Installation Manual

Additional Digital Cordless Handset

Model No. KX-TGEA20EX

KX-TGHA20EX

KX-TGEA20

Thank you for purchasing a Panasonic product.

This unit is an additional handset compatible with the following series of

Panasonic Digital Cordless Phone:

- KX-TGE210/KX-TGE220 (KX-TGEA20)

- KX-TGH210/KX-TGH220 (KX-TGHA20)

(The corresponding models are subject to change without notice.)

You must register this handset with your base unit before it can be used.

This installation manual describes only the steps needed to register and

begin using the handset. Please read the base unit’s operating instructions

for further details.

Please read this installation manual before using the unit and save it for

future reference.

KX-TGHA20

Svenska/

Dansk

Français/

Português/

Türkçe

Deutsch/

Suomi/

Italiano

English/

Norsk/

Español

Accessory information

Supplied accessories

Accessory item/Part number Quantity

Charger 1

AC adaptor/PNLV233CE 1

Rechargeable batteries*1 2

Handset cover*2 1

Belt clip (KX-TGEA20) 1

*1 Please read the base unit’s operating instructions for replacement battery

information.

*2 The handset cover comes attached to the handset.

Note:

RPlease read the base unit’s operating instructions for additional/replacement

accessories.

RPanasonic Corporation declares that the radio equipment type (KX-TGEA20/

KX-TGHA20) is in compliance with Directive 2014/53/EU. The full text of the EU

declaration of conformity is available at the following internet address:

http://www.ptc.panasonic.eu/doc

Installation

TGEA_TGHA20EX(en)_0111_ver601.pd2 2 2017/01/11 17:46:21

Setting up

Connections

Connect the AC adaptor plug to the unit until you hear a click.

Connect the AC adaptor to the power outlet.

Note:

RUse only the supplied Panasonic AC adaptor PNLV233CE.

RThe AC adaptor must remain connected at all times. (It is normal for the adaptor

to feel warm during use.)

Battery installation/Battery charging

When the language selection is displayed after installing the batteries for the first

time, you can select your desired language.

MbN: Select your desired language. a MOKN a MN

Important:

RUse the supplied rechargeable batteries. For replacement, we recommend using

the Panasonic rechargeable batteries noted in the base unit’s operating

instructions.

RUSE ONLY rechargeable Ni-MH batteries AAA (R03) size (

RDo NOT use Alkaline/Manganese/Ni-Cd batteries.

RConfirm correct polarities ( , ).

Charge for about 7 hours.

RConfirm “Charging” is displayed (

RWhen the batteries are fully charged, “Fully Charged” is displayed.

Installation

TGEA_TGHA20EX(en)_0111_ver601.pd3 3 2017/01/11 17:46:21

RModel shown is KX-TGHA20.

Note:

RThe handset display may show “Please wait for 1 minute.” when the

handset is placed on the charger if it is not registered to the base unit.

RIf the batteries are fully charged, but the operating time seems to be shorter,

clean the battery ends ( , ) and the charge contacts with a dry cloth and

charge again.

Display language

1MN (right soft key) #110

2MbN: Select your desired language. a MOKN a MN

Registering the handset to the base unit

Ensure that the handset is switched on. If it is not on, press and hold MN for few

seconds to turn the handset on.

1Handset:

Lift the handset and press MN.

2Base unit:

Press and hold MN for about 5 seconds.

RIf all registered handsets start ringing, press MN again to stop, then repeat

this step.

3Handset:

Place the handset on the base unit or charger.

RContinue the operation even when the handset display shows “Please

wait for 1 minute.”.

Installation

TGEA_TGHA20EX(en)_0111_ver601.pd4 4 2017/01/11 17:46:21

4With the handset still on the base unit or charger, wait until a confirmation tone

sounds and is displayed.

Note:

RIf an error tone sounds, or if is displayed, register the handset according to

the base unit’s operating instructions.

For your safety

To prevent severe injury and loss of life/property, read this section carefully before

using the product to ensure proper and safe operation of your product.

WARNING

Power connection

RCompletely insert the AC adaptor/power plug into the power outlet. Failure to do

so may cause electric shock and/or excessive heat resulting in a fire.

RRegularly remove any dust, etc. from the AC adaptor/power plug by pulling it

from the power outlet, then wiping with a dry cloth. Accumulated dust may cause

an insulation defect from moisture, etc. resulting in a fire.

RUnplug the product from power outlets if it emits smoke, an abnormal smell, or

makes an unusual noise. These conditions can cause fire or electric shock.

Confirm that smoke has stopped emitting and contact an authorised service

centre.

Installation

RTo prevent the risk of fire or electrical shock, do not expose the product to rain

or any type of moisture.

RDo not place or use this product near automatically controlled devices such as

automatic doors and fire alarms. Radio waves emitted from this product may

cause such devices to malfunction resulting in an accident.

Operating safeguards

RThe use of excessive sound volume through earphones, headphones, or

headsets may cause hearing loss. (KX-TGEA20)

CAUTION

Installation and location

RThe AC adaptor is used as the main disconnect device. Ensure that the AC

outlet is installed near the product and is easily accessible.

Installation

TGEA_TGHA20EX(en)_0111_ver601.pd5 5 2017/01/11 17:46:21

Battery

RWe recommend using the supplied batteries or additional/replacement batteries

noted in the base unit’s operating instructions for replacement battery

information. USE ONLY rechargeable Ni-MH batteries AAA (R03) size.

RDo not mix old and new batteries.

RDo not open or mutilate the batteries. Released electrolyte from the batteries is

corrosive and may cause burns or injury to the eyes or skin. The electrolyte is

toxic and may be harmful if swallowed.

RExercise care when handling the batteries. Do not allow conductive materials

such as rings, bracelets, or keys to touch the batteries, otherwise a short circuit

may cause the batteries and/or the conductive material to overheat and cause

burns.

RCharge the batteries provided with or identified for use with this product only, in

accordance with the instructions and limitations specified in this manual.

ROnly use a compatible base unit (or charger) to charge the batteries. Do not

tamper with the base unit (or charger). Failure to follow these instructions may

cause the batteries to swell or explode.

Important safety instructions

When using your product, basic safety precautions should always be followed to

reduce the risk of fire, electric shock, and injury to persons, including the following:

1. Do not use this product near water for example, near a bathtub, washbowl,

kitchen sink, or laundry tub, in a wet basement or near a swimming pool.

2. Do not use the telephone to report a gas leak in the vicinity of the leak.

3. Use only the power cord and batteries indicated in this manual. Do not dispose

of batteries in a fire. They may explode. Check with local codes for possible

special disposal instructions.

SAVE THESE INSTRUCTIONS

Other information

ROperating the product near electrical appliances may cause interference. Move

away from the electrical appliances.

CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of

used batteries according to the instructions.

Routine care

RWipe the outer surface of the product with a soft moist cloth.

RDo not use benzine, thinner, or any abrasive powder.

Installation

TGEA_TGHA20EX(en)_0111_ver601.pd6 6 2017/01/11 17:46:21

Notice for product disposal, transfer, or return

RThis product can store your private/confidential information. To protect your

privacy/confidentiality, we recommend that you erase information such as

phonebook or caller list entries from the memory before you dispose of, transfer,

or return the product.

Information for Users on Collection and Disposal of Old Equipment and used

Batteries

123

These symbols (A, B, C) on the products, packaging, and/or accompanying

documents mean that used electrical and electronic products and batteries should

not be mixed with general household waste.

For proper treatment, recovery and recycling of old products and used batteries,

please take them to applicable collection points, in accordance with your national

legislation and the Directives 2002/96/EC and 2006/66/EC.

By disposing of these products and batteries correctly, you will help to save

valuable resources and prevent any potential negative effects on human health

and the environment which could otherwise arise from inappropriate waste

handling.

For more information about collection and recycling of old products and batteries,

please contact your local municipality, your waste disposal service or the point of

sale where you purchased the items.

Penalties may be applicable for incorrect disposal of this waste, in accordance with

national legislation.

For business users in the European Union

If you wish to discard electrical and electronic equipment, please contact your

dealer or supplier for further information.

Information on Disposal in other Countries outside the European Union

These symbols (A, B, C) are only valid in the European Union. If you wish to

discard these items, please contact your local authorities or dealer and ask for the

correct method of disposal.

Installation

TGEA_TGHA20EX(en)_0111_ver601.pd7 7 2017/01/11 17:46:21

Note for the battery symbol

This symbol (B) might be used in combination with a chemical symbol (C). In this

case it complies with the requirement set by the Directive for the chemical involved.

Installation

TGEA_TGHA20EX(en)_0111_ver601.pd8 8 2017/01/11 17:46:21

Installationsanleitung

Zusätzliches DECT Mobilteil

Modellbez. KX-TGEA20EX

KX-TGHA20EX

KX-TGEA20 KX-TGHA20

Vielen Dank, dass Sie sich für den Kauf eines Panasonic-Produkts

entschieden haben.

Dieses Gerät ist ein zusätzliches Mobilteil, das mit den folgenden digitalen Schnurlos-Te-

lefonen von Panasonic kompatibel ist:

- KX-TGE210/KX-TGE220 (KX-TGEA20)

- KX-TGH210/KX-TGH220 (KX-TGHA20)

(Änderungen an den jeweiligen Modellen vorbehalten.)

Bevor dieses Mobilteil verwendet werden kann, müssen Sie es an Ihrer Basisstation re-

gistrieren. Diese Bedienungsanleitung beschreibt nur die Registrierung des Mobilteils und

die ersten Bedienschritte. Weitere Einzelheiten finden Sie in der Bedienungsanleitung der

Basisstation.

Bitte lesen Sie diese Installationsanleitung durch, bevor Sie das Gerät in Betrieb nehmen.

Bewahren Sie diese Installationsanleitung zum späteren Nachschlagen gut auf.

TGEA_TGHA20EX(de-de)_0111ver601.1 1 2017/01/11 12:14:04

Zubehör-Informationen

Mitgeliefertes Zubehör

Zubehör/Teilenummer Menge

Ladeschale 1

Netzteil/PNLV233CE 1

Standardakkus*1 2

Akkufachabdeckung*2 1

Gürtelclip (KX-TGEA20) 1

*1 Weitere Informationen zum Auswechseln der Akkus finden Sie in der

Bedienungsanleitung der Basisstation.

*2 Das Mobilteil wird mit angebrachter Akkufachabdeckung geliefert.

Hinweis:

RWeitere Informationen zu Zubehör- oder Ersatzteilen finden Sie in der

Bedienungsanleitung der Basisstation.

RPanasonic Corporation erklärt, dass der Funkgerätetyp (KX-TGEA20/KX-TGHA20) die

Richtlinie 2014/53/EU erfüllt. Der vollständige Text der EU-Konformitätserklärung steht

unter folgender Internetadresse zur Verfügung:

http://www.ptc.panasonic.eu/doc

Installation

TGEA_TGHA20EX(de-de)_0111ver601.2 2 2017/01/11 12:14:04

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Panasonic Cornetta

Panasonic

Panasonic KX-TPA60 Manuale utente

Panasonic

Panasonic KX-TGA830E Manuale utente

Panasonic

Panasonic KX-TGA600 Manuale utente

Panasonic

Panasonic KX-TGDA20C Manuale utente

Panasonic

Panasonic KXTGA272S - H/S FOR KXTG2700 Manuale utente

Panasonic

Panasonic KX-TPA50 Manuale utente

Panasonic

Panasonic KX-TGA400B - Cordless Extension Handset Manuale utente

Panasonic

Panasonic KXTGA430 - DIGITAL CORDLESS HANDSET-INSTALL Manuale di istruzioni

Panasonic

Panasonic KX-TGA651 Manuale utente

Panasonic

Panasonic TGP 550 Manuale utente

Panasonic

Panasonic KX-TGA560B - Cordless Extension Handset Manuale utente

Panasonic

Panasonic KX-TCA181E Manuale utente

Panasonic

Panasonic KX-PRLA20C Manuale utente

Panasonic

Panasonic KX-TWA50EX Manuale utente

Panasonic

Panasonic KX-TG2700 Manuale utente

Panasonic

Panasonic KXTGA935 - DIGITAL CORDLESS HANDSET INSTALL Manuale di istruzioni

Panasonic

Panasonic KX-TGEA40 Manuale utente

Panasonic

Panasonic KX-TGA740B - Cordless Extension Handset Manuale di istruzioni

Panasonic

Panasonic KX-TGA470 Manuale utente

Panasonic

Panasonic KX-TGEA20E Manuale utente

Panasonic

Panasonic KX-TGA300B - Cordless Extension Handset Manuale utente

Panasonic

Panasonic KX-TGDA50 Manuale utente

Panasonic

Panasonic KX-TGEA40S Manuale utente

Panasonic

Panasonic KX-TGA510M - 5.8GHz Accessory Handset Manuale utente

Manuali Cornetta popolari di altre marche

Swissvoice

Swissvoice ePure HD Manuale utente

Philips

Philips TD6736/BH051P Manuale utente

ASCOM

ASCOM I62 - Manuale utente

LG-Ericsson

LG-Ericsson LIP-9010 Manuale utente

GE 1583 Manuale utente

iiNet

iiNet Handset Manuale utente

ASCOM

ASCOM 9p23 Manuale utente

AT&T

AT&T DLP70110 Manuale utente

AirCell

AirCell ST 3100 Manuale utente

Eaton

Eaton HHIR-LCD-PROG Istruzioni per il montaggio

Mitel

Mitel 112 Manuale utente

SBC

SBC SBC-381H Manuale utente

Mitel

Mitel 5602 Manuale utente

ASCOM

ASCOM d81 Messenger Istruzioni per l'installazione

SpectraLink

SpectraLink 7522 Manuale utente

Avaya

Avaya L100 Series Come usare

ooma

ooma HD2 Handset Manuale utente

Yealink

Yealink IPW56 Manuale utente
