Panasonic KX-NS1000 Manuale utente

Installation Manual

Pure IP-PBX

Model No. KX-NS1000

Thank you for purchasing this Panasonic product.

Please read this manual carefully before using this product and save this manual for future use.

In particular, be sure to read "1.1 For Your Safety (Page 22)" before using this product.

KX-NS1000: PCMPR Software File Version 003.20000 or later

Manuals and supporting information are provided on the Panasonic Web site at:

http://panasonic.net/pcc/support/pbx/

System Components

System Components for KX-NS1000

Category Model No. Description

Main Unit KX-NS1000 Main Unit

Activation Key Codes*1 KX-NSE101 Activation Key for Mobile Extension for 1 User (1

Mobile User)

KX-NSE105 Activation Key for Mobile Extension for 5 Users (5

Mobile Users)

KX-NSE110 Activation Key for Mobile Extension for 10 Users (10

Mobile Users)

KX-NSE120 Activation Key for Mobile Extension for 20 Users (20

Mobile Users)

KX-NSF201 Activation Key for Call Centre Feature Enhancement

(Call Centre Enhance)

KX-NSM005 31-50 IP Phone Capacity (Up to 50 IP Phone)

KX-NSM010 31-100 IP Phone Capacity (Up to 100 IP Phone)

KX-NSM030 31-300 IP Phone Capacity (Up to 300 IP Phone)

KX-NSM099 31-640 IP Phone Capacity (System MAX IP Phone)

KX-NSX910 51-100 IP Phone Capacity (Expansion from NSM005)

KX-NSX930 101-300 IP Phone Capacity (Expansion from

NSM010)

KX-NSX999 301-640 IP Phone Capacity (Expansion from

NSM030)

KX-NSM102 2-Channel IP Trunk Activation Key (2 IP Trunk)

KX-NSM104 4-Channel IP Trunk Activation Key (4 IP Trunk)

KX-NSM108 8-Channel IP Trunk Activation Key (8 IP Trunk)

KX-NSM116 16-Channel IP Trunk Activation Key (16 IP Trunk)

KX-NSM201 1-Channel IP Softphone/IP Proprietary Telephone

Activation Key (1 IPSoftphone/IP PT)

KX-NSM205 5-Channel IP Softphone/IP Proprietary Telephone

Activation Key (5 IPSoftphone/IP PT)

KX-NSM210 10-Channel IP Softphone/IP Proprietary Telephone

Activation Key (10 IPSoftphone/IP PT)

KX-NSM220 20-Channel IP Softphone/IP Proprietary Telephone

Activation Key (20 IPSoftphone/IP PT)

KX-NSM501 1-Channel IP Proprietary Telephone Activation Key (1

IP PT)

KX-NSM505 5-Channel IP Proprietary Telephone Activation Key (5

IP PT)

2 Installation Manual

System Components

Category Model No. Description

KX-NSM510 10-Channel IP Proprietary Telephone Activation Key

(10 IP PT)

KX-NSM520 20-Channel IP Proprietary Telephone Activation Key

(20 IP PT)

KX-NSM701 1-Channel SIP Extension Activation Key (1 SIP

Extension)

KX-NSM705 5-Channel SIP Extension Activation Key (5 SIP

Extension)

KX-NSM710 10-Channel SIP Extension Activation Key (10 SIP

Extension)

KX-NSM720 20-Channel SIP Extension Activation Key (20 SIP

Extension)

KX-NSN001 Activation Key for One-look Network (One-look

Network)

KX-NSN002 Activation Key for QSIG Network (QSIG Network)

KX-NSN101 Built-in Router (Built-in Router AK)

KX-NSN216 16-channel IPsec Activation Key (16ch IPsec AK)

KX-NSP001 Standard Activation Key Package (E-mail/Two-way

Recording) for 1 User (Std. Pkg 1 User)

KX-NSP005 Standard Activation Key Package (E-mail/Two-way

Recording) for 5 Users (Std. Pkg 5 Users)

KX-NSP010 Standard Activation Key Package (E-mail/Two-way

Recording) for 10 Users (Std. Pkg 10 Users)

KX-NSP020 Standard Activation Key Package (E-mail/Two-way

Recording) for 20 Users (Std. Pkg 20 Users)

KX-NSP101 Advanced Activation Key Package (E-mail/Two-way

Recording/Mobile/CA Pro) for 1 User (Adv. Pkg 1

User)

KX-NSP105 Advanced Activation Key Package (E-mail/Two-way

Recording/Mobile/CA Pro) for 5 Users (Adv. Pkg 5

Users)

KX-NSP110 Advanced Activation Key Package (E-mail/Two-way

Recording/Mobile/CA Pro) for 10 Users (Adv. Pkg 10

Users)

KX-NSP120 Advanced Activation Key Package (E-mail/Two-way

Recording/Mobile/CA Pro) for 20 Users (Adv. Pkg 20

Users)

KX-NSP201 Mobile Activation Key Package (E-mail/Mobile) for 1

User (Mobile Pkg 1 User)

KX-NSP205 Mobile Activation Key Package (E-mail/Mobile) for 5

Users (Mobile Pkg 5 Users)

Installation Manual 3

System Components

Category Model No. Description

KX-NSP210 Mobile Activation Key Package (E-mail/Mobile) for 10

Users (Mobile Pkg 10 Users)

KX-NSP220 Mobile Activation Key Package (E-mail/Mobile) for 20

Users (Mobile Pkg 20 Users)

KX-NSU001 Activation Key for Recording Time Expansion (REC

Time Expansion)

KX-NSU002 Activation Key for Two-way Recording Control

(Two-way REC Control)

KX-NSU003 Activation Key for Message Backup (Message

Backup)

KX-NSU102 2-Channel Unified Messaging Activation Key (2 UM

Port)

KX-NSU104 4-Channel Unified Messaging Activation Key (4 UM

Port)

KX-NSU201 Activation Key for Unified Messaging E-mail

Notification for 1 User (UM/E-mail 1 User)

KX-NSU205 Activation Key for Unified Messaging E-mail

Notification for 5 Users (UM/E-mail 5 Users)

KX-NSU210 Activation Key for Unified Messaging E-mail

Notification for 10 Users (UM/E-mail 10 Users)

KX-NSU220 Activation Key for Unified Messaging E-mail

Notification for 20 Users (UM/E-mail 20 Users)

KX-NSU299 Activation Key for Unified Messaging E-mail

Notification for All Users (UM/E-mail All Users)

KX-NSU301 Activation Key for Two-way Recording for 1 User (2way

REC 1 User)

KX-NSU305 Activation Key for Two-way Recording for 5 Users

(2way REC 5 Users)

KX-NSU310 Activation Key for Two-way Recording for 10 Users

(2way REC 10 Users)

KX-NSU320 Activation Key for Two-way Recording for 20 Users

(2way REC 20 Users)

KX-NSU399 Activation Key for Two-way Recording for All Users

(2way REC All Users)

KX-NSA010 Activation Key for CA Thin Client Server Connection

(CA Thin Client)

KX-NSA020 Activation Key for Multiple CSTA Connection (CSTA

Multiplexer)

KX-NSA201 Activation Key for CA PRO for 1 User (CA Pro 1 user)

KX-NSA205 Activation Key for CA PRO for 5 Users (CA Pro 5

users)

4 Installation Manual

System Components

Category Model No. Description

KX-NSA210 Activation Key for CA PRO for 10 Users (CA Pro 10

users)

KX-NSA240 Activation Key for CA PRO for 40 Users (CA Pro 40

users)

KX-NSA249 Activation Key for CA PRO for 128 Users (CA Pro 128

users)

KX-NSA301 Activation Key for CA ACD Monitor for 1 ICD

Supervisor (CA Supervisor)

KX-NSA401 Activation Key for CA Operator Console (CA Console)

KX-NSA901 Activation Key for CA Network Plug-in for 1 User (CA

Network 1 user)

KX-NSA905 Activation Key for CA Network Plug-in for 5 Users (CA

Network 5 users)

KX-NSA910 Activation Key for CA Network Plug-in for 10 Users (CA

Network 10 users)

KX-NSA940 Activation Key for CA Network Plug-in for 40 Users (CA

Network 40 users)

KX-NSA949 Activation Key for CA Network Plug-in for 128 Users

(CA Network 128 users)

KX-NSB0001 Activation Key for Poltys C. Bridge (Poltys C. Bridge)

KX-NSB0002 Activation Key for PSDN Option-1 (PSDN Option-1)

KX-NSB0003 Activation Key for PSDN Option-2 (PSDN Option-2)

KX-NSB0101 Activation Key for Poltys CA RCS-Start for 1 User

(Poltys CA RCS-Start 1 user)

KX-NSB0105 Activation Key for Poltys CA RCS-Start for 5 Users

(Poltys CA RCS-Start 5 users)

KX-NSB0110 Activation Key for Poltys CA RCS-Start for 10 Users

(Poltys CA RCS-Start 10 users)

KX-NSB0149 Activation Key for Poltys CA RCS-Start for 128 Users

(Poltys CA RCS-Start 128 users)

KX-NSB0201 Activation Key for Poltys CA RCS-Extend for 1 User

(Poltys CA RCS-Extend 1 user)

KX-NSB0205 Activation Key for Poltys CA RCS-Extend for 5 Users

(Poltys CA RCS-Extend 5 users)

KX-NSB0210 Activation Key for Poltys CA RCS-Extend for 10

Users (Poltys CA RCS-Extend 10 users)

KX-NSB0249 Activation Key for Poltys CA RCS-Extend for 128

Users (Poltys CA RCS-Extend 128 users)

KX-NSF101 Activation Key for CTI interface (CTI interface)

Physical Cards

Installation Manual 5

System Components

Category Model No. Description

FAX Card Slot KX-NS0106 FAX Interface Card (FAX)

DSP Card Slot KX-NS0110 VoIP DSP Card (S Type) (DSP S)

KX-NS0111 VoIP DSP Card (M Type) (DSP M)

KX-NS0112 VoIP DSP Card (L Type) (DSP L)

Storage Memory

Card Slot

KX-NS0135 Storage Memory (S Type) (Storage Memory S)

KX-NS0136 Storage Memory (M Type) (Storage Memory M)

KX-NS0137 Storage Memory (L Type) (Storage Memory L)

Free Slot KX-NS0180 2-Port Analogue Trunk / 2-Port SLT Card (SLC2/

LCOT2)

KX-NS0280 4-Port BRI / 2-Port SLT Card (SLC2/BRI4)

KX-NS0290CE PRI30 / 2-Port SLT Card (SLC2/PRI30)

KX-NS0290 PRI23 / 2-Port SLT Card (SLC2/PRI23)

KX-NS0130 Stacking Master Card (STACK-M)

Doorphone Slot KX-NS0161 Doorphone Interface Card (DOORPHONE)

*1 Note that the types of activation keys are subject to change without notice. For CA activation keys, refer to the documentation for

CA.

System Components for Legacy Gateways

For details about supported optional service cards and Power Supply Units (PSUs), refer to the Installation

Manual of the corresponding PBX.

KX-NCP500/KX-NCP1000/KX-NS1020

Category Model No. Description

Legacy Gateways KX-NCP500 KX-NCP500 as Legacy Gateway Unit

KX-NCP1000 KX-NCP1000 as Legacy Gateway Unit

KX-NS1020 KX-NS1020 Expansion Cabinet

Legacy Gateway Cards KX-NS0131 Stacking Card for KX-NCP Series (STACK-S (NCP))

Physical Trunk Cards KX-NCP1180 4-Port Analogue Trunk Card (LCOT4)

KX-NCP1187 T-1 Trunk Card (T1)

KX-NCP1188 E-1 Trunk Card (E1)

KX-NCP1280 2-Port BRI Card (BRI2)

KX-NCP1290 PRI Card (PRI23)

KX-NCP1290CE PRI Card (PRI30)

KX-NCP1290CJ PRI Card (PRI30)

6 Installation Manual

System Components

Category Model No. Description

Physical Extension

Cards

KX-NCP1170 4-Port Digital Hybrid Extension Card (DHLC4)

KX-NCP1171 8-Port Digital Extension Card (DLC8)

KX-NCP1172 16-Port Digital Extension Card (DLC16)

KX-NCP1173 8-Port Single Line Telephone Extension Card (SLC8)

KX-NCP1174 16-Port Single Line Telephone Extension Card

(SLC16)

Other Physical Cards KX-NCP1190 Optional 3-Slot Base Card (OPB3)

KX-TDA0161 4-Port Doorphone Card (DPH4)

KX-TDA0162 2-Port Doorphone Card (German Type) (DPH2)

KX-TDA0164 4-Port External Input/Output Card (EIO4)

KX-TDA0166 16-Channel Echo Canceller Card (ECHO16)

KX-TDE100/KX-TDE200/KX-TDA100/KX-TDA200/KX-TDA100D

Category Model No. Description

Legacy Gateways KX-TDE100 KX-TDE100 as Legacy Gateway Unit

KX-TDE200 KX-TDE200 as Legacy Gateway Unit

KX-TDA100 KX-TDA100 as Legacy Gateway Unit

KX-TDA200 KX-TDA200 as Legacy Gateway Unit

KX-TDA100D KX-TDA100D as Legacy Gateway Unit

Legacy Gateway Cards KX-NS0132 Stacking Card for KX-TDE Series (STACK-S (TDE))

Physical Trunk Cards KX-TDA0180 8-Port Analogue Trunk Card (LCOT8)

KX-TDA0181 16-Port Analogue Trunk Card (LCOT16)

KX-TDA0182 8-Port DID Card (DID8)

KX-TDA0183 4-Port Analogue Trunk Card (LCOT4)

KX-TDA0184 8-Port E & M Trunk Card (E&M8)

KX-TDA0187 T-1 Trunk Card (T1)

KX-TDA0188 E-1 Trunk Card (E1)

KX-TDA0284 4-Port BRI Card (BRI4)

KX-TDA0288 8-Port BRI Card (BRI8)

KX-TDA0290CE PRI Card (PRI30)

KX-TDA0290CJ PRI Card (PRI30)

KX-TDA0290 PRI Card (PRI23)

KX-TDA1180 8-Port Analogue Trunk Card with CID (CLCOT8)*1

Installation Manual 7

System Components

Category Model No. Description

Physical Extension Cards KX-TDA0143 4 Cell Station Interface Card (CSIF4)

KX-TDA0144 8 Cell Station Interface Card (CSIF8)

KX-TDA0170 8-Port Digital Hybrid Extension Card (DHLC8)*2

KX-TDA0171 8-Port Digital Extension Card (DLC8)

KX-TDA0172 16-Port Digital Extension Card (DLC16)

KX-TDA0173 8-Port Single Line Telephone Extension Card

(SLC8)*2

KX-TDA0174 16-Port Single Line Telephone Extension Card

(SLC16)*2

KX-TDA0175 16-Port Single Line Telephone Extension with

Message Lamp Card (MSLC16)*2

KX-TDA0177 16-Port Single Line Telephone Extension Card with

Caller ID (CSLC16)*2

KX-TDA1176 16-Port Single Line Telephone Extension with Caller

ID and Message Lamp Card (MCSLC16)*3

KX-TDA1178 24-Port Single Line Telephone Extension with Caller

ID and Message Lamp Card (MCSLC24)*3

Other Physical Cards KX-TDA0161 4-Port Doorphone Card (DPH4)

KX-TDA0162 2-Port Doorphone Card (German Type) (DPH2)

KX-TDA0164 4-Port External Input/Output Card (EIO4)

KX-TDA0166 16-Channel Echo Canceller Card (ECHO16)

KX-TDA0168 Extension Caller ID Card (EXT-CID)

KX-TDA0189 8-Port Caller ID/Pay Tone Card (CID/PAY8)

KX-TDA0190 Optional 3-Slot Base Card (OPB3)

KX-TDA0193 8-Port Caller ID Card (CID8)

KX-TDA1186 8-Port Analogue Trunk Card with CID Daughter Card

(CLCOT8E)*1

PSUs*4 KX-TDA0103 L-Type Power Supply Unit (PSU-L)

KX-TDA0104 M-Type Power Supply Unit (PSU-M)

KX-TDA0108 S-Type Power Supply Unit (PSU-S)

*1 KX-TDA100D only.

*2 Except KX-TDA100D.

*3 Except KX-TDA100/KX-TDA200.

*4 Some PSUs are only supported by certain PBXs. For more details, refer to the Installation Manual of the corresponding PBX.

8 Installation Manual

System Components

KX-TDE600/KX-TDE620/KX-TDA600/KX-TDA620

Category Model No. Description

Legacy Gateways KX-TDE600 KX-TDE600 as Legacy Gateway Unit

KX-TDE620 KX-TDE620 as Legacy Gateway Unit

KX-TDA600 KX-TDA600 as Legacy Gateway Unit

KX-TDA620 KX-TDA620 as Legacy Gateway Unit

Legacy Gateway Cards KX-NS0132 Stacking Card for KX-TDE Series (STACK-S (TDE))

Physical Trunk Cards KX-TDA0182 8-Port DID Card (DID8)

KX-TDA0184 8-Port E & M Trunk Card (E&M8)

KX-TDA0187 T-1 Trunk Card (T1)

KX-TDA0188 E-1 Trunk Card (E1)

KX-TDA0284 4-Port BRI Card (BRI4)

KX-TDA0288 8-Port BRI Card (BRI8)

KX-TDA0290CE PRI Card (PRI30)

KX-TDA0290CJ PRI Card (PRI30)

KX-TDA0290 PRI Card (PRI23)

Physical Extension

Cards

KX-TDA0143 4 Cell Station Interface Card (CSIF4)

KX-TDA0144 8 Cell Station Interface Card (CSIF8)

KX-TDA0170 8-Port Digital Hybrid Extension Card (DHLC8)

KX-TDA0171 8-Port Digital Extension Card (DLC8)

KX-TDA0172 16-Port Digital Extension Card (DLC16)

KX-TDA0173 8-Port Single Line Telephone Extension Card (SLC8)

KX-TDA0177 16-Port Single Line Telephone Extension Card with

Caller ID (CSLC16)

KX-TDA6174 16-Port Single Line Telephone Extension Card

(ESLC16)

KX-TDA6175 16-Port Single Line Telephone Extension with Message

Lamp Card (EMSLC16)

KX-TDA6178 24-Port Single Line Telephone Extension Card with

Caller ID (ECSLC24)

KX-TDA6179 24-Port Single Line Telephone Extension with Caller ID

and Message Lamp Card (EMSLC24)

KX-TDA6381 16-Port Analogue Trunk Card w/o CID (ELCOT16)

KX-TDA6382 16-Port Analogue Trunk Card with CID16 (ELCOT16)

Other Physical Cards KX-TDA0161 4-Port Doorphone Card (DPH4)

KX-TDA0162 2-Port Doorphone Card (German Type) (DPH2)

Installation Manual 9

System Components

Category Model No. Description

KX-TDA0164 4-Port External Input/Output Card (EIO4)

KX-TDA0168 Extension Caller ID Card (EXT-CID)

KX-TDA0189 8-Port Caller ID/Pay Tone Card (CID/PAY8)

KX-TDA0190 Optional 3-Slot Base Card (OPB3)

KX-TDA0193 8-Port Caller ID Card (CID8)

KX-TDA6166 16-Channel Echo Canceller Card (EECHO16)

PSUs KX-TDA0103 L-Type Power Supply Unit (PSU-L)

KX-TDA0104 M-Type Power Supply Unit (PSU-M)

Unsupported System Components for Legacy Gateways

The following components are not supported for legacy gateways.

Model No. Description

KX-NCP1104 4-Channel VoIP DSP Card (DSP4)

KX-TDA0105 Memory Expansion Card (MEC)

KX-TDA0191 4-Channel Message Card (MSG4)

KX-TDA0192 2-Channel Simplified Voice Message Card (ESVM2)

KX-TDA0194 4-Channel Simplified Voice Message Card (ESVM4)

KX-TDA0196 Remote Card (RMT)

KX-TDA0410 CTI Link Card (CTI-LINK)

KX-TDA0470 16-Channel VoIP Extension Card (IP-EXT16)

KX-TDA0480 4-Channel VoIP Gateway Card (IP-GW4)

KX-TDA0484 4-Channel VoIP Gateway Card (IP-GW4E)

KX-TDA0490 16-Channel VoIP Gateway Card (IP-GW16)

KX-TDE0105 Memory Expansion Card (IPCMEC)

KX-TDE0110 16-Channel VoIP DSP Card (DSP16)

KX-TDE0111 64-Channel VoIP DSP Card (DSP64)

Equipment Compatibility for KX-NS1000

The PBX supports the following equipment:

Cell Stations

DECT

•DECT 8-Channel IP Cell Station Unit Using a V-IPCS4 Card for DECT Portable Station

(KX-NCP0158CE)

DECT 6.0

•DECT 6.0 8-Channel IP Cell Station Unit Using a V-IPCS4 Card for DECT 6.0 Portable Station

(KX-NCP0158)

10 Installation Manual

System Components

Altri manuali per KX-NS1000

Indice

Altri manuali Panasonic Centralino

Panasonic

Panasonic KX-TA824 Manuale utente

Panasonic

Panasonic KX-TDA50 Manuale utente

Panasonic

Panasonic KX- TAW848 Scheda tecnica

Panasonic

Panasonic KX-TD500 Manuale utente

Panasonic

Panasonic KX-TD500 Manuale utente

Panasonic

Panasonic KX-T7625 - Digital Proprietary Speakerphone 24... Manuale utente

Panasonic

Panasonic KX-TD1232CE Istruzioni per l'installazione e il funzionamento

Panasonic

Panasonic KX-TDA100D Manuale utente

Panasonic

Panasonic KX-NS700 Manuale del proprietario

Panasonic

Panasonic KX-TD1232 Guida alla risoluzione dei problemi

Panasonic

Panasonic KX-NCP500 Manuale del proprietario

Panasonic

Panasonic KX-TDA600 - Hybrid IP PBX Control Unit Max. 1008... Manuale utente

Panasonic

Panasonic KX-TDA100D Manuale utente

Panasonic

Panasonic KX-NS700 Manuale utente

Panasonic

Panasonic KX-TDA15 Manuale del proprietario

Panasonic

Panasonic KX-NS Series Manuale utente

Panasonic

Panasonic KX-TDE200 Manuale utente

Panasonic

Panasonic KX-NS500 Manuale del proprietario

Panasonic

Panasonic KX-NCP500 Istruzioni per il montaggio

Panasonic

Panasonic KX-NS700 Manuale del proprietario

Panasonic

Panasonic KX-TDA50 Scheda tecnica

Panasonic

Panasonic KX-TVM200AL Manuale utente

Panasonic

Panasonic HYBRID IP-PBX KX-TDA200 Manuale utente

Panasonic

Panasonic KX-TDE100 Manuale utente

Manuali Centralino popolari di altre marche

Allo.com

Allo.com Nano 2 Manuale utente

ZYCOD

ZYCOD ZX50 Manuale utente

LV switch

LV switch IPPBX800 Manuale di istruzioni

Edge-Core

Edge-Core VST3305 Manuale utente

Rauland-Borg

Rauland-Borg Telecenter IV Manuale utente

Grandstream Networks

Grandstream Networks UCM6208 Manuale utente

ATCOM

ATCOM IPPBX IP02 Manuale utente

bintec elmeg

bintec elmeg elmeg hybird 600 Manuale utente

MCK

MCK EXTender PBXgateway Manuale utente

NEC

NEC SL1000 Manuale utente

Epygi

Epygi Quadro Quadro 2xi Manuale utente

SMC Networks

SMC Networks TigerVoIP SMCPBX10 Manuale utente

AGFEO

AGFEO AC 14 analog Manuale utente

Nortel

Nortel QSY22 Manuale utente

Epygi

Epygi Quadro Quadro 4xa Manuale utente

Samsung

Samsung NX-308 Manuale utente

SpectraLink

SpectraLink Link 3000 Manuale

Allo.com

Allo.com Nano 2 Manuale utente
