Pelgrim PKV155 Manuale utente

Manual

fridge with freezer compartment

PKV155

569055

We thank you for the

confidence you have shown by

purchasing our appliance.

We wish you find a lot of pleasure in its

use.

The appliance is intended solely for

household use.

The refrigerator-freezer is intended for

use in households.

The lower part is the refrigerator

compartment intended for storing fresh

food at temperatures above 0°C.

The upper part is the freezer

compartment intended for freezing fresh

food and long-term storage

of frozen food (up to one year, depending

on the type of food). This compartment is

labeled with four stars / asterisks.

TABLE OF CONTENTS

569055

INTRODUCTION

APPLIANCE

DESCRIPTION

DEFROSTING

AND CLEANING

THE APPLIANCE

OTHER

STORING AND

FREEZING FOOD

4 IMPORTANT NOTES AND WARNINGS

8 ADVICE FOR SAVING POWER WITH REFRIGERATION

APPLIANCES

9 APPLIANCE DESCRIPTION

10 INSTALLATION AND CONNECTION

12 CHANGING THE DIRECTION OF DOOR OPENING

15 OPERATING THE APPLIANCE

17 APPLIANCE INTERIOR EQUIPMENT

21 RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE

22 STORING FOOD IN THE REFRIGERATOR

23 STORING FOOD IN THE FRESHZONE DRAWER

24 FREEZING AND STORING FROZEN FOOD

24 Freezing process

25 Important warnings on freezing fresh food

25 Storage of industrially frozen food

26 Frozen food storage time

26 Defrosting frozen food

27 DEFROSTING THE APPLIANCE

28 CLEANING THE APPLIANCE

29 TROUBLESHOOTING

30 INFORMATION ABOUT APPLIANCE NOISE

IMPORTANT

NOTES AND WARNINGS

569055

This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or metal capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

Before connecting the appliance to the power mains,

please read carefully the instructions for use which

describe the appliance and its correct and safe use. The

instructions apply for several appliance types/models;

thus, settings or equipment may be described herein

which is not available in your appliance.

Remove the packaging intended for protecting the

appliance or particular parts during transport.

Spacers are fitted on the

corners of the doors.

Remove them and insert

the supplied plugs into

their slots (only in some

models).

569055

Before connecting the appliance to the power

mains, let the appliance rest in a vertical position for

approximately 2 hours. This will reduce the possibility

of operation faults due to the effect of transport on the

cooling system.

The appliance must be connected to the power

mains and grounded in compliance with the effective

standards and regulations.

The appliance may not be used outdoors and it may

not be exposed to rain.

Do not store explosive substances such as aerosol cans

with a flammable propellant in this appliance.

Before cleaning the appliance, unplug the appliance

from the power mains (unplug the power cord from the

wall outlet).

If the power cord is damaged, it must be replaced by a

service technician or other adequately trained person.

If the appliance will be out of use for a prolonged

period of time, switch it off using the relevant button,

and unplug the appliance from the power mains. Empty

the appliance, defrost it, clean it, and leave the door

ajar.

If LED lighting does not work, call a service technician.

Do not attempt a repair of the LED lighting yourself, as

there is danger of contact with high voltage!

569055

To protect the environment, take the obsolete

appliance to an authorized home appliance collection

center.

Packaging is made of environmentally friendly materials

that can be recycled, disposed of, or destroyed without

any hazard to the environment.

Rating plate can be found in the appliance interior. If

the language on the rating plate is not the language of

your choice or the language of your country, replace it

with the one supplied.

WARNING! Keep ventilation openings, in the

appliance enclosure or in the built-in structure, clear of

obstruction.

WARNING! Do not use mechanical devices or other

means to accelerate the defrosting process, other than

those recommended by the manufacturer.

WARNING! Do not damage the refrigerant circuit.

WARNING! Do not use electrical appliances inside

the food storage compartments of the appliance,

unless they are of the type recommended by the

manufacturer.

569055

The symbol on the product or its packaging indicates that the product should not

be treated as normal household waste. The product should be taken to an

authorized collection center for waste electric and electronic equipment

processing. Correct disposal of the product will help prevent any negative effects

on the environment and health of people which could occur in case of incorrect product

removal. For detailed information on removal and processing of the product, please

contact the relevant municipal body in charge of waste management, your waste

disposal service, or the store where you bought the product.

ADVICE FOR SAVING POWER

WITH REFRIGERATION

APPLIANCES

569055

• Install the appliance as speciﬁed in the instruction manual.

• Do not open the door more often than necessary.

• Occasionally make sure air circulation underneath the appliance is unobstructed.

• Condenser unit on the rear wall should be kept clean (see chapter Cleaning the

appliance).

• If the gasket is damaged or does not provide a perfect seal for other reasons, have it

replaced as soon as possible.

• Store the food in tightly sealed containers or appropriate packaging.

• Before placing the food in the appliance, cool it to room temperature.

• Defrost frozen food in the refrigerator compartment.

• Remove some of the drawers from the freezer compartment as described in the

instruction manual, in order to make use of the entire interior.

• Defrost your conventional freezer when an approximately 3-5 milimeter layer of of frost

or ice has built up on the refrigerated surfaces.

• Make sure the layout of shelves in the compartment is uniform and that the food

is placed so that the air can freely circulate in the appliance interior (observe the

recommended placement of food as described in the instructions).

• In appliances with a fan, do not block the fan slots.

• If you do not need the fan or the ionizer, switch them o to reduce power consumption.

APPLIANCE DESCRIPTION

569055

• Appliance interior equipment may change according to the appliance model.

• The drawers are protected against pulling out. To remove a drawer from the appliance,

pull it out as far as it will go, then lift at the front and pull out completely.

A Refrigerator compartment

B Freezer compartment

1 Control unit

2 Fan with air ionizer (+ on/off

switch)

3 LED lighting of refrigerator

interior

4 Pull-out glass shelf

(heightadjustable)

5 Water discharge gutter /

groove

6 CrispZone fruit and

vegetables drawer with

humidity control

7 Height-adjustable door bin

8 Bottle shelf

INSTALLATION AND CONNECTION

569055

SELECTING THE ROOM

• Install the appliance in a dry and well ventilated room. The appliance will operate correctly

if the environment temperature is in the interval speciﬁed in the table. The appliance class is

indicated on the rating plate / label with the basic information on the appliance.

Class Temperature

SN (subnormal) from +10°C to +32°C

N (normal) from +16°C to +32°C

ST (subtropical) from +16°C to +38°C

T (tropical) from +16°C to +43°C

Warning: Make sure the room where the appliance is installed is large enough. There

should be at least 1 m3of space per 8 grams of refrigerant. Amount of refrigerant is stated

on the rating plate in the appliance interior.

INSTALLING THE APPLIANCE

Appliance installation should be carried

out by at least two persons to avoid any

physical injury or damage to the appliance.

• The appliance must stand level or tilted

slightly to the back, stable on a solid

base. At the front, the appliance is ﬁtted

with two adjustable legs that can be used

to level the appliance. At the rear side,

casters allow for easier installation of the

appliance (only with some models).

• There should be a clearance of at least 5 cm

between the appliance and any cupboard

installed above it, in order to allow adequate

cooling of the condenser unit.

• The appliance is supplied with two

spacers which should be installed on

the lower part of the housing to prevent

from pushing the appliance too close to

the wall. Appliance may also be installed

without the spacers; however, this may

increase power consumption.

max

30 mm

> 90°
