Philips HI845/02 Manuale utente

Aquazur

HI845, HI838, HI835

DE G HFCBA

CALC CLEAN

ENGLISH 6

DEUTSCH 16

FRANÇAIS 26

NEDERLANDS 36

ITALIANO 46

HI845, HI838, HI835

General description

AShot-of-steam button

BSteam control

CSpray button

DTemperature pilot light

ESteam trigger

FTemperature dial

GSoft-touch handgrip

HConnecting cord/supply hose

ISpray nozzle

JInternal reservoir

KCalc-clean button

LAnti-calc cassette

MFilling opening

NCassette release button

OSuspension hook

PMains cord

QWater tank

RRubber mat

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Check if the voltage indicated on the type plate corresponds to

the local mains voltage before you connect the appliance.

◗Only connect the appliance to an earthed wall socket.

◗Do not use the appliance if the plug, the cord, the supply hose or

the appliance itself shows visible damage, or if the appliance has

been dropped or is leaking.

◗Check the cord and the supply hose regularly for possible

damage.

◗If the mains cord or the supply hose is damaged, it must be

replaced by Philips, a service centre authorised by Philips or

similarly qualified persons in order to avoid a hazard.

◗Never leave the appliance unattended when it is connected to the

mains.

◗Never immerse the iron or the steam tank in water.

◗Keep the appliance out of the reach of children.

◗The iron stand and the soleplate of the iron can become

extremely hot and may cause burns if touched. If you want to

move the steam tank, do not touch the stand.

◗Do not allow the mains cord and supply hose to come into

contact with the soleplate when it is hot.

◗When you have finished ironing, when you clean the appliance,

when you fill or empty the water tank and also when you leave

the iron even for a short while: set the steam control to position

O, put the iron on its heel and remove the mains plug from the

wall socket.

ENGLISH6

ENGLISH 7

◗Only use this iron with the stand supplied.

◗Always place and use the iron and the steam tank on a stable,

level and horizontal surface. Do not put the steam tank on the

soft part of the ironing board.

◗Do not put perfume, vinegar, starch, descaling agents, ironing aids

or other chemicals in the water tank.

◗This appliance is intended for household use only.

Before first use

C1Press the cassette release button and remove the anti-calc

cassette from the water tank. Enter the current date

(day/month/year) on the sticker on the cassette. Reinsert the

cassette into the water tank.

C2Fill the water tank with tap water (using a jar/bottle) up to the

MAX indication.

C3Set the temperature dial to MAX.

C4Set the steam control to position 4.

The temperature pilot light goes on.

MAX.

ENGLISH8

C5When the pilot light goes out, squeeze the steam trigger under

the handgrip continuously.

The iron starts producing steam after about 2 minutes.

6Pass the iron over a piece of damp cloth for several minutes to

remove any residues from the soleplate.

BThe iron may give off some smoke when you use it for the first time.This

will cease after a short while.

Preparing for use

How to use the rubber mat and the suspension hook

The rubber mat allows you to put down the hot iron during ironing.

The suspension hook allows you to suspend the water tank from the

ironing board.

C◗The rubber mat can be placed either on the water tank or on the

ironing board.

C◗If you want to put the iron on the water tank, always put the

rubber mat on the water tank.

C◗Never put the iron on the water tank without the rubber mat.

C◗The water tank can be suspended from the metal tray of most

ironing boards by means of the suspension hook. Pull the

suspension hook out the water tank and attach it to the metal

tray of the ironing board.

Remove the rubber mat from the water tank and place it on the

ironing board before suspending the water tank from the suspension

hook.

Do not place the rubber mat on a table or any other surface that may

be damaged by heat.

MAX.

ENGLISH 9

Filling the water tank

Never immerse the iron in water.

1Unplug the appliance and make sure you don't squeeze the

steam trigger.

C◗If the water tank is in horizontal position, fill the it up to the MAX

level indicated on the side or in the filling opening.

C◗If the water tank is in vertical position, fill it up to the MAX

indication on the side. Do not exceed this level.

Do not put perfume, vinegar, starch, descaling agents, ironing additives

chemically descaled water or other chemicals in the water tank.

Setting the temperature

1Put the iron on the rubber mat.

C2Set the required ironing temperature by turning the

temperature dial to the appropriate position.

Check the laundry care label for the required ironing temperature:

-1Synthetic fabrics (e.g. acrylic, nylon, polyamide, polyester)

-1Silk

-2Wool

-3Cotton, linen

If you do not know what kind(s) of fabric(s) an article is made of,

determine the right ironing temperature by ironing a part that will not

be visible when you wear or use the article.

Silk, woollen and synthetic materials: iron the reverse side of the fabric

to prevent shiny patches. Avoid using the spray function to prevent

stains.

Start ironing the articles that require the lowest ironing temperature,

such as those made of synthetic fibres.

3Put the mains plug in an earthed wall socket.

4When the amber temperature pilot light has gone out, wait a

while before you start ironing.

The amber pilot light will go on from time to time during ironing.

MAX.

Using the appliance

Steam ironing

1Make sure that there is enough water in the water tank.

2Put the iron on the rubber mat.

3Select the recommended ironing temperature (see chapter

'Preparing for use', section 'Setting the temperature').

C4Select the appropriate steam setting. Make sure that the steam

setting you select is suitable for the ironing temperature

selected:

- 1 - 2 for moderate steam (temperature settings 2to 3)

- 3 - 4 for maximum steam (temperature settings 3to MAX)

BThe iron will start steaming as soon as the set temperature has been

reached.

BJust before the water tank is empty, the iron will normally produce a

burst of steam and some minor spitting may occur.This is a normal

phenomenon related to the electrical pump.

Ironing without steam

1Select the recommended ironing temperature (see chapter

'Preparing for use', section 'Setting the temperature').

Do not squeeze the steam trigger.

Features

Spray function

You can use the spray function to remove stubborn creases at any

temperature.

1Make sure that there is enough water in the water tank.

C2Press the spray button several times to moisten the article to

be ironed.

BWhen the internal reservoir is empty, squeeze the steam trigger for

about one minute to refill it. Refilling is complete when you see or hear

steam coming out from the steam vents in the soleplate.

C◗The internal reservoir must be filled at a temperature setting

between 2and MAX. It is not possible to fill the internal

reservoir at a temperature setting below 2.

ENGLISH10
