Published by Philips Consumer Lifestyle Page 1of 32 For internal use only

Document No. : CSW-07-081-18028

PerfectCare Elite

Philips Consumer Lifestyle

Version 25

Product Information

Fast & Powerful Crease Removal

OptimalTEMP technology

Safe rest

Soleplate: T-ionicGlide

Steam output control • Steam tip

Variable steam settings

Vertical steaming

Easy to Use

Cord freedom (swivel): 180cord freedom

Cord storage: Cord storage compartment

Hose storage: Hose storage compartment

Low water alarm

Open handle

Refill any time

Safe for all fabrics: Even for delicates like silks

Ultra light and comfortable

Filling and emptying water: Detachable water

tank, Extra large filling hole

Sustainability

ECO setting

Energy saving: 50% energy reduction

Safety Information

This product meets the requirements regarding

interference suppression on radio and TV.

Calc Management

Suitable for tap water

Calc clean reminder

Calc clean solution: Easy De-Calc Plus

Technical Information

Voltage

Frequency

Dimensions (W x H x L)

Packaging

Product

Weight

Iron

Iron + Base

220 - 240 V

50 - 60 Hz

31 x 35 x 51 cm

23.3 x 28.5 x 45.3 cm

0.8 kg

5.1 kg

GC9610

GC9611

GC9612

GC9614

GC9615

GC9620

GC9622

GC9625

GC9630

GC9635

GC9640

GC9641

GC9642

GC9644

GC9646

GC9647

GC9648

GC9650

Published by Philips Consumer Lifestyle Page 2of 32 For internal use only

Document No. : CSW-07-081-18028

GC9610 –GC9650

Product Matrix

Model

GC9610

GC9611

GC9612

GC9614

Power

2000-2400W

Heat - up Time

2 minutes

Steam Pressure

7.0 Bar

7.5 Bar

Continuous Steam

135 g/min

150 g/min

Steam Boost

490 g

500 g

Vertical Steam

Yes

Soleplate

T-ionicGLIDE

ECO Mode

Yes

Silent Steam Technology

No

Water Tank

1800 ml

Storage Solution

Carry Lock

Safety Auto-Off

No

Power cord length

1.65 m

Hosecord length

1.6 m

Accessories

No

Published by Philips Consumer Lifestyle Page 3of 32 For internal use only

Document No. : CSW-07-081-18028

GC9610 ~ GC9650

Product Matrix

Model

GC9615

GC9620

GC9622

GC9625

Power

2000-2400W

Heat - up Time

2 minutes

Steam Pressure

7.5 Bar

6.5 Bar

6.7 Bar

Continuous Steam

150 g/min

130 g/min

135 g/min

Steam Boost

510 g

450 g

470 g

Vertical Steam

Yes

Soleplate

T-ionicGLIDE

ECO Mode

Yes

Silent Steam Technology

No

Water Tank

1800 ml

Storage Solution

Carry Lock

Safety Auto-Off

No

Yes

Power cord length(m)

1.65 m

1.8 m

Hosecord length(m)

1.6 m

Accessories

No

Published by Philips Consumer Lifestyle Page 4of 32 For internal use only

Document No. : CSW-07-081-18028

GC9610 –GC9650

Product Matrix

Model

GC9630

GC9635

GC9640

GC9641

Power

2000-2400W

Heat - up Time

2 minutes

Steam Pressure

6.7 Bar

7.5 Bar

7.0 Bar

Continuous Steam

135 g/min

155 g/min

140 g/min

135 g/min

Steam Boost

470 g

520 g

480 g

Vertical Steam

Yes

Soleplate

T-ionicGLIDE

ECO Mode

Yes

Silent Steam Technology

No

Yes

Water Tank

1800 ml

Storage Solution

Carry Lock

Safety Auto-Off

Yes

Power cord length

1.8 m

Hosecord length

1.6 m

Accessories

No

Non-Woven Bag

Published by Philips Consumer Lifestyle Page 5of 32 For internal use only

Document No. : CSW-07-081-18028

GC9610 –GC9650

Product Matrix

Model

GC9642

GC9644

GC9646

GC9647

Power

2000-2400W

Heat - up Time

2 minutes

Steam Pressure

7.2 Bar

7.3 Bar

Continuous Steam

145 g/min

150 g/min

Steam Boost

490 g

500 g

510 g

Vertical Steam

Yes

Soleplate

T-ionicGLIDE

ECO Mode

Yes

Silent Steam Technology

Yes

Water Tank

1800 ml

Storage Solution

Carry Lock

Safety Auto-Off

Yes

Power cord length

1.8 m

Hosecord length

1.6 m

Accessories

Non-Woven Bag

–

Published by Philips Consumer Lifestyle Page 6of 32 For internal use only

Document No. : CSW-07-081-18028

GC9610 –GC9650

Product Matrix

Model

GC9648

GC9650

Power

2000-2400W

Heat - up Time

2 minutes

Steam Pressure

7.7 Bar

7.5 Bar

Continuous Steam

160 g/min

150 g/min

Steam Boost

540 g

500 g

Vertical Steam

Yes

Soleplate

T-ionicGLIDE

ECO Mode

Yes

Silent Steam Technology

Yes

Water Tank

1800 ml

Storage Solution

Carry Lock

Safety Auto-Off

Yes

Power cord length

1.8 m

Hosecord length

1.6 m

Accessories

–

Non-Woven Bag,

Glove

Published by Philips Consumer Lifestyle Page 7of 32 For internal use only

Document No. : CSW-07-081-18028

GC9610 –GC9650

Part List

GC9610/20

GC9611/20

GC9611/21

GC9612/20

POS

DESCRIPTION

889961020290

889961120290

889961121160

889961220290

FRANCE

SWITZERLAND

FRANCE

1

INLAY & LIGHT STRIP MOLDED

423902661883

2

REFLECTOR 2K MOLDED

423902661311

3

WA3 STELLAR MS-LED WIRE

423902187003

5

TRIGGER MOLDED

423902661341

8

HOUSING & DECO PLATE 2K PRINTED

423902188523

10

CHASSIS MOLDED

423902661292

13

SOLEPLATE ASSY

423902269631

14

HOSE CORD MTD ASSY

423902186966

15*

WATER TANK PRTED ASSY

423902187892

19

STAND TOP ASSY

423903011771

423903011841

423903011861

20

STELLAR POWER BOARD PCBA

423903012562

21

PCBA HOLDER MOLDED

423902661593

22

STELLAR HALL SENSOR PCBA

423902187392

23

STELLAR UI BOARD PCBA

423902187385

24

BUTTON FRAME PRTED

423901455391

423903011791

25

POWER BUTTON PRTED

423903011801

26

PUMP JIAYIN JYPC302 MOUNTED ASSY

423902187361

30

INLET SUPPORT SEAL

423901561571

31

INLET COUPLING PLATE WELDED

423902188461

32

INLET COUPLING SUPPORT MOLDED

423902661601

34

HOSE CLIP-BRAIDED RUBBER HOSE

423901010281

35

INOX CLAMP

423901010261

36

STELLAR BOILER

423903014431

37

E-VALVE 7 BAR

423901013832

38A

SAFETY VALVE 8 BAR

423901013822

38B

SAFETY CAP NAT

423901559211

39

WATER PROBE ASSY

423902186972

42

RINSE CAP PRINTED ASSY#

423903011811

43

MAINSCORD EU

423900012951

423900013491

423900012951

50

STAND BOTTOM ASSY

423902188504

Notes: * Option for CRP

Published by Philips Consumer Lifestyle Page 8of 32 For internal use only

Document No. : CSW-07-081-18028

GC9610 –GC9650

Part List

GC9612/21

GC9614/20

POS

DESCRIPTION

889961221160

889961420010

889961420290

889961420380

FRANCE

SWITZERLAND

FRANCE

1

INLAY & LIGHT STRIP MOLDED

423902661883

2

REFLECTOR 2K MOLDED

423902661311

3

WA3 STELLAR MS-LED WIRE

423902187003

5

TRIGGER MOLDED

423902661341

8

HOUSING & DECO PLATE 2K PRINTED

423902188523

10

CHASSIS MOLDED

423902661292

13

SOLEPLATE ASSY

423902269631

14

HOSE CORD MTD ASSY

423902186966

15*

WATER TANK PRTED ASSY

423902187892

19

STAND TOP ASSY

423903011861

423903014791

20

STELLAR POWER BOARD PCBA

423903012562

21

PCBA HOLDER MOLDED

423902661593

22

STELLAR HALL SENSOR PCBA

423902187392

23

STELLAR UI BOARD PCBA

423902187385

24

BUTTON FRAME PRTED

423903011791

25

POWER BUTTON PRTED

423903011801

26

PUMP JIAYIN JYPC302 MOUNTED ASSY

423902187361

423902186522

423902187361

30

INLET SUPPORT SEAL

423901561571

31

INLET COUPLING PLATE WELDED

423902188461

32

INLET COUPLING SUPPORT MOLDED

423902661601

34

HOSE CLIP-BRAIDED RUBBER HOSE

423901010281

35

INOX CLAMP

423901010261

36

STELLAR BOILER

423903014431

37

E-VALVE 7 BAR

423901013832

38A

SAFETY VALVE 8 BAR

423901013822

38B

SAFETY CAP NAT

423901559211

39

WATER PROBE ASSY

423902186972

42

RINSE CAP PRINTED ASSY#

423903011811

43

MAINSCORD EU

423900013491

423900012951

50

STAND BOTTOM ASSY

423902188504

Notes: * Option for CRP

Published by Philips Consumer Lifestyle Page 9of 32 For internal use only

Document No. : CSW-07-081-18028

GC9610 –GC9650

Part List

GC9614/21

GC9615/20

GC9620/20

POS

DESCRIPTION

889961421160

889961520010

889961520290

889962020010

SWITZERLAN

D

WEU

FRANCE

WEU

1

INLAY & LIGHT STRIP MOLDED

423902661883

2

REFLECTOR 2K MOLDED

423902661311

3

WA3 STELLAR MS-LED WIRE

423902187003

5

TRIGGER MOLDED

423902661341

8

HOUSING & DECO PLATE 2K PRINTED

423902188523

10

CHASSIS MOLDED

423902661292

423902670973

13

SOLEPLATE ASSY

423902269631

14

HOSE CORD MTD ASSY

423902186966

423903007293

15*

WATER TANK PRTED ASSY

423902187892

19

STAND TOP ASSY

423903014791

423903014811

423902188534

20

STELLAR POWER BOARD PCBA

423903012562

423902187379

21

PCBA HOLDER MOLDED

423902661593

22

STELLAR HALL SENSOR PCBA

423902187392

23

STELLAR UI BOARD PCBA

423902187385

24

BUTTON FRAME PRTED

423903011791

423902187841

25

POWER BUTTON PRTED

423903011801

423902187851

26

PUMP JIAYIN JYPC302 MOUNTED ASSY

423902187361

30

INLET SUPPORT SEAL

423901561571

31

INLET COUPLING PLATE WELDED

423902188461

32

INLET COUPLING SUPPORT MOLDED

423902661601

34

HOSE CLIP-BRAIDED RUBBER HOSE

423901010281

35

INOX CLAMP

423901010261

36

STELLAR BOILER

423903014431

423903014421

37

E-VALVE 7 BAR

423901013832

38A

SAFETY VALVE 8 BAR

423901013822

38B

SAFETY CAP NAT

423901559211

39

WATER PROBE ASSY

423902186972

42

RINSE CAP PRINTED ASSY#

423903011811

423902187871

43

MAINSCORD EU

423900013491

423900012951

242207098596

50

STAND BOTTOM ASSY

423902188504

423903007281

Notes: * Option for CRP

Published by Philips Consumer Lifestyle Page 10 of 32 For internal use only

Document No. : CSW-07-081-18028

GC9610 –GC9650

Part List

GC9622/20

GC9625/20

GC9630/20

POS

DESCRIPTION

889962220010

889962220500

889962520290

889963020010

WEU

SINGAPORE

FRANCE

WEU

1

INLAY & LIGHT STRIP MOLDED

423902188443

423902188453

2

REFLECTOR 2K MOLDED

423902661311

3

WA3 STELLAR MS-LED WIRE

423902187003

5

TRIGGER MOLDED

423902661341

8

HOUSING & DECO PLATE 2K PRINTED

423902188523

10

CHASSIS MOLDED

423902670973

423902661292

423902670973

13

SOLEPLATE ASSY

423902269631

14

HOSE CORD MTD ASSY

423903007293

423902186966

423903007293

15*

WATER TANK PRTED ASSY

423902187892

19

STAND TOP ASSY

423902188554

423902188515

20

STELLAR POWER BOARD PCBA

423902187379

21

PCBA HOLDER MOLDED

423902661593

22

STELLAR HALL SENSOR PCBA

423902187392

23

STELLAR UI BOARD PCBA

423902187385

24

BUTTON FRAME PRTED

423902187841

25

POWER BUTTON PRTED

423902187851

26

PUMP JIAYIN JYPC302 MOUNTED ASSY

423902187361

30

INLET SUPPORT SEAL

423901561571

31

INLET COUPLING PLATE WELDED

423902188461

32

INLET COUPLING SUPPORT MOLDED

423902661601

34

HOSE CLIP-BRAIDED RUBBER HOSE

423901010281

35

INOX CLAMP

423901010261

36

STELLAR BOILER

423903014421

423903014431

423903014421

37

E-VALVE 7 BAR

423901013832

38A

SAFETY VALVE 8 BAR

423901013822

38B

SAFETY CAP NAT

423901559211

39

WATER PROBE ASSY

423902186972

42

RINSE CAP PRINTED ASSY#

423902187871

43

MAINSCORD EU

242207098596

242207098618

242207098596

50

STAND BOTTOM ASSY

423903007281

423902188504

423903007281

Notes: * Option for CRP

Philips GC9610 Manuale utente

Manuali Ferro popolari di altre marche
