Philips GC2089 series Manuale utente

Always there to help you

EasySpeed Plus Cordless

GC2078-GC2089 series

Specifications are subject to change without notice

User manual

4239 000 93831

ENGLISH

m j

2345

7 86

10 11 12 13

14 15 16 17

EasySpeed Plus Cordless GC2078-GC2089 series

ENGLISH 6

ESPAÑOL 14

FRANÇAIS 23

ITALIANO 33

PORTUGUÊS 42

Important

Read the separate important information leaet and the user manual

carefully before you use the appliance. Save both documents for future

reference.

General description (Fig. 1)

1 Spray nozzle

2 Cap of lling opening

3 Steam control

- CALC CLEAN = Calc-Clean function

- = dry ironing

- = optimal steam

- = maximum steam

- = turbo steam

4 Steam boost button

5 Spray button

6 Temperature dial

7 Type plate

8 Water tank with MAX water level indication

9 Soleplate

10 Light ring

11 Base

12 Iron storage lock

13 Mains cord

Using the appliance

Filling the water tank

Note: Your appliance has been designed to be used with tap water. In case

you live in an area with hard water, fast scale build-up may occur.Therefore,

it is recommended to use distilled or de-mineralized water to prolong the

lifetime of your appliance.

Note: Do not add perfume, water from tumble dryer, vinegar, magnetically

treated water (e.g.,Aqua+), starch, descaling agents, ironing aids, chemically

descaled water or other chemicals as they may cause water spitting, brown

staining, or damage to your appliance.

6ENGLISH

ENGLISH

1 Set the steam control to position . (Fig. 2)

2 Fill the water tank up to the MAX indication (Fig. 3).

3 Closethecapofthellingopening.

Selecting temperature and steam setting

Table 1

Fabric type Temperature

setting

Steam

setting

Steam

boost

Spray

Linen MAX , Yes Yes

Cotton 3, Yes Yes

Wool 2No Yes

Silk 1No No

Synthetic fabrics

(e.g. acrylic, nylon,

polyamide, polyester).

1No No

Note: As indicated in the table above, do not use steam or steam boost at a

low temperature, otherwise hot water may leak from the iron.

1 Consult table 1 to set the temperature dial to the appropriate

setting for your garment (Fig 4)

2 Consult table 1 to select a steam setting that corresponds to the

temperature you have set. (Fig. 5)

3 Place the iron on its base and connect the base to a power socket.

(Fig 6.)

Note: Make sure that the base sits on a stable and level surface. It is

recommended to place the base on the soft part of the ironing board.

ENGLISH

4 Thelightringstartstoashbluelight,indicatingtheironisheating

up. (Fig 7.)

5 Whenthebluelightturnssteady,youcanstartironing.(Fig.8)

Operation of Smart Charging base

The iron is equipped with Smart Charging base. The light will indicate

thestatusoftheiron,andremindyoutochargetheironafter20to

25 seconds to ensure a good wrinkle removal performance. Please

refer to table 2 for the operation of the base.

Note: to ensure good wrinkle removal performance, always put the iron on

its base during the resting period. Do not place the iron on its heel. (Fig.9)

Table 2

Light status Iron status Instructions

Flashing blue Heating up Wait for iron to be ready.

Steady blue Ready for use You can start ironing.

Flashing orange The iron needs to

be charged now Put the iron back to the

base to charge it.

Slow breathing

blue (specic

types only)

Safety auto-off has

been activated Refer to Chapter

“Features”, section “safety

auto-off”.

Features

Spray function

- Press the spray button to moisten the garment to be ironed. This

helps remove stubborn creases (Fig. 10).

Steam boost function

- Press and release the steam boost button for a powerful boost of

steam to remove stubborn creases (Fig. 11).

ENGLISH

- For optimal steam boost performance, it is recommended to press

the steam boost trigger at a 5 seconds interval.

Vertical steam

- You can use the steam boost function when you hold the iron in

vertical position for removing creases from hanging clothes, curtains

etc. (Fig. 12)

Dry ironing

- Set the steam control to to iron without steam. (Fig. 2)

Safety auto-off function (specic types only)

- The iron switches off automatically if the iron is not in use for

8 minutes. The light ring starts to slowly breath in blue to indicate

the safety auto-off mode is activated.

- To let the iron heat up again, remove the iron (if the iron is on the

base) and put it back to the base.

Cleaning and maintenance

Cleaning

1 Set the steam control to ,unplugthebaseandlettheironcool

down. (Fig. 2)

2 Pour any remaining water out of the water tank.

3 Wipeakesandanyotherdepositsoffthesoleplatewithadamp

cloth and a non-abrasive (liquid) cleaning agent.

Caution:Tokeepthesoleplatesmooth,avoidhardcontactwithmetal

objects.Neveruseascouringpad,vinegarorotherchemicalstoclean

the soleplate.

Note: Regularly rinse the water tank with tap water. Empty the water tank

after rinsing it.

ENGLISH

Calc-Clean function

IMPORTANT: To prolong the lifetime of your appliance and

to maintain good steaming performance, use the Calc-Clean

function once every two weeks. If the water in your area is

very hard (i.e. when akes come out of the soleplate during

ironing), use the Calc-Clean function more frequently.

1 Make sure the steam control is set to . (Fig. 2)

2 Fill the water tank to the MAX indication. (Fig. 3)

Do not pour vinegar or other descaling agents into the water tank.

3 Set the temperature dial to MAX. (Fig. 13)

4 Pluginthebase,puttheirononthebaseandlettheironheatup.

(Fig. 6)

5 Remove the iron when the light ring turns steady blue. (Fig. 8)

6 Hold the iron over the sink. Push the steam control to the Calc-

Clean position and hold it. (Fig. 14)

7 Gently shake the iron while holding the steam control until all

water in the water tank has been used up. (Fig. 15)

Caution:Whilescaleisushedout,steamandboilingwateralsocome

out of the soleplate.

8 Set the steam control back to . (Fig. 2)

Note: Repeat the Calc-Clean process if the water that comes out of the iron

still contains scale particles.

After the Calc-Clean process

1 Put the iron on the base. Let the iron heat up to dry the soleplate.

2 Take the iron from the base when the light ring turns steady blue.

ENGLISH

3 Move the iron gently over a piece of cloth to remove any water

stains on the soleplate.

Storage

1 Set the steam control back to . (Fig. 2)

2 Pour out any remaining water from the water tank.

3 Unplug the mains cord and wind the mains cord around the base.

(Fig. 16)

Removeironfromthebasewhenyouwindthecord,asthesoleplate

could still be hot.

4 Put the iron on the base. Lock the iron to its base. (Fig. 17)

5 Let the iron cool down before you store it.

You can carry the iron and base by the iron handle. (Fig. 18)

Troubleshooting

This chapter summarises the most common problems you could

encounter with the appliance. If you are unable to solve the problem

with the information below, visit www.philips.com/support for a list of

frequently asked questions or contact the Consumer Care Centre in

your country (see the worldwide guarantee leaet for contact details).

Problem Possible cause Solution

The iron does

not produce

steam.

Cordless iron cools

down after a while. It

needs to be recharged.

Put the iron back to the

base until the light ring

turns steady blue light,

indicating that the iron is

ready for use again.

The steam control is

set to . Set the steam control to

a steam setting (consult

Table 1 in Chapter “using

the appliance”).

The water tank is empty. Fill the water tank.

ENGLISH

Problem Possible cause Solution

You are using a

temperature of below

2 dots.

ConsultTable 1

in Chapter “using

the appliance” for

temperature and steam

setting.

The iron leaks. Cordless iron cools

down after a while. It

needs to be recharged.

Put the iron back to its

base to heat up and dry

the soleplate.

You are using steam or

steam boost at a low

temperature.

Put the iron back to its

base to heat up and dry

the soleplate.

ConsultTable 1 for use

of steam and steam

boost.

You have used the

steam boost function

too often within a very

short period.

Put the iron back to its

base to heat up and dry

the soleplate. Use the

steam boost function

less frequently.

The water tank is

overlled. Do not ll the water

tank beyond the MAX

indication.

The door of lling

opening is not closed

properly.

Make sure that the

door of lling opening is

closed properly.

Flakes and

impurities come

out of the soleplate

during ironing.

You have not

performed Calc-Clean

function for some time.

The iron need to be

cleaned.

Use the Calc-Clean

function (see chapter

‘Cleaning and

maintenance’, section

‘Calc-Clean function’).
