Phil & Teds E3 Manuale utente
™
your e3 twin
survival guide
nitty
`
gritty
bits
`
bobs 2
one: wheeling
`
dealing 3
two: swivel
`
swerve 4
three: up
`
running 5
four: handling 6
five: hooding up 7
six: insert babies 7
ups
`
downs
newborns 8
toddlers 9
tricks
`
treats
buggy covers 10
buggy cocoon 10
buggy storage 11
buggy liners 11
cuts
`
bruises 13
rights
`
remedies 14
return
`
relax 15
nitty
`
gritty twin
welcome to the
adaptable
`
delightful
world of
our boxes make a great
distraction for your children while
you get into the nitty
`
gritty. the
plastic bag, however, does not!
Please read the WARNINGS on inside
back cover carefully and help us continue
improving our adaptability range by
returning your warranty from.
Open your e3 twin carton and check that
the following bits and bobs are there
a. 2 x rear wheels
b. 1 x main buggy
c. 2 x front wheel
d. 4 x bungs (attached to front of buggy)
– use when bumper bar is not attached
(push in silver buttons and remove).
e. 2 x clear backflap (for use in newborn
baby position)
check your bits
`
bobs
You will need
1 x scissors
1 x adult (or someone who follows
instructions!)
Now just follow steps one to six...
b
a
d
Please note that this buggy has not been designed for
running or jogging purposes.
32
e
c
1. Take main buggy and lay flat
(sunhoods up) as shown.
one: wheeling
`
dealing
2. Lift handle so rear axle is clear to
attach rear wheels.
3. Remove rear wheels from plastic bag
and use scissors to unwrap packaging
(discard bag immediately – it is a
suffocation hazard for children).
4. Take one rear wheel and push in silver
button on silver wheel axle.
5. Hold silver button in while inserting
wheel axle into buggy frame. Line up
silver button so it pops out of hole
on frame.
32
6. Repeat for second rear wheel on
opposite side (wheels work on
either side).
`
two: swivel
`
swerve
1. Turn twin buggy over and lift front as
far as hinge will allow.
2. Remove first front wheel from bag (the
rod is greased so watch out for greasy
fingers!).
4. Release cap. Your wheel will be in
place for use.
5. Repeat for other front wheel.
to lock the front wheels
1. Align silver button with small hole on
inside of front wheel black cap.
2. Turn wheel towards rear wheels
of buggy so front wheel is directly
underneath footwell and parallel with
rear wheels.
3. Cap will then fully close and fix front
wheel. Reverse for swivel.
3. Extend black
cap out fully
on underside
of footwell and
insert rod on
front wheel.
cap open cap closed
4
`
swivel fixed
`
`
ab
three: up
`
running
to fold
1. Press lever ‘b’ and pull lever ‘a’
(autolocks) on either side at bottom of
frame seat with fingers whilst holding
frame with palms of hands.
2. Let handle drop down, lift buggy by
cross bar (parallel to bumper bar) ‘c’;
front wheels (swivel) fold under frame.
3. Attach wrist strap around main buggy
frame to help hold it folded.
Make sure children are clear of buggy before folding,
unfolding or adjusting the buggy. Watch fingers - injury
may result.
5
4.
Ensure levers
‘a’ and ‘b’ (autolocks) are
properly engaged (as above).
Ensure that you hold the main
frame of the buggy when lifting in
and out of car.
1. Turn buggy over onto 4 wheels.
2. Pull up rear frame.
3.
Pull up until you hear a resounding ‘click’.
Ensure that locks are engaged. Seats
should now be firmly in place.
four: handling her
handle
1.
Push hood forward to access top
of frame.
2. Press in buttons ‘a’ on inside of handle
(both L and R sides).
3.
Hold both buttons in and pull handle
up until you hear a clear ‘click’. Ensure
buttons
‘a’
pop out again.
If you’re not happy with lower handle
setting adjust to higher setting:
4. Push in buttons ‘a’ on either side on
the inside of the handle again.
5. Pull handle up to higher postion until
you hear a clear ‘click’.
Ensure buttons
‘a’
pop out again.
a‘a’
push
in
`
6
When pulling buggy
ALWAYS adjust handle to
ensure it aligns with frame
as per photo.
brakes
Now you’re up and running don’t let buggy
get away on you - use brakes.
1. Stand behind buggy and push brake
lever down with foot. This will put
brakes on. Push up to take brakes off.
off
on
Safety Wrist Strap - Your buggy can be free wheeling
without the brakes so the safety wrist strap should be
worn at all times when pushing the buggy. Just loop it
round your wrist.
six: insert babies
Apply brakes and insert babies and fasten
safety harnesses.
1. Unclip 4 buckles on breastplate
(circled in green) and place baby
in buggy.
2. Adjust upper straps to fit snugly on
babies’ shoulders.
3. The breastplate should sit snugly on
each baby’s chest. Adjust side straps
until it sits in correct position. (You
should be able to fit 2 average size
fingers between straps and baby.)
4.
Adjust crotch strap length (under or
over webbing loop) for a comfortable
fit.
1. Attach snaps on back of sunhoods to
higher snaps on handle, both left and
right sides.
five: hooding up
2. Move to front of buggy and secure
snaps on front of sunhoods to seats.
WARNING: Ensure harnesses are used and properly
adjusted at all times.
Note that the windows in the hood are lined with a
sun mesh of a lower shade factor than buggy fabric.
Always use sun cream and clothing for protection of
children in direct sunlight.
7
newborn buggy
(carry newborn babies)
1. With buggy set up ready to go,
apply brakes.
2. Undo 2 clips at back of seat, ‘a’ and ‘b’.
ups
`
downs
a
b
3. Undo clips ‘c’ and ‘d’ at top of seat
base and push base corners down
until it is almost flat.
4.
Undo zips fully
on either side of
seat base for a
completely flat
newborn bed.
5. Lie baby flat
in newborn
position, facing
cd
The back flap can be
rolled up and held
at top using strip
of hook/loop tape
at top.
WARNING: Never
allow the plastic to
fall over the child.
1
22
33
forward, and secure baby firmly with
adjusted safety harness.
6. Repeat for other seat.
using the clear plastic back flap
1. Attach clear plastic back flap using
hook/loop tape at top, ‘1’, and sides, ‘2’
and ‘3’.
