Thank you for purchasing a Panasonic digital cordless phone.

Please read this installation manual before using the unit and

save it for future reference.

For assistance, visit our website:

http://www.panasonic.com/help

for customers in the U.S.A. or

Puerto Rico.

This unit is an additional handset compatible with the following

series of Panasonic Digital Cordless Phones:

KX-TG6311/KX-TG6321/KX-TG9331/KX-TG9341/

KX-TG9361/KX-TG9371/KX-TH1211

You must register this handset with your base unit before it can

be used. This installation manual describes only the steps

needed to register and begin using the handset. Please read

the base unit’s operating instructions for further details.

Charge the batteries for about 7 hours before initial use.

Additional Digital Cordless Handset

Model No. KX-TGA935

Installation Manual

PNQX1009ZA DM0108PN0

TGA935(e).fm Page 1 Tuesday, January 15, 2008 7:47 PM

2For assistance, please visit http://www.panasonic.com/help

Supplied accessories

*1 Please read the base unit’s operating instructions for replacement

battery information.

*2 The handset cover comes attached to the handset.

Note:

LPlease read the base unit’s operating instructions for additional/

replacement accessories.

Sales and support information

LTo order additional/replacement accessories, call 1-800-332-5368.

LTTY users (hearing or speech impaired users) can call 1-866-605-

1277.

Connection

Note:

LUse only the supplied Panasonic AC adaptor PQLV209.

LThe AC adaptor must remain connected at all times. (It is normal for

the adaptor to feel warm during use.)

Accessory item/Order number Quantity

Charger/PNLC1003ZB 1

AC adaptor for charger/PQLV209T 1

Rechargeable batteries*1 2

Handset cover*2/PNYNTGA936BR 1

Belt clip/PNKE1011Z1 1

(120 V AC,

60 Hz)

Hooks

TGA935(e).fm Page 2 Tuesday, January 15, 2008 7:47 PM

For assistance, please visit http://www.panasonic.com/help 3

Battery installation and battery charge

Important:

LUse the supplied rechargeable batteries (Part No. HHR-65AAABU).

LWhen installing the batteries:

– Wipe the battery ends (S, T) with a dry cloth.

– Avoid touching the battery ends (S, T) or the unit contacts.

– Ensure correct polarities (S, T).

LWhen replacing the batteries:

– USE ONLY rechargeable Ni-MH batteries AAA (R03) size.

– Do NOT use Alkaline/Manganese/Ni-Cd batteries.

– We recommend using the Panasonic rechargeable batteries noted

in the base unit’s operating instructions for replacement battery

information.

1Release the battery cover

latch and lift the cover open.

2Insert the batteries negative

(T) end first.

Place the handset on

the charger for about

7 hours before initial

use.

Fasten the battery

cover latch.

Close the handset

cover.

TGA935(e).fm Page 3 Tuesday, January 15, 2008 7:47 PM

4For assistance, please visit http://www.panasonic.com/help

Note:

LIf the batteries are fully charged, but the operating time seems to be

shorter, clean the battery ends (S, T) and the charge contacts with a

dry cloth.

Attention:

Registering a handset to a base unit

1Base unit:

KX-TG6311/KX-TG9361/KX-TH1211

Press and hold {LOCATOR}for 4 seconds. (No registration tone)

KX-TG6321/KX-TG9331/KX-TG9341/KX-TG9371

Press and hold {LOCATOR}for 4 seconds until the registration tone

sounds.

LIf all registered handsets start ringing, press the same button to

stop. Then repeat this step.

LThe next step should be completed within 90 seconds.

2Handset:

Press {OK}, then wait until a long beep sounds.

Note:

LWhile registering, “Base registering”is displayed on all

registered handsets.

LIf “Error!!”is displayed while registering, press {OFF}and register

the handset again.

A nickel metal hydride battery that is

recyclable powers the product you

have purchased.

Please call 1-800-8-BATTERY (1-

800-822-8837) for information on how

to recycle this battery.

TGA935(e).fm Page 4 Tuesday, January 15, 2008 7:47 PM

For assistance, please visit http://www.panasonic.com/help 5

Display language

1{MENU}i{#}{1}{1}{0}

2{V}/{^}: Select the desired setting.

3Press the right soft key to save. i{OFF}

Wall mounting

1Drive the screws (not included) into the wall.

2Mount the charger (A), then slide it down (B) and to the right (C)

until it is secure.

Belt clip

You can hang the handset on your belt or pocket using the supplied belt

clip.

NTo attach the belt clip NTo remove the belt clip

25.4 mm

(1 inch)

Screws

(120 V AC, 60 Hz)

TGA935(e).fm Page 5 Tuesday, January 15, 2008 7:47 PM

6For assistance, please visit http://www.panasonic.com/help

For your safety

To prevent severe injury and loss of life/property, read this section

carefully before using the product to ensure proper and safe operation of

your product.

WARNING

Power connection

LCompletely insert the AC adaptor/power plug into the power outlet.

Failure to do so may cause electric shock and/or excessive heat

resulting in a fire.

LRegularly remove any dust, etc. from the AC adaptor/power plug by

pulling it from the power outlet, then wiping with a dry cloth.

Accumulated dust may cause an insulation defect from moisture, etc.

resulting in a fire.

LUnplug the product from power outlets if it emits smoke, an abnormal

smell, or makes an unusual noise. These conditions can cause fire or

electric shock. Confirm that smoke has stopped emitting and contact

the Panasonic Call Center at 1-800-211- PANA (1-800-211-7262).

Installation

LTo prevent the risk of fire or electrical shock, do not expose the product

to rain or any type of moisture.

LDo not place or use this product near automatically controlled devices

such as automatic doors and fire alarms. Radio waves emitted from

this product may cause such devices to malfunction resulting in an

accident.

CAUTION

Installation and relocation

LThe AC adaptor is used as the main disconnect device. Ensure that

the AC outlet is installed near the product and is easily accessible.

TGA935(e).fm Page 6 Tuesday, January 15, 2008 7:47 PM

For assistance, please visit http://www.panasonic.com/help 7

Battery

LWe recommend using the supplied batteries or additional/replacement

batteries noted in the base unit’s operating instructions for

replacement battery information. USE ONLY rechargeable Ni-MH

batteries AAA (R03) size.

LDo not mix old and new batteries.

LDo not open or mutilate the batteries. Released electrolyte from the

batteries is corrosive and may cause burns or injury to the eyes or skin.

The electrolyte may be toxic if swallowed.

LExercise care when handling the batteries. Do not allow conductive

materials such as rings, bracelets or keys to touch the batteries,

otherwise a short circuit may cause the batteries and/or the conductive

material to overheat and cause burns.

LCharge the batteries provided with or identified for use with this

product only, in accordance with the instructions and limitations

specified in this manual.

LOnly use a compatible base unit (or charger) to charge the batteries.

Do not tamper with the base unit (or charger). Failure to follow these

instructions may cause the batteries to swell or explode.

Other information

LOperating the product near electrical appliances may cause

interference. Move away from the electrical appliances.

LUse only the power cord and batteries indicated in this manual. Do not

dispose of batteries in a fire. They may explode. Check with local

codes for possible special disposal instructions.

Routine care

LWipe the outer surface of the product with a soft moist cloth.

LDo not use benzine, thinner, or any abrasive powder.

Notice for product disposal, transfer, or return

LThis product can store your private/confidential information. To protect

your privacy/confidentiality, we recommend that you erase the

TGA935(e).fm Page 7 Tuesday, January 15, 2008 7:47 PM

8For assistance, please visit http://www.panasonic.com/help

information such as phonebook or caller list entries from the memory

before you dispose of, transfer, or return the product.

Splash resistance (handset only)

The handset is designed to be splash-resistant. You can use the handset

with wet hands.

LDo not immerse in water or leave under running water.

LKeep the handset away from salt water.

LAvoid exposure to prolonged high humidity.

LSince water in headset jack may cause damage, close the headset

jack cover when the optional headset is not in use. When the optional

headset is connected, do not use the handset with wet hands.

LIf the handset is wet, wipe with a soft dry cloth.

LThe base unit/charger is not designed to be splash resistant. Do not

place the handset on the base unit/charger if the handset is wet.

Drop resistance (handset only)

The handset is designed to be drop-resistant, however, it should not be

thrown or stepped on.

FCC and other information

This equipment is hearing aid compatible as defined by the FCC in 47

CFR Section 68.316.

When you hold the phone to your ear, noise might be heard in your

Hearing Aid. Some Hearing Aids are not adequately shielded from

external RF (radio frequency) energy. If noise occurs, use an optional

headset accessory or the speakerphone option (if applicable) when

using this phone. Consult with your audiologist or Hearing Aid

manufacturer about the availability of Hearing Aids which provide

adequate shielding to RF energy commonly emitted by digital devices.

WHEN PROGRAMMING EMERGENCY NUMBERS AND(OR) MAKING

TEST CALLS TO EMERGENCY NUMBERS:

TGA935(e).fm Page 8 Tuesday, January 15, 2008 7:47 PM

For assistance, please visit http://www.panasonic.com/help 9

1) Remain on the line and briefly explain to the dispatcher the reason for

the call.

2) Perform such activities in the off-peak hours, such as early morning or

late evenings.

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may

cause undesired operation.

Privacy of communications may not be ensured when using this phone.

CAUTION:

Any changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate this

device.

NOTE:

This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following

measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

TGA935(e).fm Page 9 Tuesday, January 15, 2008 7:47 PM

10 For assistance, please visit http://www.panasonic.com/help

FCC RF Exposure Warning:

LThis product complies with FCC radiation exposure limits set forth for

an uncontrolled environment.

LThis handset may not be collocated or operated in conjunction with

any other antenna or transmitter.

LThe handset may be carried and operated with only the specific

provided belt-clip. Other non-tested belt-clips or similar body-worn

accessories may not comply and must be avoided.

Notice

LFCC ID can be found inside the battery compartment or on the bottom

of the unit.

Notice

Lߎߩ⵾ຠߪޔᣣᧄ࿖ᄖߢߩ૶↪ࠍ⋡⊛ߣߒߡ⸳⸘ߐࠇߡ߅ࠅޔᣣᧄ

࿖ౝߢߩ૶↪ߪᴺᓞ㆑෻ߣߥࠅ߹ߔޕᓥߞߡޔᒰ␠ߢߪᣣᧄ࿖ౝߦ

߅޿ߡߪේೣߣߒߡୃℂߥߤߩࠨ࡯ࡆࠬߪ⥌ߒ߆ߨ߹ߔޕ

Lҏ౰ࠢட࣏୽ٺҢՄ೩Ȅӵڏт୽ড়᎛୵ܖٺҢȂџ૖ོႂІ࿋

ӴݲٽȄ

LThis product is designed for use in the United States of America.

Sale or use of this product in other countries may violate local laws.

LCet appareil est conçu pour être utilisé aux États-Unis d’Amérique.

La vente ou l’emploi de cet appareil dans certains autres pays peut

constituer une infraction à la législation locale.

LEste producto está diseñado para usarse en los Estados Unidos de

América.

La venta o el empleo de este producto en ciertos países puede

constituir violación de la legislación local.

TGA935(e).fm Page 10 Tuesday, January 15, 2008 7:47 PM

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Panasonic Cornetta

Panasonic

Panasonic KX-TGA106M - Cordless Extension Handset Manuale utente

Panasonic

Panasonic KX-TGA680C Manuale utente

Panasonic

Panasonic KX-TGA800E Manuale utente

Panasonic

Panasonic KX-TGA510M - 5.8GHz Accessory Handset Manuale utente

Panasonic

Panasonic KX-TGDA50 Manuale utente

Panasonic

Panasonic KX-TGDA30EX Manuale utente

Panasonic

Panasonic KX-TD7685 - Wireless Digital Phone Manuale utente

Panasonic

Panasonic KX-TGP600G Manuale utente

Panasonic

Panasonic KX-TGA648E Manuale utente

Panasonic

Panasonic KX-TG939 Manuale utente

Panasonic

Panasonic KX-TG2559LBS Manuale utente

Panasonic

Panasonic CY-BT100N Manuale utente

Panasonic

Panasonic TGP600 Manuale utente

Panasonic

Panasonic KX-TPA60 Manuale utente

Panasonic

Panasonic KX-PRXA15E Manuale utente

Panasonic

Panasonic KX-TGA560B - Cordless Extension Handset Manuale utente

Panasonic

Panasonic KX-TGA641 Manuale utente

Panasonic

Panasonic KX-PRXA10C Manuale utente

Panasonic

Panasonic KX-TGFA97 Manuale utente

Panasonic

Panasonic KX-TGDA99 Manuale utente

Panasonic

Panasonic KX-TGA520M - Accessory Handset For KX-TG5200M Series Expandable... Manuale utente

Panasonic

Panasonic KX-TGA731E Manuale utente

Panasonic

Panasonic KX-TGA572S Manuale utente

Panasonic

Panasonic KX-TGA270S Manuale utente

Manuali Cornetta popolari di altre marche

Swissvoice

Swissvoice ePure HD Manuale utente

Philips

Philips TD6736/BH051P Manuale utente

ASCOM

ASCOM I62 - Manuale utente

LG-Ericsson

LG-Ericsson LIP-9010 Manuale utente

GE 1583 Manuale utente

iiNet

iiNet Handset Manuale utente

ASCOM

ASCOM 9p23 Manuale utente

AT&T

AT&T DLP70110 Manuale utente

AirCell

AirCell ST 3100 Manuale utente

Eaton

Eaton HHIR-LCD-PROG Istruzioni per il montaggio

Mitel

Mitel 112 Manuale utente

SBC

SBC SBC-381H Manuale utente

Mitel

Mitel 5602 Manuale utente

ASCOM

ASCOM d81 Messenger Istruzioni per l'installazione

SpectraLink

SpectraLink 7522 Manuale utente

Avaya

Avaya L100 Series Come usare

ooma

ooma HD2 Handset Manuale utente

Yealink

Yealink IPW56 Manuale utente
