Pelgrim PKS34140 Manuale utente

Instructions for use

Built-in refrigerator

PKS24088

PKS24102

PKS24122

PKD23102

PKS24140

PKS34088

PKS34102

PKS34122

PKS34140

PKD34140

715469

We thank you for the confidence you have shown by purchasing

our appliance which is designed to simplify your life. To make the use of the

product easier, we have supplied detailed instructions for use, and installation

instructions supplied on a separate sheet. The instructions should allow you to

learn about your new appliance as quickly as possible.

We wish you find a lot of pleasure in its use.

The appliance is intended solely for household use.

The refrigerator is intended for storing fresh food at temperatures above 0°C.

Please visit our website where you can enter your appliance model number,

indicated on the rating plate or the warranty sheet, to find detailed description

of your appliance, tips on use, troubleshooting, service information, instructions

for use etc.

www.pelgrim.nl

Important safety warning

General information and tips

Protecting the environment

Do not wash in the dishwasher

Link to the EU EPREL database

The QR code on the energy label supplied with the appliance provides a web

link to the registration of this appliance in the EU EPREL database. Keep

the energy label for reference together with the user manual and all other

documents provided with this appliance.

It is possible to find information related to the performance of the product

in the EU EPREL database using the link https://eprel.ec.europa.eu and the

model name and product number that you can find on the rating plate of the

appliance.

For more detailed information about the energy label, visit www.theenergylabel.eu.

CONTENTS

715469

INTRODUCTION

APPLIANCE

DESCRIPTION

DEFROSTING

AND CLEANING

THE APPLIANCE

4 IMPORTANT NOTES AND PRECAUTIONS

4 BEFORE USING THE APPLIANCE FOR THE FIRST TIME

5 IMPORTANT SAFETY INSTRUCTIONS

8 IMPORTANT INFORMATION ON THE USE OF APPLIANCE

9 ENVIRONMENT PROTECTION

10 ADVICE FOR SAVING ENERGY WITH REFRIGERATION

APPLIANCES

11 INSTALLATION AND CONNECTION

13 APPLIANCE DESCRIPTION

15 OPERATING THE APPLIANCE

17 APPLIANCE INTERIOR EQUIPMENT

20 STORING FOOD

22 DEFROSTING THE APPLIANCE

23 CLEANING THE APPLIANCE

24 TROUBLESHOOTING MISCELLANEOUS

STORING FOOD

IMPORTANT NOTES AND

PRECAUTIONS

Before connecting the appliance to the power mains,

please read carefully the instructions for use which

describe the appliance and its correct and safe use.

The instructions apply to several appliance types/

models; thus, settings or equipment may be described

herein which is not available in your appliance. We

recommend saving this instruction manual for future

reference and attach it to the appliance if it is sold in

the future.

Check for any damage or irregularities on your

appliance. If you find your appliance is damaged,

notify the retailer from which you have purchased the

appliance.

Before connecting the appliance to the power mains,

let the appliance rest in a vertical position for a

minimum of 2 hours. This will reduce the possibility of

operation faults due to the effect of transport on the

cooling system.

715469

BEFORE USING THE APPLIANCE FOR

THE FIRST TIME

715469

IMPORTANT SAFETY INSTRUCTIONS

The appliance must be connected to the power

mains and grounded in compliance with the effective

standards and regulations.

WARNING! Do not locate multiple portable socket-

outlets or portable power supplies at the rear of the

appliance.

Before cleaning the appliance, unplug it from the

power mains (unplug the power cord from the wall

outlet).

WARNING! If the supply cord is damaged, it must be

replaced by the manufacturer, its service agent or

similarly qualified persons in order to avoid a hazard.

WARNING! When positioning the appliance, ensure the

supply cord is not trapped or damaged.

If LED lighting does not work, call a service technician.

Do not attempt a repair of the LED lighting yourself, as

there is danger of contact with high voltage!

WARNING! Do not use any electric devices inside

the appliance, except for those allowed by the

manufacturer of this refrigeration appliance.

WARNING! Do not use mechanical devices or other

means to accelerate the defrosting process, other

than those recommended by the manufacturer.

WARNING! To avoid any hazard resulting from poor

stability of the appliance, make sure it is installed as

instructed.

WARNING! Risk of fire/flammable materials.

715469

Danger of frostbite

Never put frozen food in your mouth and avoid

touching frozen food as this may cause frostnip or

frostbite.

Safety of children and vulnerable persons

The appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person

responsible for their safety.

Children should be supervised to ensure that they do

not play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

Remove the packaging intended to protect the

appliance or particular parts during transport and keep

it outside the reach of children.

It presents danger of injury or suffocation.

When removing a used appliance, disconnect the

power cord, remove the door, and leave the shelves in

the appliance. This will prevent children from locking

themselves in the appliance.

For European markets only

This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

715469

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

Children aged from 3 to 8 years are allowed to load

and unload refrigerating appliances.

Warning regarding the refrigerant

The appliance contains a small amount of an

environmentally friendly yet flammable gas R600a.

Make sure that no parts of the cooling system

are damaged. A gas leak is not hazardous to the

environment, but it could cause eye injury or fire.

In case of a gas leak, ventilate the room thoroughly,

disconnect the appliance from the power mains, and

call a service technician.

715469

The appliance may not be used outdoors and it may

not be exposed to rain.

Do not store explosive substances such as aerosol cans

with a flammable propellant in this appliance.

If the appliance will be out of use for an extended

period of time, switch it off using the relevant button,

and unplug it from the power mains. Empty the

appliance, defrost it, clean it, and leave the door ajar.

In the event of a defect or power cut, do not open the

freezer compartment unless the appliance has been

out of operation for more than the hours indicated

on the appliance’s type plate (temperature rise time).

After this time, you must either use the frozen food or

make sure that it is properly cooled (for example, by

transferring it to another appliance).

WARNING! Keep ventilation openings, in the

appliance enclosure or in the built-in structure, clear

of obstruction.

IMPORTANT INFORMATION ON THE USE

OF APPLIANCE

WARNING! This appliance is intended to be used in

household and similar applications such as

– staff kitchen areas in shops, offices and other working

environments;

– farm houses and by clients in hotels, motels and other

residential type environments;

– bed and breakfast type environments;

– catering and similar non-retail applications.

715469

The symbol on the product or its packaging indicates that the product

should not be treated as normal household waste. The product should be

taken to an authorized collection centre for waste electric and electronic

equipment processing. Correct disposal of the product will help prevent

any negative effects on the environment and health of people which could

occur in case of incorrect product removal. For detailed information on

removal and processing of the product, please contact the relevant municipal

body in charge of waste management, your waste disposal service, or the

store where you bought the product.

Packaging is made of environmentally friendly materials

that can be recycled, disposed of, or destroyed without

any hazard to the environment.

!Removing an obsolete appliance

To protect the environment, take the obsolete

appliance to an authorized home appliance collection

centre.

Before doing so, do the following:

• disconnect the appliance from the power mains;

• do not allow children to play with the appliance.

ENVIRONMENT PROTECTION

WARNING! Do not damage the refrigerant circuit.

This will also prevent pollution.

Technical information on the appliance

Rating plate can be found in the

appliance interior (see figure). It indicates

data on voltage, gross and net volume,

type and amount of refrigerant, and

information on the climate classes.

ADVICE FOR SAVING ENERGY

WITH REFRIGERATION

APPLIANCES

715469

• Install the appliance as specified in the instruction manual.

• Do not open the door more often than necessary.

• Occasionally make sure air circulation underneath the appliance is

unobstructed.

• If the gasket is damaged or does not provide a perfect seal for any reason,

have it replaced as soon as possible.

• Store the food in tightly sealed containers or appropriate packaging.

• Before placing the food in the refrigerator, allow it to cool down to room

temperature.

• Defrost frozen food in the refrigerator compartment.

• Make sure the layout of shelves in the compartment is uniform and that

the food is placed so that the air can freely circulate in the appliance

interior (observe the recommended placement of food as described in the

instructions).

• The lower the temperature is set the higher the energy consumption will be.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Pelgrim Frigorifero

Pelgrim

Pelgrim KK2174A Manuale utente

Pelgrim

Pelgrim PKO3082 Manuale utente

Pelgrim

Pelgrim PKS5178 Manuale utente

Pelgrim

Pelgrim KCS3178 Manuale utente

Pelgrim

Pelgrim PKVO3082 Manuale utente

Pelgrim

Pelgrim OKG260 Manuale utente

Pelgrim

Pelgrim PKS4178K Manuale utente

Pelgrim

Pelgrim PCS22178L Manuale utente

Pelgrim

Pelgrim KK2178V Manuale utente

Pelgrim

Pelgrim PKS 3122F/P01 Manuale utente

Pelgrim

Pelgrim PKS24102 Manuale utente

Pelgrim

Pelgrim PCS3178L Manuale utente

Pelgrim

Pelgrim PKS34088 Manuale utente

Pelgrim

Pelgrim PKS35178 Manuale utente

Pelgrim

Pelgrim PKV188 Manuale utente

Pelgrim

Pelgrim PCS2178 Manuale utente

Pelgrim

Pelgrim PCD5178N Manuale utente

Pelgrim

Pelgrim PCD23178L Manuale utente

Pelgrim

Pelgrim PKV154 Manuale utente

Pelgrim

Pelgrim PKS 3178F/P01 Manuale utente

Pelgrim

Pelgrim KB 7170 Manuale utente

Pelgrim

Pelgrim PKS27088 Manuale utente

Pelgrim

Pelgrim PKS14088 Manuale utente

Pelgrim

Pelgrim KK2088K Manuale utente

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Samsung

Samsung RF323TE Manuale utente

Beko

Beko CSA31022 Manuale utente

IKEA

IKEA FROSTIG C 185 E Manuale utente

Electrolux

Electrolux ER 6821 D Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente
