Pet Gear PG8250NZ Manuale utente

To see our full line of products, visit us online at: www.petgearinc.com

CUSTOMER SERVICE HELP DESK

[email protected]

Toll-Free 877-752-9123 - Eastern Standard Time 8am-3pm, Monday through Friday

For The ON-THE-GO Pet™

INSTRUCTION MANUAL

SPECIAL EDITION

NO-ZIP PET STROLLER

PG8250NZ

Interior Dimensions:

26L x 12W x 19.5H

SPECIAL EDITION NO-ZIP PET STROLLER • PG8250NZ

PARTS LIST

Check that you have all the parts shown BEFORE assembling your product.

If any parts are missing, call Customer Service.

UNFOLDING THE STROLLER

Stroller

Back Tray

2-Front Wheel

Assembly 2-Rear Wheels

2-Washers 2-Cotter Pins 2-Hub Caps

Rear Axel Assembly

Step 1. Release folding latch (A).

Step 2. Spread handle (B) and seat

apart until the frame clicks and locks

on both sides.

Step 3. Ensure that the stroller is

locked in on both sides before using.

SPECIAL EDITION NO-ZIP PET STROLLER • PG8250NZ 3

OPENING THE STROLLER

Spread the canopy apart to the open position.

Canopy

TO ASSEMBLE REAR WHEELS

Step 1. Slide wheel assembly onto axle.

Step 2. Slide washer onto axle.

Step 3. Fit straight part of cotter pin

through hole on axle.

Step 4. Line up each of the tabs in the hub cap with

the slots in the wheel, snap hub cap into place.

Step 5. Repeat for other side.

SPECIAL EDITION NO-ZIP PET STROLLER • PG8250NZ

Step 1. Place front wheels unit on leg with locking lever

pointing downward.

Step 2. Press locking lever and slide swivel housing

onto front leg.

Step 3. Release locking lever.

TO ASSEMBLE FRONT WHEELS

Step 1. Turn stroller over.

Step 2. Position rear axle assembly as shown.

Step 3. Push rear axle onto frame until it clicks and

locks into place on both sides.

NOTE: Pull down rmly on the brackets to be sure

they are securely attached to the stroller’s rear legs.

TO ASSEMBLE REAR AXEL TO FRAME

APPLYING THE BRAKES

Step 1. Push levers on both rear wheels down to lock.

Step 2. Pull levers up to unlock.

WARNING: Never leave your stroller parked without applying brakes.

Unlock

Lock

SPECIAL EDITION NO-ZIP PET STROLLER • PG8250NZ 5

Step 1. Open stroller and pull

compartment down.

Step 2. Clip onto frame.

Step 1. To close comparment,

pull downward to latch clip

onto frame.

Step 2. Lift up on latch clip

and secure by pushing down

until it locks.

TO SECURE COMPARTMENT TO FRAME

TO SECURE LATCH

SPECIAL EDITION NO-ZIP PET STROLLER • PG8250NZ

To help secure compartment, Velcro aps around tube

and fasten to the bottom of the compartment.

TO SECURE SIDE FLAP

Pull upward on latch clip to release.

TO UNLOCK LATCH

SPECIAL EDITION NO-ZIP PET STROLLER • PG8250NZ 7

Step 1. For ease in folding the stroller,

unlock latch, open the canopy, and

unwrap the Velcro aps from around

tube on both sides of the stroller.

Unwrap the

Velcro aps from

around tube.

Flaps need to be unwrapped on both sides

of the stroller.

Unlock latch. Open the canopy.

FOLDING THE STROLLER

Step 2.

Pull upward to unclip the compartment

from the frame.

Step 3.

Pull upward on the compartment.

At this point, please make sure that latch is unlocked,

the canopy is open, and the 2

Velcro aps from around

tubes on both sides of the stroller are unwrapped.

SPECIAL EDITION NO-ZIP PET STROLLER • PG8250NZ

FOLDING THE STROLLER

Step 4. Slide frame lock release

the main frame lock release

(D) rotate the folding mechanism

almost 180 degrees forward until

stroller releases and handle is

lowered.

C. D.

SLIDE TO RIGHT

SLIDE TO RIGHT AND ROTATE 180 DEGREES FORWARD WHILE

SQUEEZING MAIN FRAME (D) LOCK RELEASE

Step 1. To assemble the back tray, rst align a

hole on one side of the tray with one of the bolts

on the handle of the same side of the stroller.

Step 2. Snap one side of the tray over the bolt

on the handle then repeat for the other side.

TO ASSEMBLE BACK TRAY

SPECIAL EDITION NO-ZIP PET STROLLER • PG8250NZ

LOOKING AFTER YOUR STROLLER

WHEEL MAINTENANCE

• Always store product in a clean, dry place.

• Not recommended for use on the beach.

• Do not put heavy items on top of the stroller.

• Clean frame by wiping with a lightly oiled cloth.

• Do not use detergent or abrasives. Spot clean fabric with dry cleaning uid or mild soap

and warm water.

• To ensure easy maneuverability and to minimize wear and tear, (especially wheels, axles,

and swivels), keep all moving parts clean and lubricated with WD40®or light machine oil.

• NOTE: Do not lubricate brake components or swivel locks.

• Regularly check stroller for loose parts. These should be tightened or replaced.

• To clean and lubricate front and rear wheels, push out locking lever under wheel housing

to release rear wheel.

• To ensure ease of maneuverability and to minimize wear and tear, keep all moving parts

clean and lubricated with WD40®or light machine oil.

• Push wheel sets back on until they click and lock in position; pull on wheel housings to

ensure they are secure.

• Push stroller back and forth and rotate swivels around to work in lubricant.

• Clean the rear wheel assembly and the rest of the frame with warm, soapy water; clean

off with warm water and dry thoroughly.

• NOTE: Do not lubricate brake components or swivel locks.

10 SPECIAL EDITION NO-ZIP PET STROLLER • PG8250NZ

WARNING!

FOR PETS ONLY.

Not intended to be used as a restraining device for aggressive or dangerous animals that dig, chew or paw

aggressively. Do not leave your pet unattended. PET GEAR is not liable for any damage caused by aggressive,

destructive, immature or untrained animals. Do not use near an open or exposed ame. Failure to follow these

warnings and the instructions could result in serious injury or death.

• Do not carry additional bags, goods, or accessories in or on stroller except as recommended

in the manufacturer’s instructions.

• Recommended use of an approved safety restraint correctly tted and adjusted.

• Do not leave pet unsupervised in stroller.

• Before making adjustments to stroller ensure that pet’s body is clear of any moving parts.

• This stroller is designed for one pet only.

• Do not hang bags from handles as this may cause the product to become unstable.

• Do not use on escalator or stairs; fold stroller and carry.

• Put on brake whenever you park the stroller.

• Ensure stroller is completely erected and check that all locks are engaged before placing pet

in stroller.

• Do not overload as stroller may become unstable; maximum weight of pet using this stroller

not to exceed 45 lbs.

• Any goods carried in the basket not to exceed 6 lbs.

REPLACEMENT PARTS

Use only PET GEAR replacement parts.

Please have your model number ready before calling.

You can also request parts: http://www.petgearinc.com/main.asp?sel=2

192 Sheldon Avenue∙West Rutland, VT∙05777∙877-752-9123∙www.petgearinc.com
