Phonak myPilot Manuale utente
User Guide
0682 !
2
Contents
Welcome 4
Description 6
myPilot accessories 7
Getting started 8
Charging the battery and general battery info 8
Turning myPilot ON or OFF 10
Keypad lock 11
Operating range 12
Using myPilot 13
Home screen 13
Volume control 14
Program selection 16
Status information 17
myPilot battery status 19
ZoomControl 20
3
Menu functions 22
Menu overview 22
ZoomControl 22
Volume 23
Lock keypad 24
Alarm clock 24
Status information 26
Settings 27
Reset button 32
Important information 33
Maintenance and care 33
Safety notice 34
Important points 35
Troubleshooting 38
iCom (optional) 42
Service and warranty 44
Declaration of conformity 45
Phonak distributors worldwide 46
4
Congratulations on choosing a digital hearing system
from Phonak. Your new myPilot is a very important part
of it. myPilot is an elegant and user-friendly remote
control and status reader which gives you access to all
functions of your digital hearing system. Furthermore,
it guarantees easy management of your hearing
programs with visual confirmation on a state-of-the-
art color display.
You can use myPilot to tune both of your hearing
instruments simultaneously. Or you can control both
hearing instruments individually, allowing you to
perfectly fine-tune your hearing instruments to any
specific hearing situation.
Welcome
5
Please read this manual carefully to benefit from all
the features of your new myPilot. Ask your hearing care
professional if you have any questions.
For further information, please visit the Phonak website
www.phonak.com.
Phonak – life is on
For your safety, carefully read the chapter
Important information on pages 33–41.
6
햳
햴
햵햶
Description
햲ON/OFF button
햳Color LCD display
햴Keypad
Up Volume up
Down Volume down
Right Next program
Left Previous program
Center Menu/select
햵Mini USB
connection
햶Reset button
햲
7
myPilot accessories
• Case
• Lanyard
• Power supply
Contents may vary depending on country.
Charging the battery and general battery info
myPilot has an internal, rechargeable battery.
To charge it, connect the charging cable to myPilot
as shown in the picture below. Then plug the
other end of the charging cable into a power outlet.
Do not use myPilot while charging.
For safety reasons, recharge the battery only
with chargers supplied by Phonak.
8
Getting started
9
During the charging process, the battery symbol on
the Home screen is blinking. Once the battery is fully
charged, the battery symbol will stop flashing and
remain visible.
Charging an empty battery typically takes about
90 minutes. It is safe to leave the charger connected
overnight—the battery cannot be overcharged.
When charging myPilot for the first time, leave
it to charge for five hours, even if the battery
symbol stops flashing.
A new battery’s full performance is achieved only
after two or three complete charge and discharge
cycles.
The myPilot battery can be charged hundreds of
times. If the operating time of your myPilot reduces
substantially, please contact your hearing care
professional.
i
10
Turning ON
To turn myPilot ON,
press and hold the
ON/OFF button for
about a second
until you see the
display turn ON.
Turning OFF
To turn myPilot OFF, press and hold the ON/OFF button
for about two seconds until you see the display turn
OFF.
For optimal convenience it is suggested to keep
myPilot turned on while wearing the hearing
instruments. To avoid unwanted changes of the
hearing instruments settings you can use the
keypad lock. When you turn your hearing
instruments off please also switch off myPilot.
Getting started /
Turning myPilot ON or OFF
i
