PASCO PS-3217 Guida
PASCO Form Number Description Date Revision
013-17357 PS-3217 Battery Replacement Instructions 05-05-22 Page 1 of 3 A
PS‐3217;WirelessO2SensorBatteryReplacementInstructions
Reference:Batterypartnumber540‐113;Li‐Poly1000mAH
RecommendedEquipment:(PS‐3299;BatteryReplacementToolSet)
Step1:PositiontheSensoronasurfaceasshown.Notethelocationofthe(4)TorxT5
Screws.Removethe4screwswiththeTorxT5Screwdriver.
Caution:Eachscrewhasasmallplasticwasher.Pleasemakesurethewashersdonotcomeoff
thescrews.
PASCO Form Number Description Date Revision
013-17357 PS-3217 Battery Replacement Instructions 05-05-22 Page 2 of 3 A
Step2:Rotatethebackcoverasshown.
Step3RemovethebatteryholddowncoverbyremovingthetwoscrewswiththeTorxT5
Screwdriver.Unplugthebatteryconnector.Seebelow.
Step4:Replacetheoldbatterywiththereplacementbatteryandreversetheotherstepsto
reassembletheunit.
PASCO Form Number Description Date Revision
013-17357 PS-3217 Battery Replacement Instructions 05-05-22 Page 3 of 3 A
Step5:Completethereassemblyanddisposeoftheoldbatteryproperlypertheinstructions.
Ifyouneedfurtherassistance,pleasecontactTechnicalSupportat[email protected]or
throughwww.pasco.comonchat.Toaccesschatthroughyourbrowser,pleaseenableall
cookiesonourwebsite.
