40-725 User Manual

PXI RF Matrix Module

Page (II) RF MATRIX MODULE 40-725

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

RF MATRIX MODULE 40-725

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) RF MATRIX MODULE 40-725

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

RF MATRIX MODULE 40-725

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI Modules ............4.1

Module Architecture 40-725.................................................4.2

Sub-Units 40-725 .................................................................4.3

Programming The Module ....................................................4.4

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting.........................................................................6.1

Section 7

Maintenance Information............................................................7.1

Switching System Test Tools ...............................................7.1

Relay Lookup Tables ............................................................7.1

Component Layout ...............................................................7.3

CONTENTS

Page (VI) RF MATRIX MODULE 40-725

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

RF MATRIX MODULE 40-725

pickering

Page (VII)

REED RELAY MODULE 40-110/115/120/125

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the host chassis are populated with blanking plates to prevent access to user

I/O signals that may be present. Blanking panels are available to order from Pickering in a variety

of slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

anti-static bags.

CAUTION - PRODUCT DOCUMENTATION SYMBOL

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page (VIII) RF MATRIX MODULE 40-725

pickering

THIS PAGE INTENTIONALLY BLANK

Page 1.1

RF MATRIX MODULE 40-725

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI 8x9 RF Coaxial Matrix 40-725

ISSUE 10.3 JUN 2021

Supported by

eBIRST

The 50 Ω version of the 40-725 is supported by eBIRST

switching system test tools. These simplify switching

system fault-ﬁnding by quickly testing the system and

graphically identifying the faulty relay.

For more information go to: pickeringtest.com/ebirst

y8x9 RF Coaxial Matrix

yUp to 500 MHz Bandwidth

y50 Ω and 75 Ω Versions Available

yHigh Quality Ruthenium Reed Relays

yHigh Density SMB Front Panel Mounted

Coaxial Connectors

y75 Ω Version Suitable for Telecoms and High

Quality Video Switching

yVISA, IVI & Kernel Drivers Supplied for

Windows

ySupported by PXI or LXI Chassis

ySelected Builds Supported by

eBIRST

™

y3 Year Warranty

The 40-725 is an 8x9 RF matrix module suitable for

switching frequencies up to 500 MHz. Available in either

50 Ω or 75 Ω versions with SMB coaxial connectors, it is

intended for the easy construction of high performance

bidirectional matrix switching systems.

Automatic isolation switches are located on all X and

Y connections (see diagram below). These can be used

to disconnect the matrix from the external test ﬁxture,

maximizing isolation and RF performance.

MATRIX

CROSSPOINT

ISOLATION

SWITCH

8x9 Coaxial Matrix Schematic Diagram

Other RF Matrix Modules in Pickering’s PXI Range:

40-726A 12x8 300 MHz, 50 Ω/75 Ω - Optional Y Loop-Thru

40-727 16x4 300 MHz, 50 Ω/75 Ω - Optional Y Loop-Thru

40-728 16x2 300 MHz, 50 Ω/75 Ω - Optional Y Loop-Thru

40-729 8x4 300 MHz, 50 Ω/75 Ω - Optional Y Loop-Thru

40-750 8x2 1.5 GHz, 50 Ω/75 Ω - Y Loop-Thru

40-872 single/dual 2x2 3 GHz, 50 Ω

40-832 single/dual 2x2 3 GHz, 75 Ω

45-720A 6U, 16x16 250 MHz, 50 Ω/75 Ω - Y Loop-Thru

Alternative LXI Ethernet Controlled RF Matrices:

60-760 Single/Dual 24x8 25 MHz, 50 Ω

60-711 Single/Dual 24x8 25 MHz, 75 Ω

60-110 Scalable 24x8 to 104x16 200 MHz, 50 Ω

Matrix Operation

The 40-725 is a true 8x9 high density matrix, any

combination of crosspoints may be selected. Only the

signal is switched, all grounds are common.

Page 1.2 RF MATRIX MODULE 40-725

pickering

SECTION 1 - TECHNICAL SPECIFICATION

8x9 RF Coaxial Matrix, 40-725

pickeringtest.com

Speciﬁcations

40-725-511 (50 Ω Version) Insertion Loss Plot to 500 MHz 40-725-511 (50 Ω Version) VSWR Plot to 500 MHz

40-725-511 (50 Ω Version) Crosstalk Plot to 500 MHz 40-725-511 (50 Ω Version) Isolation Plot to 500 MHz

40-725-511 (50 Ω SMB) Perfomance Plots
