Peerless-AV ACC-V1500X Manuale utente

12022-03-07 #:120-9246-1

ENG

ACC-V1500X

For VESA 1200 and 1500 Mounting Patterns

200 lb

(91 kg)

MAX

22022-03-07 #:120-9246-1

ENG - Before installing make sure the supporting surface will support the combined load of the equipment and

hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.

Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to safely lift

and position equipment. This product is intended for indoor use only. Use of this product outdoors could lead to



call customer care at 1-800-865-2112.

WARNING

Symbols

ENG

WARNING

ENG

Screws must get at

least three full turns



ENG 1

ENG To properly tighten screws: Tighten until screw

head makes contact, then tighten another 1/2

turn. Do not overtighten screws.

+1/2

Skip to step.

ENG

32022-03-07 #:120-9246-1

Parts List

Part #Description Qty

Aadaptor rail 2 10009122RBLK

BM8 x 15mm 4 520-1068

C4mm allen wrench 1 560-9646

DM8 x 20mm 4 520-1120

Etube cap 4 590-1334

C(1)

4mm allen

wrench

A (2)

adaptor rail

E (4)

tube cap

Parts (Before beginning, make sure you have all parts shown below).

ENG

B(4)

M8 x 15mm D(4)

M8 x 20mm

42022-03-07 #:120-9246-1

A(2)

E(4)

VESA 1200mm

VESA 1500mm

52022-03-07 #:120-9246-1

D(4)

A(2)

2b C

D(4)

A(2)

62022-03-07 #:120-9246-1

M6/M8 washer



B(4)

 DS-VW795-QR

SR598

72022-03-07 #:120-9246-1

B(4)

Peerless-AV Europe

Unit 3 Watford Interchange,

Colonial Way, Watford, Herts,

WD24 4WP, United Kingdom

Customer Care

44 (0) 1923 200 100

www.peerless-av.com

Peerless-AV América Latina

Av. de las Industrias 413

Parque Industrial Escobedo

General Escobedo N.L., México 66062

Servicio al Cliente

01-800-849-65-77

www.peerless-av.com

Peerless-AV

2300 White Oak Circle

Aurora, IL 60502

Email: [email protected]

Ph: (800) 865-2112



www.peerless-av.com

www.peerless-av.com/warranty

Warranty Garantía Garantie Garantie Garantie

Garanzia Záruka Záruka Garantia 

ENG ESP  DEU NEL

ITL  SLK POR TÜR
