHECK (See Figure 1 .)
PREVENTION OF ELECTRO STATIC DISCHARGE (ESD) TO ELECTROSTATICALLY SENSITIVE (ES) DEVICES
Precaution of Laser Diode
About lead free solder (PbF)
General Description
1 Operating instructions
PREVENTION OF STATIC ELECTRICITY DISCHARGE
1 Grounding for electrostatic breakdown prevention
1.1 Worktable grounding
1.2 Human body grounding
1.3 Handling of optical pickup
2 Handling Precautions for Traverse Unit (Optical Pickup)
Disassembling the Casing and Checking P.C.B.s
1 Dissasembly Procedure
2 Casing Parts and P.C.B. Positions
3 Top Panel
4 Front Panel
5 Rear panel
6 Power supply P.C.B.
7 Main P.C.B. and Mechanism Unit
8 Motor P.C.B.
9 Operation (L) P.C.B. and Operation (R) P.C.B.
10 Service Position
10.1 Servicing position of the Main P.C.B. and the Operation P.C.B.
10.2 List of the Extension Cables
ASSEMBLING AND DISASSEMBLING THE MECHANISM UNIT
1 Disassembly Procedure
2 Motor P.C.B.
file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/navigator.html (1 of 4)03.10.2007 22:42:57

Navigator
3 Clamp Plate Unit
4 Tray
5 Traverse Block
6 Traverse Gear
7 Optical Pickup Unit
7.1 Precautions in optical pickup replacement
7.2 Disassembling the Optical Pickup Unit
7.3 Cautions to Be Taken When Replacing the Optical Pickup
8 Disassembling the Middle Chassis
9 Disassembling the Traverse Gear A&sol; FG P.C.B.
10 Disassembling the Spindle Motor Unit
Self-Diagnosis Function and Service Modes
1 Optical Pickup Breakdown Diagnosis
2 Service Mode Table 1
3 DVD Self Diagnostic Function-Error Code
4 Last Error Code saved during NO PLAY
5 Service mode table 2
6 Sales demonstration lock function
6.1 Setting
6.2 Cancellation
7 Handling After Completing Repairs
7.1 Method
7.2 Precautions
Servicw Precautions
1 Recovery after the dvd player is repaired
2 Firmware version-up of the DVD player
ADJUSTMENT PROCEDURES
1 Service Tools and Equipment
2 Important points in adjustment
2.1 Important points in optical adjustment
2.2 Important points in electrical adjustment
3 Storing and Handling Test Discs
4 Optical adjustment
file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/navigator.html (2 of 4)03.10.2007 22:42:57

Navigator
4.1 Optical pickup tilt adjustment
4.1.1 Adjustment procedure
4.1.2 Important points
4.1.3 Check after adjustment
4.1.4 Procedure for screw lock
Abbreviations
VOLTAGE CHART
1 POWER SUPPLY P.C.B.
2 MAIN P.C.B.
3 OPERATION P.C.B.
BLOCK DIAGRAM
1 OVERALL BLOCK DIAGRAM
2 POWER SUPPLY BLOCK DIAGRAM (DVD-S35GCS&sol;GCU&sol;GC&sol;GCA&sol;GD&sol;EE&sol;GN&sol;PL&sol;PX&sol;PLA)
3 POWER SUPPLY BLOCK DIAGRAM (DVD-S35PLA)
4 SERVO BLOCK DIAGRAM
5 VIDEO BLOCK DIAGRAM
6 AUDIO BLOCK DIAGRAM
INTERCONNECTION SCHEMATIC DIAGRAM& SCHEMATIC DIAGRAM NOTES
1 INTERCONNECTION SCHEMATIC DIAGRAM
2 SCHEMATIC DIAGRAM NOTES
SCHEMATIC DIAGRAM
1 POWER SUPPLY SCHEMATIC DIAGRAM (DVD-S35GCS&sol;GCU&sol;GC&sol;GCA&sol;GD&sol;PL&sol;PX)
2 POWER SUPPLY SCHEMATIC DIAGRAM (DVD-S35EE&sol;GN)
3 POWER SUPPLY SCHEMATIC DIAGRAM (DVD-S35PLA)
4 PRE SECTION (MAIN P.C.B. (1&sol;3)) SCHEMATIC DIAGRAM (DVD-S35GCS&sol;GCU&sol;GC&sol;GCA&sol;GD&sol;EE&sol;GN&sol;PL&sol;PLA)
5 DV1 SECTION (MAIN P.C.B. (2&sol;3)) SCHEMATIC DIAGRAM (DVD-S35GCS&sol;GCU&sol;GC&sol;GCA&sol;GD&sol;EE&sol;GN&sol;PL&sol;PLA)
6 AUDIO&sol;VIDEO SECTION (MAIN P.C.B. (3&sol;3)) SCHEMATIC DIAGRAM (DVD-S35GCS&sol;GCU&sol;GC&sol;GCA&sol;GD&sol;EE&sol;GN&sol;PL&sol;PLA)
7 PRE SECTION (MAIN P.C.B. (1&sol;3)) SCHEMATIC DIAGRAM (DVD-S35PX)
8 DV1 SECTION (MAIN P.C.B. (2&sol;3)) SCHEMATIC DIAGRAM (DVD-S31PX)
9 AUDIO&sol;VIDEO SECTION (MAIN P.C.B. (3&sol;3)) SCHEMATIC DIAGRAM (DVD-S35PX)
10 MOTOR SCHEMATIC DIAGRAM
11 OPERATION SCHEMATIC DIAGRAM
PRINT CIRCUIT BOARD
file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/navigator.html (3 of 4)03.10.2007 22:42:57

Navigator

17.1 POWER SUPPLY P.C.B. (DVD-S35GCS/GCU/GC/GCA/GD/PL/PX)

17.2 POWER SUPPLY P..B. (DVD-S35EE/GN)

17.3 POWER SUPPLY P.C.B. (DVD-S35PLA)

17.4 MAIN P.C.B. (1/2) (COMPONENT SIDE) (DVD-S35GCS/GCU/GC/GCA/GD/EE/GN/PL/PLA)

17.5 MAIN P.C.B. (2/2) (FOIL SIDE) (DVD-S35GCS/GCU/GC/GCA/GD/EE/GN/PL/PLA)

17.6 MAIN P.C.B. ADDRESS INFORMATION

17.7 MAIN P.C.B. (1/2) (COMPONENT SIDE) (DVD-S35PX)

17.8 MAIN P.C.B. (2/2) (FOIL SIDE) (DVD-S35PX)

17.9 MOTOR P.C.B.

17.10 OPERATION P.C.B.

18 EXPLODED VIEWS

18.1 Casing Parts& Mechanism Section Exploded View

18.2 Mechanism Section Exploded View

18.3 Packing& Accessories Section Exploded View

19 REPLACEMENT PARTS LIST

20 Schematic Diagram for printing with A4 size

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/navigator.html (4 of 4)03.10.2007 22:42:57

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0000000000.html

Service Manual

TOP NEXT

ORDER NO.CHM0306017C0

DVD Player

●DVD-S35EE

DVD-S35GN

DVD-S35PL

DVD-S35PLA

DVD-S35PX

❍DVD-S35GCS

DVD-S35GCU

DVD-S35GC

DVD-S35GCA

DVD-S35GD

DL1S Mechanism Series

Colour

(S).......................Silver Type

(K).......................Black Type (S35EE Only)

Specifications

Power supply: AC120 V, 60 Hz

(DVD-S35PLA only)

AC220-240V, 50Hz

(DVD-S35EE/GN only)

AC110-240V, 50/60Hz

(except DVD-S35PLA/EE/GN)

Power consumption: 14 W

Dimensions: 430 (W)×267 (D)×60 (H) mm

[1615/ 16”(W) x 108/ 16”(D) x 27/ 16” (H)]

(excludingprotrusions)

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0000000000.html (1 of 4)03.10.2007 22:43:11

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0000000000.html

Mass: 2.1 kg (4.7 lb.)

Signal system: NTSC

(DVD-S35PX only)

PAL625/50, PAL525/60, NTSC

(except DVD-S35PX)

Operating temperature range: +5 to+35°C (+41 to 95°F)

Operating humidity range: 5 to 90% RH (no condensation)

Region number: Region No.1

(DVD-S35PX only)

Region No.2

(DVD-S35GC/GCA)

Region No.3

(DVD-S35GCS/GCU/GD)

Region No.4

(DVD-S35GN/PL/PLA)

Region No.5

(DVD-S35EE only)

Discs played [8 cm (3”) or 12 cm (5”)]:

(1) DVD-RAM (DVD-VR compatible)

(2) DVD-Audio (except DVD-S35PX)

(3) DVD-Video

(4) DVD-R (DVD-Video compatible)

(5) CD-Audio (CD-DA)

(6) Video CD

(7) SVCD (Conforming to IEC62107)

(8) CD-R/CD-RW (CD-DA, Video CD formatted discs)

(9) WMA/MP3

•Maximum number of tracks and groups recognizable:

999 tracks and 99 groups

•Compatible compression rate:

WMA: between 48 kbps and 192 kbps

MP3: between 32 kbps and 320 kbps

(10) JPEG

•Exif Ver 2.1 JPEG Baseline files

•Maximum number of pictures and groups recognizable:

3000 pictures and 300 groups

•Picture resolution:

between 320× 240 and 6144× 4096 pixels (sub sampling is 4:2:2 or 4:2:0)

Video output:

Output level: 1 Vp-p (75Ω)

Output terminal: Pin jack

Number of terminal: 1 system

S video output:

Y output level: 1 Vp-p (75Ω)

C output level: NTSC; 0.286 Vp-p (75Ω)

PAL; 0.300Vp-p (75Ω)

(except DVD-S35PX)

Output terminal: S terminal

Number of terminal: 1 system

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0000000000.html (2 of 4)03.10.2007 22:43:11

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0000000000.html

Component video output (480P/480I)

(DVD-S35PXonly)

(NTSC:480p/480I,PAL:576I)

(exceptDVD-S35PX)

Y output level: 1 Vp-p (75Ω)

PB output lebel: 0.7 Vp-p (75Ω)

PR output level 0.7 Vp-p (75Ω)

Output terminal: Pin jack

(Y:green, PB :blue, PR :red)

Number of terminal: 1 system

Audio output:

Output level: 2 Vrms (1 kHz, 0 dB)

Output terminal: Pin jack

Number of terminal

2 channel: 1 system

Audio performance:

(1) Frequency response:

•DVD (linear audio): 4 Hz-22 kHz (48 kHz sampling)

4 Hz-44 kHz (96 kHz sampling)

•DVD-Audio:

(exept DVD-S35PX) 4 Hz-88 kHz

(192 kHz sampling)

•CD audio: 4 Hz-20 kHz

(2) S/N ratio:

•CD audio: 115 dB

(3) Dynamic range:

•DVD (linear audio): 100 dB

•CD audio: 98 dB

(4) Total harmonic distortion:

•CD audio: 0.0025%

Digital audio output:

Optical digital output: Optical terminal

Pickup

Wave length: 658 nm/790 nm

Laser power: CLASS Ua/ CLASS I

(DVD-S35PX only)

CLASS 2/ CLASS 1

(except DVD-S35PX)

Power consumption in standby mode:

approx. 2W

Solder:

This model uses lead free solder (PbF).

Note:

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0000000000.html (3 of 4)03.10.2007 22:43:11

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0000000000.html

Specifications are subject to change without notice.

Mass and dimensions are approximate.

TOP NEXT

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0000000000.html (4 of 4)03.10.2007 22:43:11

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0100000000x.html

1 SAFETY PRECAUTIONS

TOP PREVIOUS NEXT

1.1 GENERAL GUIDELINES

1.1.1 LEAKAGE CURRENT COLD CHECK

1.1.2 LEAKAGE CURRENT HOT CHECK (See Figure 1 .)

TOP PREVIOUS NEXT

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0100000000x.html03.10.2007 22:43:17

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0101000000.html

1.1 GENERAL GUIDELINES

TOP PREVIOUS NEXT

1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which

have been overheated or damaged by the short circuit.

2. After servicing, see to it that all the protective devices such as insulation barriers, insulation

papers shields are properly installed.

3. After servicing, make the following leakage current checks to prevent the customer from being

exposed to shock hazards.

1.1.1 LEAKAGE CURRENT COLD CHECK

1.1.2 LEAKAGE CURRENT HOT CHECK (See Figure 1 .)

TOP PREVIOUS NEXT

file:///C|/Documents and Settings/eDOK/Рабочий стол/DVD-S35xx/s0101000000.html03.10.2007 22:43:27
