Wireless LAN Switch

Key Feature

Data Sheet

The WLS-1280 is a Wireless LAN Switch dedicatedly designed for small /

medium-scale network environment. It enables administrators to effectively

manage different categories of users based on self-defined policies. There

is no need to change any configuration for client devices. The simplified

deployment and administration eases the integration into existing wired

and wireless networks.

With the Access Point (AP) management functions, the WLS-1280 is able

to aggregate up to 12 controlled Access Points. The administrator can

discover, configure, copy from template, update, and monitor all managed

the APs from one single secured interface. Such design avoids the need to

configure the devices one by one.

The WLS-1280 also provides the comprehensive security features. The

authorized end-to-end communication for both wired and wireless

network can prevent anonymous users to occupy the valuable bandwidth.

The local VPN termination with client approach offers the highest level of

wireless security without any hassle.

WLS-1280

Networking

• Supports Router, NAT mode

• Supports dual WAN for fail over, or load balancing

• Controllable LAN ports require user authentication

• Support IP Plug and Play (IP PnP)

• Buillt-in DHCP server and supports DHCP relay

• Supports Walled Garden (free surfing zone)

• Built-in hardware-based VPN accelerator

Security

• Supports 64/128-bit WEP, WPA, and WPA2 data encryptions

• Supports VPN termination of IPSec tunnels

• Supports VPN passthrough

• Supports DoS attack protection

• Supports MAC Access Control List

• Supports User Black List

AP Management

• Manageable APs include WAP-4033/4033PE and WAP-4060PE

• Supports up to 12 managed APs

• Centralized remote management via HTTP interface

• Auto discover managed APs

• Locally maintain configuration profiles for all managed APs

• Single UI for upgrading and restoring managed APs' firmware

• Monitor all managed APs' status and associated client list

• System alarms and status reports on managed APs

Monitor and Report

• Status monitoring of on-line users

• IP-based monitoring of network devices

• Supports Syslog

• User traffic history logging

Accounting and Billing

• Supports RADIUS accounting, RADIUS VSA (Vendor Specific

Attributes)

• Built-in billing profiles for on-demand accounts

• Supports session expiration control

• Provides billing report on screen

• Provides detailed per-user traffic history

User Management

• Supports up to 120 concurrent users

• Provides 500 local accounts and 2000 on-demand accounts

• Supports multiple login methods (POP3, LDAP, RADIUS, NT Domain)

• Role-based and policy-based access control

• Supports monitor IP on 3rd party APs

System Administration

• Customizable login and logout portal page

• SSH remote management

• Console management interface

• Backup and restore system configurations

PLANET reserves the right to change specifications without prior notice. All brand names and trademarks are property or

11-06 C-WLS1280-1

PLANET Technology Corporation

11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan R.O.C.

Tel: 886-2-2219-9518  Fax: 886-2-2219-9528

Email: [email protected] www.planet.com.tw

VoIP Gateway: vip.planet.com.tw

Wireless LAN Switch

WLS-1280

Wireless LAN Switch

Product

Specification

Applications

Ordering Information

Model

Hardware

WAN Ports

LAN Ports

Console Port

LED Indicator

Dimensions (W x D x H)

Weight

Environmental Specification

Power Requirement

Electromagnetic Compatibility

Capacity and Performance

Concurrent User

Local Account

On-demand Account

Managed Access Point

Monitored 3rd Party Access Point

VPN Termination Tunnel

VPN 3DES/DES Throughput

WLS-1280

2 x 10/100Base-TX RJ-45

8 x 10/100Base-TX RJ-45

1 x RJ-11

Power, Status, WAN 1-2, LAN 1-8

243 x 150 x 45.5mm

1.28kg

Operating temperature: 0 - 45 Degree C

Storage temperature: -20 - 70 Degree C

Relative humanity: 0% - 90% (non-condensing)

12V DC, 1.5A

FCC, CE

120

500

2000

120

30Mbps

Cost-effective PoE Wireless LAN

The PLANET WLS-1280 integrates

“user control” - AAA and “wireless

access” - AP management, into one

system. As the topology, the WLS-1280

is set to control both wired and

wireless users in company's Intranet.

The user account information is stored

in the local database or an external

server. User authentication is processed

via SSL encrypted web interface. User

policy based control, including

bandwidth, access control, services

type control, utilize the usage of the

dual WAN interfaces

Data Sheet

WLS-1280

Switch

Built-in Account

Database

Switch

POP3(S)

LDAP

RADIUS

NT Domain

DMZ

App Server

Web Server

Mail Server

WLS-1280

IPSec VPN Encrypted Network

Modem Modem

Managed

Access Point

Failover
