Phonak Virto B-Titanium Series Guida all'installazione

Government Services

DALC Training Guide

Spring 2017

Sections:

Hearing Instruments

Features

Apps

Accessories

Roger

Other Resources

If you need any

other assistance

please contact us

at 888-561-7555

Includes Current Contract Phonak Product Families:

Bolero B

Virto B-Titanium

Audéo B

CROS B CROS II

Virto V Accessories

Audéo V Bolero V

Naída V

Government Services

DALC Training Guide

Spring 2017

Hearing Instruments

Fitting Software 1

In-The-Ear Custom Products 2

Receiver-In-Canal Products 6

Behind-The-Ear Products 14

CROS Products 23

Features

Belong Features 41

Venture Features 43

Tinnitus Balance Portfolio 44

Apps

RemoteControl App 47

Accessories

PilotOne II 59

ComPilot II 61

ComPilot Air II 66

DECT II Phone 69

Accessories (continued)

EasyCall II 73

TVLink II 78

RemoteMic 81

Cross Reference/Parts and Pieces 83

Roger

Wireless Technology 86

Roger Pen/EasyPen 87

Roger Clip-On Mic 93

Roger Receivers 97

Replacement Parts 102

Other Resources

Helpful Resource Movies 103

Additional Parts and Accessories 105

Notes Pages 127

Table of Contents:

Phonak VA DALC Training Guide 1

Phonak Target™ 5.1

Fitting software is required to t these devices, and can be downloaded within your existing Target software. If you require

a hard copy, please contact Phonak Customer Service.

Waking up the device

Devices are sent to you in “sleep” mode. To “wake” the devices, simply insert into a charger for 2 seconds. Devices are

shipped with a partial charge. We recommend charging prior to tting.

iCube II

iCube II is required to program these devices. Be sure to turn the devices on (long press of the push button, the LED light

will blink 1x) before connecting to iCube II.

Phonak Audéo™B-R and Bolero B-PR

2 Phonak VA DALC Training Guide

Target 5.1 or higher

Fitting Software

iCube II, NOAHLink, Hi Pro, HI Pro 2, Programming Cables

Interfaces

Phonak CROS w/ iCube

Phonak Virto V Nano, Phonak Virto Q Nano, Phonak Ambra Nano:

• Programming cables, CPC/custom programming codes found in the miscellaneous section, page 3 of ROES digital

hearing aid

Audéo Q 10 RIC, Programming cables

Interface Exceptions

If you need to program hearing instruments outside of the

client’s ears (e.g. to prepare the hearing instruments before a

fitting session), place the hearing instruments on a at surface

and put the neckloop of iCube II around them as shown in

the picture.

Programming Hearing Instruments on your Desk

This training guide only includes materials for active contract products. For prior

contract products, information is available on Phonak Pro (www.phonakpro.com)

under the resource tab. Select literature and then search by product.

Phonak VA DALC Training Guide 3

Virto B-Titanium Product Description

Power level

Hardware configuration / options / technology

Battery size

Push button (for program or volume change)

EasyPhone (for acoustic phone)

MiniControl1(for program or volume change)

Telecoil2

Microphone technology

IP rating

Phonak Virto B90Titanium

•

optional

Omni

IP683

In-The-Ear (ITE) Custom Products

Mild to Moderately-

Severe Hearing Loss

Mild to Severe

Hearing Loss

Mild to Severe

Hearing Loss

Mild to Profound

Hearing Loss

Invisible-In-Canal

(IIC)

Completely-In-Canal

(CIC)

In-The-Canal (ITC)/

Half Shell (HS)

Full Shell

(FS)

1 Only available without push button

2 Will increase size of device

3 IP68 indicates that the hearing aid is water resistant and dust tight. It survived continuous immersion in 1 meter of water for 60 minutes and 8 hours in a dust chamber as per the

IEC60529 standard. No traces of dust were evident within the housing.

4 Phonak VA DALC Training Guide

Power level

Maximum Power Output (dB SPL)

Maximum gain (dB)

Frequency range (Hz)

Working current (mA)

Fitting range

2cc coupler

Ear simulator

2cc coupler

Ear simulator

2cc coupler

109

120

<100 - 7000

0.9

115

125

<100 - 6700

0.9

119

129

<100 - 7000

1.2

For moderate to

severe hearing loss,

all audiometric

configurations

For mild to

moderately-severe

hearing loss, all

audiometric

configurations

For mild to

moderate hearing

loss, all audiometric

configurations

Technical Data

Shell styles

IIC / CIC

Shell color Faceplate color

Colors

BlackTitanium Gray

Phonak VA DALC Training Guide 5

Virto V Product Description

Power level

Hardware configuration / options / technology

Default shell style

Battery size

Push button (program / volume)

Volume control (wheel)

Telecoil

EasyPhone

Microphone technology

Wireless (connectivity & QuickSync)

Binaural VoiceStream Technology™

CROS II Custom compatibility

Phonak

Virto V90 IIC

Phonak

Virto V90 CIC

Phonak

Virto V90 HS

Phonak

Virto V90 FS

•

IIC

•

Omni

•

CIC

•

Omni

•

312 (or 13)

•

Directional

•

13 (or 312)

•

•

Directional

•

Phonak

Virto V90 CA

•

•(312 battery only)

312 (or 10)

•

Optional

•

Directional

•

Virto B Features

Programs (Automatic)

AutoSense OS

Additional programs

Features

FlexControl

FlexVolume

SoundRecover 2

User Preference Tuning

Fine-tuning channels

WhistleBlock

NoiseBlock

WindBlock

EchoBlock

SoundRelax

AOV & AOV-O

Tinnitus Balance

auto Acclimatization

Premium

•

Calm Situation

Speech in Noise

Comfort in Noise

Music

Speech in Car

Comfort in Echo

Max. additional programs

Comfort in Echo

Calm Situation

Comfort in Noise

Music

Acoustic phone

Custom program

6 Phonak VA DALC Training Guide

Virto V Features

Programs (Automatic)

AutoSense OS

Features

UltraZoom

SNR-Boost

FlexControl

FlexVolume

DuoPhone*

SoundRecover

User Preference Tuning

Fine Tuning Channels

WhistleBlock

NoiseBlock

WindBlock

EchoBlock

SoundRelax

QuickSync

AOV

Tinnitus Balance

auto Acclimatization

Premium

•

Premium

•

Calm Situation

Speech in Noise

Comfort in Noise

Music

Speech in Loud Noise*

Speech in Car

Comfort in Echo

*Binaural VoiceStream

Technology™ —

bilateral fitting required

Additional programs (Manual)

Streaming programs

•

Max. additional programs

Speech in Wind*

Comfort in Echo

Speech in Loud Noise*

Speech in 360°*

Speech in Noise

Calm Situation

Comfort in Noise

Music

Acoustic phone

Max. streaming programs

Bluetooth audio + mic

Bluetooth phone / DECT + mic

RemoteMic / Roger

Audio jack

Power level

Maximum Power Output (dB SPL)

Maximum gain (dB)

Frequency range (Hz)

Working current (mA)

Fitting range

2cc coupler

Ear simulator

2cc coupler

Ear simulator

2cc coupler

130

135

<100 - 5200

1.2

112

120

<100 - 7000

1.2

118

125

<100 - 6700

1.1

122

129

<100 - 7000

1.2

For moderate to

profound hearing

loss, all audiometric

configurations

For moderate to

severe hearing loss,

all audiometric

configurations

For mild to

moderately-severe

hearing loss, all

audiometric

configurations

For mild to

moderate hearing

loss, all audiometric

configurations

Technical Data

Colors

Shell colorsFaceplate colors

Tan Cocoa Pink

Red

Transparent

Brown

Blue

Transparent

White Transparent

26 28

2119 36

14 22

Tan

Black

(IIC only)

Brown

Pink

Cocoa

Phonak VA DALC Training Guide 7

Battery Door Virto B 10L

004-2440-061 BLACK

Battery Door Virto B 10R

004-2441-061 BLACK

Battery Door Virto V 10L

004-2440-141 TAN

004-2440-221 COCOA

004-2440-261 PINK

004-2440-281 BROWN

Battery Door Virto V 10R

004-2441-141 TAN

004-2441-221 COCOA

004-2441-261 PINK

004-2441-281 BROWN

Battery Door Virto V 312L

004-2442-141 TAN

004-2442-221 COCOA

004-2442-261 PINK

004-2442-281 BROWN

Battery Door Virto V 312R

004-2443-141 TAN

004-2443-221 COCOA

004-2443-261 PINK

004-2443-281 BROWN

Battery Door Virto V 13L

004-2444-141 TAN

004-2444-221 COCOA

004-2444-261 PINK

004-2444-281 BROWN

Battery Door Virto V 13R

004-2445-141 TAN

004-2445-221 COCOA

004-2445-261 PINK

004-2445-281 BROWN

Battery Door PB Virto V 10L

042-0093-061 BLACK

042-0093-141 TAN

042-0093-221 COCOA

042-0093-261 PINK

042-0093-281 BROWN

Battery Door PB Virto V 10R

042-0094-061 BLACK

042-0094-141 TAN

042-0094-221 COCOA

042-0094-261 PINK

042-0094-281 BROWN

Battery Door Virto Nano L

004-8263-141 TAN

004-8263-221 COCOA

004-8263-261 PINK

004-8263-281 BROWN

Battery Door Virto Nano R

004-8264-141 TAN

004-8264-221 COCOA

004-8264-261 PINK

004-8264-281 BROWN

ITE Battery Doors

8 Phonak VA DALC Training Guide

Virto B-Titanium User Guide

Left & right hearing aid markings

Changing batteries

Blue marking for left

hearing aid.

Red marking for right

hearing aid.

Remove the

sticker from the

new battery

and wait two

minutes.

Left Right

Open the

battery door.

Place battery in the

battery door with the

“+” symbol facing

upwards.

1 2 3

On/O

Push button

Models with this option only:

The push button on your hearing aid

can have various functions.

OOn

The picture below shows the model described in this user guide.

Virto B-Titanium

Custom made

shell

Battery door

Push button

(optional)

Removal handle

Sound outlet / wax protection system

Left & right hearing aid markings

There is a red or blue inlay in the battery door to tell you if it is a

left or a right hearing aid.

Blue marking for left hearing aid.

Red marking for right hearing aid.

On/O

The battery door is also the on/o switch.

Closed battery door = hearing aid is on Opened battery door = hearing aid is o

When you switch on the hearing aid you may hear a start-up melody.

Parts of the Hearing Aid

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Phonak Apparecchio acustico

Phonak

Phonak Cassia Manuale utente

Phonak

Phonak Q90 Manuale utente

Phonak

Phonak microEleva Manuale utente

Phonak

Phonak TVLink II Manuale utente

Phonak

Phonak Perseo Manuale di istruzioni

Phonak

Phonak Roger 02 Manuale di installazione e funzionamento

Phonak

Phonak Dalia Manuale utente

Phonak

Phonak Audeo L-R Series Manuale utente

Phonak

Phonak Dynamic SoundField Manuale utente

Phonak

Phonak roger Manuale utente

Phonak

Phonak Roger Table Mic Manuale utente

Phonak

Phonak ComPilot Manuale utente

Phonak

Phonak Naida S Manuale utente

Phonak

Phonak Phonak Audeo B90-10 Manuale utente

Phonak

Phonak audeo B90-direct Manuale utente

Phonak

Phonak ROGER EARPIECE Manuale utente

Phonak

Phonak PilotOne II Manuale utente

Phonak

Phonak CROS P Manuale utente

Phonak

Phonak Behind-the-Ear hearing aids Manuale utente

Phonak

Phonak Certena Manuale utente

Phonak

Phonak Roger Pen Manuale utente

Phonak

Phonak Roger Touchscreen Mic Manuale utente

Phonak

Phonak Virto V90 Manuale utente

Phonak

Phonak Tactical Wireless PTT AC Manuale utente

Manuali Apparecchio acustico popolari di altre marche

Sonic

Sonic Bliss miniBTE Manuale utente

Lexie

Lexie B1 Manuale elenco delle parti

Widex

Widex FM+DEX Manuale utente

Siemens

Siemens Triano Manuale utente

Camplicomms

Camplicomms HC-200 Manuale utente

Widex

Widex SUPER 220 S2-VSD Manuale utente

Williams Sound

Williams Sound SoundPlus WIR 237 Guida

Oticon Medical

Oticon Medical Ponto SoundConnector Manuale utente

Siemens

Siemens Life micon Manuale utente

Starkey

Starkey Destiny Manuale utente

Audicus

Audicus The Icon Manuale utente

Advanced Bionics

Advanced Bionics Slim HP Standard Manuale utente

Widex

Widex DREAM440 THE DREAM SERIES Manuale utente

NIKEN

NIKEN NK-401 Manuale utente

ON Semiconductor

ON Semiconductor Ezairo 7111 Pre Suite Manuale utente

Sonetik

Sonetik GOHEAR Manuale utente

Widex

Widex FL-9 Manuale utente

Siemens

Siemens MUSIC Pro Pro IT Manuale utente
