Philips CRA01 Manuale utente

Philips

Public Signage cards

Loop Through

CRA01

Loop Through Card for Public Signage

VGA and RS232 loop through card

Philips Smart Cards are designed to expand the possibilities of your Philips Smart Card

Public Signage Monitor BDL3231C/00 or BDL4231C/00

Operational flexibility for different applications

• VGA loop through enables daisy chaining to multiple monitors

• Monitor is network controllable for remote management

Issue date 2009-12-21

Version: 2.3.17

12 NC: 8670 000 33169

UPC: 6 09585 14142 1

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

Specifications

CRA01/00

Public Signage cards

Loop Through

Highlights

Signal loop through

Multiple screen daisy chain effectively distributes

control and visual content from a single source to an

array of monitors in various locations within a site.

Network controllability: RS232

Network controllability allows user to control and

adjust monitors remotely through RS232 protocol.

Connectivity

• PC: RS232 D-Sub9, RS232 D-sub9 output, VGA-in

D-Sub 15HD, VGA-out D-Sub 15HD

Power

• Consumption (On mode): < 2 W

Accessories

• Included accessories: Warranty Leaflet, Quick

start guide, Local RS232 interconnect. cable, Local

VGA interconnect. cable, Plastic end cap

Miscellaneous

• Warranty: Europe: 1 year, North America: 3 years

Packaging dimensions

• Packaging dimensions (W x H x D):

23 x 6.4 x 16 cm

• Packaging dimensions (W x H x D):

9.1 x 2.5 x 6.3 inch

• Net weight: 0.22 kg

• Net weight: 0.485 lb

• Gross weight: 0.33 kg

• Gross weight: 0.728 lb

• Tare weight: 0.11 kg

• Tare weight: 0.243 lb

• UPC: 6 09585 14142 1

• Number of products included: 1

• Packaging type: Carton

Outer Carton

•Outercarton(Lx W x H): 67 x 48 x 26.5 cm

•Outercarton(Lx W x H): 26.4 x 18.9 x 10.4 inch

• Net weight: 5.28 kg

• Net weight: 11.640 lb

• Gross weight: 12.7 kg

• Gross weight: 27.998 lb

• Tare weight: 7.42 kg

• Tare weight: 16.358 lb

• UPC: 6 09585 14892 5

• Number of consumer packages: 24

•
