Vibration Limit Switch LVL-M4

Contents

2022-08

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Content of this Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.2 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.3 Symbols Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.4 Registered Trademarks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2 Basic Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.1 Requirements for Personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.2 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.3 Workplace Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.4 Operational Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.5 Product Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.6 Functional Safety SIL (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.7 IT Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3 Incoming Acceptance and Product Identification . . . . . . . . . . . . . . . . . . . . . . . 11

3.1 Incoming Acceptance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3.2 Product Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3.3 Storage and Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4 Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.1 Mounting Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4.2 Mounting the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.3 Sliding Sleeves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.4 Post-Mounting Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

5 Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

5.1 Connection Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

5.2 Connecting the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5.3 Post-Connection Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

6 Operation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

6.1 Overview of Operation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

2022-08

Vibration Limit Switch LVL-M4

Contents

7 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

7.1 Function Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

7.2 Functional Test Using the Button on the Electronic Insert . . . . . . . . . . 36

7.3 Functional Test of the Electronic Switch with a Test Magnet . . . . . . . . 37

7.4 Switching on the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

7.5 Establishing a Connection via P+F Level App . . . . . . . . . . . . . . . . . . . . 37

7.6 Further Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Vibration Limit Switch LVL-M4

Introduction

2022-08

1 Introduction

1.1 Content of this Document

This document contains information that you need in order to use your product throughout

the applicable stages of the product life cycle. These can include the following:

•Product identification

•Delivery, transport, and storage

•Mounting and installation

•Commissioning and operation

•Maintenance and repair

•Troubleshooting

•Dismounting

•Disposal

The documentation consists of the following parts:

•Datasheet – product overview

The datasheet contains the essential technical data for product selection.

•Technical information (TI) – planning aid

The document contains all the technical data on the device and provides an overview

of the accessories and other products that can be ordered for the device.

•Manual (BA) – complete information

The manual contains all information from incoming acceptance to disposal.

•Brief instructions (KA), present document – guide that takes you quickly to the 1st

measured value

The brief instructions contain all the essential information from incoming acceptance

to initial commissioning.

•Instruction manual (SI) – safety-relevant document

Depending on the approval, the required instruction manuals are supplied

with the device.

Additionally, the following parts may belong to the documentation, if applicable:

•EU-type examination certificate

•EU declaration of conformity

•Attestation of conformity

•Certificates

•Control drawings

•Functional safety manual

•Additional documents

Note

This document does not substitute the instruction manual.

Note

For full information on the product, refer to the instruction manual and further documentation

on the Internet at www.pepperl-fuchs.com.

Note

For specific device information such as the year of construction, scan the QR code

on the device. As an alternative, enter the serial number in the serial number search

at www.pepperl-fuchs.com.

2022-08

Vibration Limit Switch LVL-M4

Introduction

1.2 Safety Information

Target Group, Personnel

Responsibility for planning, assembly, commissioning, operation, maintenance,

and dismounting lies with the plant operator.

Only appropriately trained and qualified personnel may carry out mounting, installation,

commissioning, operation, maintenance, and dismounting of the product. The personnel must

have read and understood the instruction manual and the further documentation.

Prior to using the product make yourself familiar with it. Read the document carefully.

1.3 Symbols Used

This document contains symbols for the identification of warning messages and

of informative messages.

Warning Messages

You will find warning messages, whenever dangers may arise from your actions.

It is mandatory that you observe these warning messages for your personal safety and in order

to avoid property damage.

Depending on the risk level, the warning messages are displayed in descending order

as follows:

Danger!

This symbol indicates an imminent danger.

Non-observance will result in personal injury or death.

Warning!

This symbol indicates a possible fault or danger.

Non-observance may cause personal injury or serious property damage.

Caution!

This symbol indicates a possible fault.

Non-observance could interrupt the device and any connected systems and plants,

or result in their complete failure.

Vibration Limit Switch LVL-M4

Introduction

2022-08

Informative Symbols

Action

This symbol indicates a paragraph with instructions. You are prompted to perform an action

or a sequence of actions.

▶ Reference to another section or to further documentation

Permitted

Procedures, processes or actions that are permitted.

Forbidden

Procedures, processes or actions that are forbidden.

Electrical Symbols

Ground connection

Grounded clamp, which is grounded via a grounding system.

Protective earth (PE)

Ground terminals, which must be grounded prior to establishing any other connections.

The ground terminals are located on the inside and outside of the device.

Tool Symbols

Flat-blade screwdriver

Allen key

Open-ended wrench

Symbols in Graphics

1, 2, 3 ... Item numbers

A, B, C, ... Views

Explosion-hazardous area

Non-explosion-hazardous area

Note

This symbol brings important information to your attention.

)

2022-08

Vibration Limit Switch LVL-M4

Introduction

1.4 Registered Trademarks

Android®

Android, Google Play and the Google Play logo are trademarks of Google Inc.

Apple®

Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., registered

in the U.S. and other countries. App Store is a service mark of Apple Inc.

Bluetooth®

The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth® SIG,

Inc. and any use of such marks by Pepperl+Fuchs is under license. Other trademarks and

trade names are those of their respective owners.

Vibration Limit Switch LVL-M4

Basic Safety Instructions

2022-08

2 Basic Safety Instructions

2.1 Requirements for Personnel

The personnel must fulfill the following requirements to carry out the necessary tasks,

e. g. commissioning and maintenance:

•Trained, qualified specialists must have a relevant qualification for the specific function

•and task

•Are authorized by the plant owner/operator

•Are familiar with federal/national regulations

•Must have read and understood the instructions in the manual

and supplementary documentation

•Follow instructions and comply with conditions

2.2 Intended Use

•Only use the device for liquids.

•Improper use can pose hazards.

•Ensure that the device is free of defects while it is in operation.

•Use the device only for media to which the process-wetted materials have an adequate

level of resistance.

•Do not exceed or drop below the limit values for the device, see manual

and technical information TI01403O/98/EN.

2.2.1 Incorrect Use

The manufacturer is not liable for damage caused by improper or non-intended use.

Residual Risks

Due to heat transfer from the process, the temperature of the electronics housing

and the assemblies contained therein may rise to 80 °C (176 °F) during operation.

Danger of burns from contact with surfaces!

•If necessary, ensure protection against contact to prevent burns.

For requirements concerning functional safety in accordance with IEC 61508,

the associated SIL documentation must be observed.

2.3 Workplace Safety

For work on and with the device:

•Wear the required personal protective equipment according to federal/national

regulations.

2022-08

Vibration Limit Switch LVL-M4

Basic Safety Instructions

2.4 Operational Safety

Risk of injury!

•Operate the device only if it is in proper technical condition, free from errors and faults.

•The operator is responsible for ensuring failure-free operation of the device.

Modifications to the Device

Unauthorized modifications to the device are not permitted and can lead

to unforeseeable dangers.

•If, despite this, modifications are required, consult with Pepperl+Fuchs.

Repair

To ensure continued operational safety and reliability:

•Only perform repair work on the device if this is expressly permitted.

•Observe federal/national regulations pertaining to the repair of an electrical device.

•Use original spare parts and accessories from Pepperl+Fuchs only.

Hazardous Area

To eliminate danger to persons or the facility when the device is used in the hazardous area

(e. g. explosion protection):

•Check the nameplate to verify whether the ordered device can be used for the intended

purpose in the hazardous area.

•Observe the specifications in the separate supplementary documentation that

is an integral part of this manual.

2.5 Product Safety

This device is designed in accordance with good engineering practice to meet state-of-the-art

safety requirements, has been tested, and left the factory in a condition in which it is safe

to operate.

The device meets general safety standards and legal requirements. It also complies

with the EU directives listed in the device-specific EU Declaration of Conformity.

Pepperl+Fuchs confirms this by affixing the CE mark to the device.

2.6 Functional Safety SIL (Optional)

The functional safety manual must be strictly observed for devices that are used

in functional safety applications.

2.7 IT Security

We only provide a warranty if the device is installed and used as described

in the instruction manuals. The device has safety mechanisms integrated to prevent

users from inadvertently changing settings.

Provide additional protection for the device and data transfer to/from the device

•IT security measures defined in the plant owner/operator's own security policy

must be implemented by plant owners/operators themselves.

Altri manuali per LVL-M4

Indice

Altri manuali Pepperl+Fuchs Interruttore

Pepperl+Fuchs

Pepperl+Fuchs VISOLUX LD28/76a Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs LKL-P1 Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs SI00114O-H Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs Vibracon LVL-M2C Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs Vibracon LVL-B1 Guida di riferimento

Pepperl+Fuchs

Pepperl+Fuchs LVL-M4 Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs SI00113O-F Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs HiC2832R1 Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs Raritan Dominion KX II-101 Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs ARS B2 IA Series Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs Vibracon LVL-M Series Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs HiC284 Series Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs Vibracon LVL-M H Series Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs RocketLinx ICRL2-U-5RJ45-DIN Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs RocketLinx ICRL2-U-16RJ45-G-DIN Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs ARS B2 IC Series Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs LCL2 Guida di riferimento

Pepperl+Fuchs

Pepperl+Fuchs LVL-M4 Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs RocketLinx ICRL-U-5RJ45-G-DIN Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs Vibracon LVL-M1 Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs LVL-M4 Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs HD2-GTR-4PA Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs LVL-M4 Manuale utente

Pepperl+Fuchs

Pepperl+Fuchs LVL-M4 Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente
