Pentax Optio 50 - Optio 50 5MP Digital Camera Manuale utente
1
Front View
Name Description
Self-timer LED Blinks blue during Self-timer mode until picture is
taken.
Viewfinder Allows you to frame the subject of the picture.
Flash Provides flash illumination.
Shutter release
button
Focuses and locks the exposure of the camera
when pressed halfway down, and takes the picture
when pressed all the way down.
Lens 3x optical zoom lens allows you to take telephoto
and wide-angle pictures.
Power button Turns the camera power on and off.
Mode dial Sets the camera mode.
DC input terminal Allows you to connect AC power adapter to the
camera to operate the camera without battery.
PC/AV terminal Allows you to connect a USB cable or an AV cable to
the camera.
Microphone Allows you to record sound with the recorded movie
clips.
Shutter release button
Self-timer LED
Power button
Mode dial
Flash
Viewfinder
Lens
PC/AV terminal
DC input terminal
Microphone
This
Quick Start Guide
is only for quick reference. For more details
on advanced functions, you can refer to your Operating Manual.
GETTING TO KNOW YOUR CAMERA
2
Rear View
Name Description
Viewfinder Allows you to frame the subject of the picture.
Viewfinder LED Displays the camera current state.
/ button Zooms the lens to telephoto position.
During zoom playback, it changes the size of the
Zoom Display image displayed on the LCD monitor.
/ button Zooms the lens to wide-angle position.
Changes the display into nine images (thumbnail) in
the playback mode.
button Switches to Playback mode. The latest image and
information appear on the LCD monitor.
MENU button Toggles OSD menu on and off.
/DISPLAY
button
Confirms the menu item selection.
Turns the LCD monitor display and live view on and
off.
Strap holder Camera strap attachment.
button Allows you to erase the picture.
Tripod socket Allows tripod mounting.
Viewfinder
MENU button
button
button
OK/DISPLAY button
Four - way controller
Battery/Card cover
Tripod socket
Strap holder
Viewfinder LED
LCD monitor
Zoom/ / / / button
3
Mode Dial
Battery/Card cover Allows you to access to the battery and insert or
remove the memory card.
LCD monitor Provides menu information to operate the camera,
and previews the picture before taking it and review
it afterwards.
Four-way
controller
Allows you to scroll through menus and pictures,
and then select choices.
(W)- Selects the flash mode in Capture mode.
(X)- Selects the self-timer mode in Capture mode.
Mode Dial
Name Description
Simple Lets the camera set the functions
automatically.
Program The basic picture-taking mode.
Portrait Lets you take portrait-type pictures.
Landscape Lets you take landscape views.
Sport Lets you take sport pictures.
Night-scene Lets you take dark scenes such as night
views.
Setup Lets you select the camera preferences.
Moving Picture(Movie) Lets you take moving pictures.
Mode dial
4
Attaching the Camera Strap
Attach the camera strap as shown
in the illustration.
1. Open the battery/card cover.
2. Insert the battery in the
correct orientation as shown
on the right.
3. Close the battery/card cover.
Attaching the Camera Strap
Inserting the Battery
• You can use 2 AA size batteries (alkaline or Ni-MH rechargeable)
to power the camera.
2
1
2
1
1
2
GETTING STARTED
5
1. Open the battery/card cover.
2. Insert the SD memory card in the
correct orientation as shown on the
right.
Hold the SD memory card with its
metal contact end surface facing the
rear side of the camera, and then
insert the card as far as it can go.
3. Close the battery/card cover.
Press the button to turn the power on.
The viewfinder LED lights green and the camera is ready to take
pictures.
Inserting the SD Memory Card (Optional Accessory)
Turning the Power On
Power button
6
Choosing the OSD (On-Screen Display) Language
1. Set the mode dial to .
2. Use the four-way controller (X) to
select [Set-up2] menu.
[Set-up2] of the set-up menu is
displayed.
3. Use the four-way controller (T) to
select [Language] and press the
button.
4. Use the four-way controller (ST)
to select the language.
5. Press the button to confirm the
language selection.
Choosing the OSD (On-Screen Display) Language
Set-up 1 Set-up 2
OK : 3 / 5
Date Adjust
Video Out
Language
Brightness
PAL
English
y/m/d
Language
OK : 1 / 8
7
1. Set the mode dial to and use
the four-way controller (X) to select
[Set-up2] menu.
[Set-up2] of the set-up menu is
displayed.
2. Select [Date Adjust] with the four-
way controller (T).
3. Use the four-way controller (WX)
to select the date type.
4. Press the button.
The Date Adjust screen appears.
5. Use the four-way controller (WX)
to select itemís field and adjust the
value for the date and time with the
four-way controller (ST).
6. After confirming all settings are
correct, press the button.
Setting the Date and Time
Set-up1 Set-up2
OK : 1 / 5
Date Adjust
Video Out
Language
Brightness
PAL
English
d/m/y
Date Adjust
0 2 / 0 1 / 2 0 1 0
0 4 : 0 0
OK : Select :
8
1. Press the
button to turn on the camera.
2. Set the mode dial to .
3. Compose your image in the LCD monitor or through the viewfinder.
4. Press the shutter release button halfway down to automatically focus
the image. Proper exposure is determined and locked at the same
time.
5. Press the shutter release button down fully to take the pictures.
1. Press the button.
The last image appears on the screen.
2. Use the four-way controller (WX) to view the pictures.
Four-way controller (W): go back to the previous image.
Four-way controller (X): advance to the next image.
Taking Still Pictures
Playing Back Still Pictures
Power button
OK/DISPLAY button
Shutter release button
Viewfinder
LCD monitor
Zoom / / / button
Mode dial
Power button
Playback button
Four - way controller
LCD monitor
9
This mode allows you to record movie clips with sound via built-in
microphone.
1. Rotate the mode dial to and turn
your camera on by pressing the
button.
2. Press the shutter button to
start
recording.
3. To stop recording, press the shutter
button again.
You can play back the recorded movie clips on the LCD monitor.
However, the sound recorded with movie clips can only be played back
on TV or computers.
1. Press the button.
2. Use the four-way controller (WX)
to go through the images until the
movie clip you want to play back
is displayed.
To view the previous image,
press the four-way controller
(W).
To view the next image, press
the four-way controller (X).
3. Press the button to start
playing back the movie clips.
To pause or resume movie
playback, press the button
again.
<
<Erasing Images
Recording Movie Clips
Playing Back Movie Clips
1
100-0001
Size 320X240
EV 0.0
01.04. ’04 05:22
1
10
1. Press the
button.
The last image will be displayed on the screen.
2. Select the image you want to erase with the four-way controller
(WX).
3. Press the button.
4. Use the four-way controller (ST) to
select [OK].
5. Press the button to confirm the
deletion.
Erasing Images
3
OK
Cancel
OK :
Delete
