phyCORE-LPC2294

QuickStart Instructions

Using Keil's ULINK and the Keil ARM7/µVision3

Software Development Tool Chain

Note: The PHYTEC Spectrum CD includes the electronic version of

the English phyCORE-LPC2292/94 Hardware Manual

Edition: June 2005

phyCORE



-LPC2294 QuickStart Instructions

In this manual are descriptions for copyrighted products that are not explicitly

indicated as such. The absence of the trademark () and copyright () symbols

does not imply that a product is not protected. Additionally, registered patents and

trademarks are similarly not expressly indicated in this manual.

The information in this document has been carefully checked and is believed to be

entirely reliable. However, PHYTEC Messtechnik GmbH assumes no

responsibility for any inaccuracies. PHYTEC Messtechnik GmbH neither gives

any guarantee nor accepts any liability whatsoever for consequential damages

resulting from the use of this manual or its associated product. PHYTEC

Messtechnik GmbH reserves the right to alter the information contained herein

without prior notification and accepts no responsibility for any damages which

might result.

Additionally, PHYTEC Messtechnik GmbH offers no guarantee nor accepts any

liability for damages arising from the improper usage or improper installation of

the hardware or software. PHYTEC Messtechnik GmbH further reserves the right

to alter the layout and/or design of the hardware without prior notification and

accepts no liability for doing so.

Rights - including those of translation, reprint, broadcast, photomechanical or

similar reproduction and storage or processing in computer systems, in whole or in

part - are reserved. No reproduction may occur without the express written

consent from PHYTEC Messtechnik GmbH.

EUROPE NORTH AMERICA

Address: PHYTEC Technologie Holding AG

Robert-Koch-Str. 39

D-55129 Mainz

GERMANY

PHYTEC America LLC

203 Parfitt Way SW, Suite G100

Bainbridge Island, WA 98110

USA

Ordering

Information: +49 (800) 0749832

order@phytec.de 1 (800) 278-9913

sales@phytec.com

Technical

Support: +49 (6131) 9221-31

[email protected] 1 (800) 278-9913

support@phytec.com

Fax: +49 (6131) 9221-33 1 (206) 780-9135

Web Site: http://www.phytec.de http://www.phytec.com

3rd Edition: June 2005

Contents

1 Introduction to the Rapid Development Kit.....................................1

1.1 Rapid Development Kit Documentation ......................................1

1.2 Overview of this QuickStart Instruction.......................................2

1.3 System Requirements ...................................................................3

1.4 The PHYTEC phyCORE-LPC2294...........................................4

1.5 Keil ARM7/µVision3 Software Development Tool Chain..........7

2 Getting Started.....................................................................................9

2.1 Installing Rapid Development Kit Software.................................9

2.2 Interfacing the phyCORE-LPC2294 to a Host-PC...................15

2.3 Downloading Example Code with Philips LPC2000

Flash Utility................................................................................18

2.4 Downloading Example Code with µVision3..............................21

2.4.1 "Blinky".........................................................................22

2.4.2 "Hello"...........................................................................25

3 Getting More Involved......................................................................31

3.1 Creating a New Project and Adding an Existing Source File.....31

3.1.1 Configure the Project Components................................33

3.1.2 Adding Source Files to the Project................................37

3.2 Modifying the Source Code........................................................40

3.3 Setting Options for Flash Target ................................................41

3.4 Building the Project....................................................................52

3.5 Downloading Code into Flash Memory......................................53

4 Debugging...........................................................................................55

4.1 Creating a Debug Project and Preparing the Debugger..............56

4.1.1 Creating a New Project..................................................56

4.1.2 Setting Options for Target.............................................57

4.2 Starting the Debugger.................................................................65

4.3 Keil µVision3 Debug Features ...................................................67

4.4 Using the Keil µVision3 Debug Features...................................69

4.4.1 Breakpoints....................................................................69

4.4.2 Single Stepping and Watch Window.............................70

4.5 Running, Stopping and Resetting...............................................71

4.6 Changing Target Settings for the "Executable Version"............72

phyCORE



-LPC2294 QuickStart Instructions

Index of Figures

Figure 1: Default Jumper Settings of the phyCOREDevelopment

Board HD200 with phyCORE-LPC2294................................15

Figure 2: JTAG Connector X701 on the phyCORE-LPC2294

(Bottom View)...........................................................................16

Figure 3: ULINK Connected to the phyCOREModule .........................17

Figure 4: Power Connector.......................................................................17

Introduction

1Introduction to the Rapid Development Kit

This QuickStart provides:

•general information on the PHYTEC phyCORE-LPC2294 Single

Board Computer (SBC),

•an overview of Keil's ARM7/µVision3 software development tool

chain evaluation version, and

•instructions on how to run example programs on the

phyCORE-LPC2294, mounted on the PHYTEC phyCORE

Development Board HD200, in conjunction with the Philips

LPC2000 Flash Utility for internal Flash, the Keil ULINK and

software tools

Please refer to the phyCORE-LPC2292/94 Hardware Manual for

specific information on such board-level features as jumper

configuration, memory mapping and pin layout. Selecting the links on

the electronic version of this document links to the applicable section

of the phyCORE-LPC2292/94 Hardware Manual.

1.1 Rapid Development Kit Documentation

This "Rapid Development Kit" (RDK) includes the following

electronic documentation on the enclosed "PHYTEC Spectrum

CD-ROM":

•the PHYTEC phyCORE-LPC2292/94 Hardware Manual

•controller User's Manuals and Data Sheets

•this QuickStart Instruction with general "Rapid Development Kit"

description, software installation hints and three example programs

enabling quick out-of-the box start-up of the phyCORE-LPC2294

in conjunction with the Keil ARM7/µVision3 software

development tool chain

phyCORE



-LPC2294 QuickStart Instructions

2© PHYTEC Messtechnik GmbH 2005 L-659e_3

1.2 Overview of this QuickStart Instruction

This QuickStart Instruction gives a general "Rapid Development Kit"

description, as well as software installation hints and three example

programs enabling quick out-of-the box start-up of the

phyCORE-LPC2294 in conjunction with the Keil ULINK and

ARM7/µVision3 software tools. It is structured as follows:

1) The "Getting Started" section uses three examples:

Blinky to demonstrate the download of user code to the internal

Flash device using the Philips LPC2000 Flash Utility

Blinky and Hello to demonstrate the download of user code to

the external Flash device using the Keil ULINK and

ARM7/µVision3 software tools

2) The "Getting More Involved" section provides step-by-step

instructions on how to modify both examples, create and build

new projects and generate and download output files to the

phyCORE-LPC2294 using the Keil tools.

3) The "Debugging" section provides a third example

program - "Debug" - to demonstrate simple debug functions

using the Keil µVision3 debug environment.

In addition to dedicated data for this Rapid Development Kit, the

PHYTEC Spectrum CD-ROM contains supplemental information on

embedded microcontroller design and development.

Introduction

1.3 System Requirements

Use of this "Rapid Development Kit" requires:

•the PHYTEC phyCORE-LPC2294

•the phyCOREDevelopment Board HD200 with the included

DB-9 serial cable and AC adapter supplying 5 VDC /min. 500 mA

•the Philips LPC2000 Flash Utility software

•the Keil ULINK JTAG-USB adapter, not included in the standard

Rapid Development Kit version1

•the PHYTEC Spectrum CD for ARM7

•an IBM-compatible host-PC (486 or higher running at least

Windows95/NT)

For more information and example updates, please refer to the

following sources:

http://www.phytec.com - or - http://www.phytec.de

support@phytec.com - or - support@phytec.de

http://www.keil.com

[email protected]

1: The Keil ULINK is included in the Rapid Development Kit version with the part number

KPCM-023-SK-2294-Keil.

phyCORE



-LPC2294 QuickStart Instructions

4© PHYTEC Messtechnik GmbH 2005 L-659e_3

1.4 The PHYTEC phyCORE-LPC2294

The phyCORE-LPC2294 represents an affordable yet highly

functional Single Board Computer (SBC) solution in sub-miniature

dimensions (60 x 53 mm). It is intended for use in memory-intensive

applications running within a multi-node CAN bus system. The

standard module is populated with a Philips LPC2294 controller.

All applicable data/address lines and signals extend from the

underlying logic devices to two high-density Molex SMT pin header

connectors (pin width is 0.635 mm/25 mil) lining the circuit board

edges. This enables the phyCORE-LPC2294 to be plugged like a

"big chip" into target hardware.

The standard module runs at a 60 MHz internal clock speed

(delivering 50/10 ns instruction cycle) and offers 1 MByte (up to

8 MByte) SRAM and 2 MByte (up to 16 MByte) Flash on-board for

DATA and CODE storage.

The module communicates by means of two RS-232 transceivers,

two (four optional) CAN bus interfaces, and a SMSC LAN91C111

10/100BaseT Ethernet controller which enables implementation of the

module in embedded Internet applications. The

phyCORE-LPC2294 operates within a temperature range of -40°C to

+85°C and requires only a 300 mA power source.

The Keil ARM/µVision3 software tools, in conjunction with the Keil

ULINK adapter, enables easy on-board download of user programs.

Introduction

The phyCORE-LPC2294 offers the following features:

•subminiature Single Board Computer (60 x 53 mm) achieved

through modern SMD technology

•populated with the Philips LPC2294 microcontroller

(TQPF-144 packaging)

•improved interference safety achieved through multi-layer PCB

technology and dedicated Ground pins

•controller signals and ports extend to two 100-pin high-density

(0.635 mm) Molex connectors aligning two sides of the board,

enabling it to be plugged like a "big chip" into target application

•32-bit, demultiplexed bus mode

•max. 60 MHz clock frequency (ca. 50 ns instruction cycle,

external; ca. 10 ns internal Flash)

•1.5 Gbyte external address space

•2 MByte (up to 16 MByte) on-board Flash1

•on-board Flash programming, no dedicated Flash programming

voltage required through use of 3.3 V Flash devices

•1 MByte (up to 8 MByte) RAM on-board, max. 2 MByte at 0 wait

states1

•up to two CAN transceivers (Infineon TLE6250V33)

•RS-232 transceiver for two serial interfaces

•SMSC 91C111 Ethernet controller with configuration EEPROM

•2 kByte (up to 8 kByte) SPI-EEPROM1

•I2C Real-Time Clock with internal quartz (can be battery buffered)

•one operating voltage for core & peripherals, 3.3 V,

typ. < 280 mA

•controller 1.8 V core voltage generated on-board

•additional 5 V operating voltage for CAN transceivers,

typ. <12 mA

•support of LPC2294 single chip mode

1: Please contact PHYTEC for more information about additional module configurations.

phyCORE



-LPC2294 QuickStart Instructions

6© PHYTEC Messtechnik GmbH 2005 L-659e_3

The phyCOREDevelopment Board HD200, in EURO-card

dimensions (160 x 100 mm) is fully equipped with all mechanical and

electrical components necessary for the speedy and secure insertion

and subsequent programming of most PHYTEC phyCOREhigh-

density series Single Board Computers. Simple jumper configuration

readies the Development Board’s connection to the

phyCORE-LPC2294, which plugs into the receptacle contact strips

mounted on the Development Board HD200.

phyCOREDevelopment Board HD200 Technical Highlights

•low voltage socket for supply with regulated input voltage 5 VDC

•additional supply voltages 3.3 VDC or 2.5 VDC

•two DB-9 sockets (P1A, P1B) configurable as RS-232 interfaces

•two additional DB-9 plugs (P2A, P2B) configurable as

CAN interfaces

•simple jumper configuration allowing use of the

phyCOREDevelopment Board HD200 with various PHYTEC

phyCOREhigh-density SBCs

•socket for RJ45 Ethernet transformer module

•one control LED (D3) for quick testing of user software

•2x 160-pin Molex connector (X2) enabling easy connectivity to

expansion boards (e.g. PHYTEC GPIO Expansion Board)

Indice

Altri manuali Phytec Scheda madre

Phytec

Phytec phyCORE-XC161 Manuale utente

Phytec

Phytec phyCORE-LPC2292/94 Manuale utente

Phytec

Phytec phycore i.mx7 Manuale utente

Phytec

Phytec phyCORE-MPC565 Manuale di programmazione

Phytec

Phytec phyBOARD Wega AM335 Series Manuale utente

Phytec

Phytec PCM-995 Manuale utente

Phytec

Phytec phyCORE-i.MX35 Manuale utente

Phytec

Phytec phyCORE-TriCore Manuale utente

Phytec

Phytec phyCORE-i.MX27 Manuale utente

Phytec

Phytec L-1008e.A0 phyCORE-i.MX 8M Plus Alpha Kit Manuale utente

Phytec

Phytec phyFLEX-i.MX 6 Manuale di programmazione

Phytec

Phytec phyCORE-LPC3180 Manuale utente

Phytec

Phytec phyCORE-i.MX 6 Manuale utente

Phytec

Phytec phyBOARD-Wega-AM335x Manuale utente

Phytec

Phytec phyCORE-MPC5200B tiny Manuale di programmazione

Phytec

Phytec phyBOARD-Wega AM335x Manuale utente

Phytec

Phytec kitCON-161CS Manuale utente

Phytec

Phytec phyCORE-AM335x Manuale utente

Phytec

Phytec phyCORE-TC1775 Manuale utente

Phytec

Phytec phyCORE-XC161 Manuale di programmazione

Phytec

Phytec PhyBOARD-Mira i.MX6 Manuale utente

Phytec

Phytec phyCORE-MPC5554 Manuale utente

Phytec

Phytec phyBOARD WEGA-AM335x Manuale utente

Phytec

Phytec phyBOARD-Subra-i.MX6 Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente

Phytec phyCORE-LPC2294 Manuale di programmazione

Manuali Scheda madre popolari di altre marche
