PCI Express Gigabit Ethernet Adapter
Quick Installation Guide Version 1.0
Thank you for purchasing PLANET ENW-9702 PCI Express
Gigabit Ethernet adapter. It is a 10/100/1000Mbps
Ethernet adapter for PCI local bus-compliant PCs,
supports Auto-Negotiation for 10/100/1000Mbps
Ethernet connection. The PLANET ENW-9702 PCI Express
Gigabit Ethernet adapter provides a highly cost-effective
solution to upgrading to the Gigabit network with your
existing Ethernet infrastructures.
Operation System Support:
Windows 98 / ME
Windows 2000 / 2003 / 2003R2
Windows XP
Windows Vista
Windows 7
Windows 8
Linux / MAC OS
Hardware Installation
Step 1: Please turn off your PC.
Step 2: Remove any metal decorations from your
hands and wrists.
Step 3: Remove the cover from your PC.
Step 4: Locate an empty PCI Express slot and remove
the corresponding back plate. Save the screw
for use in Step 6.
3. Please select “Browse my computer for driver
software” for next step.
4. Insert the bundled CD into the CD-ROM driver.
Installation on Windows 7
Note
This operation is under Win7, it is similar to
Windows Server 2008.
1. After installing ENW-9702 to your PC and boot up,
Windows 7 will detect it and you have to install
driver.
Package Content
ENW-9702 x 1
Low Profile Bracket x 1
Quick Installation Guide x 1 User’s Manual CD x 1
Step 5: Carefully insert the Gigabit Ethernet Adapter
into the chosen slot and press rmly with
proper push to ensure it is fully seated in the
slot.
Step 6: Secure the Gigabit Ethernet Adapter with the
screw you saved in step 4.
Step 7: Replace the PC cover.
Step 8: Power on your PC and refer to next section to
install driver.
5. Please click “Browse” to specify the driver location
to install. (Assume “E” is your CD-ROM drive, the
driver can be found in E:\ENW-9702\Win_7\64). Click
“Next” to continue.
The driver installs process.
2. Please Move and right click the mouse button for
Ethernet Controller item and select “Update Driver
Software”.
- 9 -
- 10 -
- 11 -
- 12 - - 13 - - 14 -
6. During the driver installation, it will pop up one
Windows Security message. Please Click “Install
this driver software anyway” button for continue
installation.
For more details, please refer to the manual of our
bundle CD-ROM.
7. Click “Close” button to complete the driver
installation.
