PERSTA DRI 21 Manuale utente

High pressure swing check valve
DRI
Operating instructions
Read the instructions prior to performing any task!

Dok.-Nr. 6402.DE.STD.03.2013, 2, en_GB
Translation of the original operating instructions
© Stahl-Armaturen PERSTA GmbH 2013
Stahl-Armaturen PERSTA GmbH
Mülheimer Str. 18
59581 Warstein-Belecke, Germany
Telephone: +49 2902 762-02
Fax: +49 2902 767-03
Email: [email protected]
Internet: www.persta.com
20.05.2021High pressure swing check valve DRI2

This manual enables safe and efficient handling of the high pres-
sure valve.
The manual is a component of the high pressure valve and must
be kept in the vicinity of the high pressure valve where it is avail-
able to personnel at all times.
The personnel must have carefully read and understood this
manual before performing any tasks. The basic prerequisite for
safe work is compliance with all the specified safety notices and
instructions.
In addition, the local occupational safety regulations and general
safety regulations must be complied with for the high pressure
valve’s area of use.
The illustrations in this manual are provided as examples only and
may deviate from the actual version.
Although the size and pressure ratings of the valve
types vary, the information in these instructions
applies generally to all valves, provided nothing to
the contrary is specified.
This manual applies to the following versions of the series 640 AB
of the high pressure swing check valve DRI:
Designation Series Nominal
diameter (DN)
[mm]
Pressure rate Class*
DRI 21 640 AB 50–300/250 PD 21 -
DRI 26 640 AB 65–300 PD 25 / PD 40 £2500
DRI 10–63 640 AB 80–600 PD 10–63 £4500
* Assignment number in the pipe construction
nIgnition hazard assessment GA004
nRisk analysis according to Pressure Equipment Directive
nRisk analysis as per the Machinery Directive
nTechnical data sheet
nBolt tightening torques according to the website:
www.persta.com
nAnd other documents included in the delivery
Information about the operating
manual
Scope of the document
Other applicable documents
Supplemental directives
20.05.2021 High pressure swing check valve DRI 3

Mülheimer Str. 18
59581 Warstein
Telephone: +49 2902 762-02
Fax: +49 2902 767-03
E-mail: [email protected]
Revision number Change/Supplemented informa-
tion
Date
1 Updates to chapter
“
Intended
use”.
05/05/2021
Customer Service - Stahl-Arma-
turen PERSTA GmbH
Revision overview
Supplemental directives
20.05.2021High pressure swing check valve DRI4

Table of contents
1 Overview.............................................................................. 7
2 Safety................................................................................... 9
2.1 Symbols in this manual................................................. 9
2.2 Intended use............................................................... 11
2.3 Safety signs................................................................ 12
2.4 Residual risks............................................................. 13
2.4.1 Basic dangers at the workplace............................... 13
2.4.2 Mechanical hazards................................................. 14
2.4.3 Thermal dangers...................................................... 14
2.4.4 Hazards due to hazardous substances and oper-
ating materials......................................................... 15
2.5 Behaviour in the event of an emergency.................... 16
2.6 Responsibility of the operating company.................... 16
2.7 Personnel requirements.............................................. 18
2.8 Personal protective equipment................................... 20
2.9 Spare parts................................................................. 21
2.10 Environmental protection.......................................... 22
3 Functional description..................................................... 23
3.1 Mode of operation of the high pressure swing check
valve........................................................................... 23
3.2 Seal to the outside...................................................... 24
3.3 Connections................................................................ 25
4 Transport and storage...................................................... 27
4.1 Safety notices for transport and storage..................... 27
4.2 Transport of packages................................................ 28
4.3 Storage of the valve.................................................... 30
4.4 Storage of spare parts................................................ 30
5 Installation......................................................................... 31
5.1 Safety notices for installation...................................... 31
5.2 Before the installation................................................. 32
5.3 Installing the valve...................................................... 33
5.4 After the installation.................................................... 33
5.4.1 Pickling the valve..................................................... 34
5.4.2 Painting the valve.................................................... 35
5.4.3 Executing the system pressure test and leak test... 35
5.4.4 Applying thermal insulation...................................... 35
6 Commissioning................................................................. 37
6.1 Safety notices for commissioning............................... 37
6.2 Prior to commissioning............................................... 39
6.3 Executing the commissioning process........................ 39
7 Maintenance...................................................................... 41
7.1 Safety instructions for maintenance............................ 41
Table of contents
20.05.2021 High pressure swing check valve DRI 5

7.2 Maintenance schedule................................................ 44
7.3 Maintenance tasks...................................................... 45
7.3.1 Visually checking the valve...................................... 45
7.3.2 Replacing the gasket of the pressure sealing
bonnet...................................................................... 46
7.4 After maintenance....................................................... 51
8 Faults and fault correction............................................... 53
8.1 Safety notices for fault correction............................... 53
8.2 Fault table................................................................... 55
8.3 Fault correction work.................................................. 57
8.3.1 Dismounting the swing check valve......................... 57
8.3.2 Mounting the swing check valve.............................. 59
9 Dismantling, disposal....................................................... 61
9.1 Safety notice for dismantling and disposal................. 61
9.2 Dismantling................................................................. 63
9.3 Disposal...................................................................... 64
10 Index................................................................................... 65
Table of contents
20.05.2021High pressure swing check valve DRI6

1 Overview
Fig. 1: High pressure swing check valve
The valve designated as high pressure swing check valve is
designed for installation in pipes.
By using the high pressure swing check valve the flow of a medium
is allowed in only one direction within the pipe.
In the other direction the closing element (Fig. 1/1) within the valve
is pressed into its seat by the medium flowing back and a return
flow is thereby prevented.
The following tools are required for the tasks described in the oper-
ating manual:
Forklift
Forklift with sufficient load-bearing capacity for transport of valves.
Brief description - high pressure
swing check valve DRI
Tools
Overview
20.05.2021 High pressure swing check valve DRI 7

Hoist
Hoist with sufficient load-bearing capacity for transporting valves
and components.
Pin puncher
Mandrel-like tool for punching out the segment rings.
Pull-off device
Pull-off device for removing the swing check valve from the body
and mounting the swing check valve. The pull-off device grasps
through the retaining ring and lifts the retaining ring with the swing
check valve out of the body from below. For the installation of the
swing check valve the retaining ring with mounted swing element
can be lowered into the housing with the pull-off device.
Ring bolts
nRing bolts to be screwed into the body.
nServe as attachment points of the valve on the hoist.
nIncluded in the scope of delivery of the valve.
Ring nuts
nRing nuts to be screwed onto the stud bolts.
nServe as attachment points of the valve on the hoist.
nIncluded in the scope of delivery of the valve.
Sling gear
Functional and approved gear for attaching valves and compo-
nents on the hoist.
Overview
20.05.2021High pressure swing check valve DRI8

2 Safety
2.1 Symbols in this manual
Safety instructions are indicated by symbols in this manual. The
safety instructions are introduced by signal words that indicate the
scope of the hazard.
DANGER!
This combination of symbol and signal word indi-
cates a hazardous situation that, if not avoided, will
result in death or serious injury.
WARNING!
This combination of symbol and signal word indi-
cates a potentially hazardous situation that, if not
avoided, may result in death or serious injury.
CAUTION!
This combination of symbol and signal word indi-
cates a potentially hazardous situation that, if not
avoided, may result in minor or moderate injury.
NOTICE!
This combination of symbol and signal word indi-
cates a potentially hazardous situation that, if not
avoided, may result in damage to property.
ENVIRONMENT!
This combination of symbol and signal word indi-
cates potential hazards for the environment.
Safety instructions may refer to specific, individual instructions.
Such safety instructions are integrated into the specific instruction,
so that the flow of reading is not interrupted during performance of
the task. The signal words described above are used.
Safety instructions
Safety instructions in specific
instructions
Safety
Symbols in this manual
20.05.2021 High pressure swing check valve DRI 9

Example:
1. Loosen the bolt.
2.
CAUTION!
Risk of getting trapped by the cover!
Close the cover carefully.
3. Tighten the bolt.
This symbol indicates useful tips and recommen-
dations as well as information on efficient and
trouble-free operation.
The following symbols are used throughout these instructions to
highlight specific instructions, results, lists, references and other
elements:
Symbol Explanation
Step-by-step instructions
ðResults of an action
References to sections of these operating
instructions and other applicable docu-
ments
Lists without a defined sequence
Tips and recommendations
Additional symbols
Safety
Symbols in this manual
20.05.2021High pressure swing check valve DRI10
