Perlesmith PSTVS01 Manuale utente

Important: We are not responsible for any personal injury or product damage

due to mishandling, incorrect mounting, incorrect assembly or incorrect use of

Caution: This TV Stand mount is intended for use with television that

does not exceed the maximum weight capacity designated. Using this mount with

products heavier than the maximum weight indicated may result in instability

1

Qty.

Specifications Model

Instruction of installation operation

Left arm

Left Connecting arm

Ф8 washer

x1

x8

x8

x8

M8x16mm Hexagonal screw

Left Product base

Right arm

Right Connecting arm

Right Product base

x1

x1

x1

x1

x1

Left base mount Right base installation

A

BC

D

E

F

G

x4

x4

x4

M6x20mm Cross round screw

M4X20mm Cross round screw

M8x45mm Cross round screw

x8

L5 plastic spacer

H

I

x8

L10 plastic spacer

x4

washer

PSTVS01 Installation Manual

2.Hardware List

this product.

causing possible injury.

1.Product Features

A

B

C

1

Screw spare parts list

No. Description

2

3

M8 Nut

4

5

6

Model: PSTVS01

Product Weight: 2.65kg

TV Size Support: 37-70"

Maximum Load: 100lbs

3

4

TV

Hang the TV & arms on the mount

Set the bar into the slot

2The left arm is connected with the base installation

The right arm is connected with the base installation

A

B

C

Using Long bolt(D,E,F,G),

and Spacer

(H,I) to mount TV set to the

steel .

washer(J)

siding

DEF GH

I

If you have any problem, please contact the email adress：

customerservice@perlegear.com

www.perlesmith.com
