Philips AD200/05 Manuale utente

www.philips.com/welcome

AD200

User manual

1EN

Contents

1 Important 2

2 Your docking speaker 3

Introduction 3

What's in the box 3

Overview of the main unit 3

3 Prepare 4

Connect power 4

Turn the unit on 4

4 Play 5

Listen to the iPod/iPhone 5

Adjust sound 5

Compatibility 5

Charge the iPod/iPhone 5

Play from an external device 6

5 Specications 7

Amplier 7

General information 7

6 Troubleshooting 8

2EN

1 Important

• Read these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or

otherapparatus(includingampliers)that

produce heat.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the apparatus.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

• Unplug this apparatus during lightning

storms or when unused for long periods

of time.

• Referallservicingtoqualiedservice

personnel. Servicing is required when

the apparatus has been damaged in any

way, such as power-supply cord or plug

is damaged, liquid has been spilled or

objects have fallen into the apparatus, the

apparatus has been exposed to rain or

moisture, does not operate normally, or

has been dropped.

• Apparatus shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on the

apparatus(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plugin

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

•Never remove the casing of this apparatus.

•Never lubricate any part of this apparatus.

•Never place this apparatus on other electrical

equipment.

3EN

2 Your docking

speaker

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Introduction

With this docking speaker, you can:

• Enjoy music on your iPod/iPhone;

• Charge your iPod/iPhone;

• Enjoy music on external audio player

through MP3 link cable.

What's in the box

Check and identify the contents of your

package:

• Main unit

• AC power adaptor

• Quick start guide

Overview of the main unit

a +/-

• Adjust volume.

b Power socket

• Connect the power adaptor.

c Dock for iPod/iPhone

d MP3-LINK

• Connect an external audio player.

• Turn the unit on/off.

4EN

3 Prepare

Always follow the instructions in this chapter in

sequence.

Connect power

Caution

•Risk of product damage! Make sure that the power

supply voltage matches the voltage printed on the

bottom of the unit.

•Risk of electric shock! When you unplug the AC

adaptor, always pull the plug from the socket. Never

pull the cord.

•Before you connect the AC adaptor, make sure that you

have completed all the other connections.

Connect the AC power adaptor, one end to the

power socket on the back of the unit, and the

other the wall power supply.

Turn the unit on

Press repeatedly on the top to turn the unit

on/off.

5EN

4 Play

Listen to the iPod/iPhone

1 Load your iPod/iPhone.

2 Play your iPod/iPhone.

» Your music on the phone comes out

through the unit.

Adjust sound

To adjust the sound, press the button +/-.

Compatibility

Made for Apple iPod models with 30-pin dock

connector as follows:

• iPodtouch(4thgeneration)

• iPodtouch(3rdgeneration)

• iPodtouch(2ndgeneration)

• iPodtouch(1stgeneration)

• iPodnano(6stgeneration)

• iPodnano(5thgeneration)

• iPodnano(4thgeneration)

• iPodnano(3rdgeneration)

• iPodnano(2ndgeneration)

• iPodnano(1stgeneration)

• iPod mini

• iPod classic

• iPod with video

• iPod with color display

• iPhone 4

• iPhone 3GS

• iPhone 3G

• iPhone

Charge the iPod/iPhone

When the system is connected to power, the

docked iPod/iPhone begins to charge.

6EN

Play from an external device

You can also listen to an external audio player

through the device.

Connect the MP3 link cable, one end to the

MP3-LINK socket at the back, and the other to

the headphone socket.

7EN

5 Specifications

Amplier

Rated Output Power 2 X 2 W RMS

General information

AC Power S009GB0590150

(Philips)

Input: 100-240 V ~,

50/60Hz, 0.3A; Output:

DC 5.9V 1500 mA

Operation Power

Consumption

8 W

Dimensions

- Main Unit

(WxHxD) 184 x 80.85 x 62 mm

Weight

- Main Unit 0.3 kg

8EN

6 Troubleshooting

Warning

•Never remove the casing of this apparatus.

To keep the warranty valid, never try to repair

the system yourself.

If you encounter problems when using this

apparatus, check the following points before

requesting service. If the problem remains

unsolved, go to the Philips web site (www.

philips.com/welcome).Whenyoucontact

Philips, ensure that the apparatus is nearby

and the model number and serial number are

available.

No power

•Make sure that the AC power adaptor of

the unit is connected properly.

•Make sure that there is power at the AC

outlet.

No sound

•Adjust the volume.

Docked iPod/iPhone can't be charged

•Make sure that the unit is compatible

the iPod/iPhone.

•Make sure that the unit is successfully

connected to the iPod/iPhone.

•Remove the protective case of your iPod/

iPhone.

Specifications are subject to change without notice

AD200_05_UM_V1.0
