Planet GS-4210 SERIES Manuale utente

L2/L4 Managed Gigabit Ethernet Switch

GS-4210 802.3bt PoE++ Series

Quick Installation Guide

Table of Contents

1. Package Contents ....................................................................................... 3

2. Requirements ............................................................................................. 4

3. Terminal Setup ........................................................................................... 5

3.1 Logging on to the Console.................................................................... 6

 3.2 ConguringIPAddressviatheConsole ................................................. 7

 3.3 StoringCurrentSwitchConguration..................................................... 9

4. Starting Web Management .........................................................................10

 4.1 LoggingintotheManagedSwitch .......................................................10

 4.2 SavingCongurationviatheWeb ........................................................13

5. RecoveringBacktoDefaultConguration.....................................................14

6. Customer Support .....................................................................................16

1. Package Contents

Thank you for purchasing PLANET L2/L4 Managed Gigabit Ethernet Switch. The

descriptionsofthisseriesareshownbelow:

GS-4210-8HP2T2S

4-port10/100/1000T802.3btPoE+4-port10/100/1000T

802.3atPoE+2-port10/100/1000T+2-port100/1000X

SFPManagedSwitch

GS-4210-8HP2S 2-port10/100/1000T802.3btPoE+6-port10/100/1000T

802.3atPoE+2-port100/1000XSFPManagedSwitch

GS-4210-16UP4C 16-port10/100/1000T802.3btPoE+4-portGigabitTP/SFP

ComboManagedSwitch

GS-4210-24UP4C 24-port10/100/1000T802.3btPoE+4-portGigabitTP/SFP

ComboManagedSwitch

GS-4210-24HP2C

4-port10/100/1000T802.3btPoE+20-port10/100/1000T

802.3atPoE+2-portGigabitTP/SFPComboManaged

Switch

“Managed Switch” mentioned in this Quick Installation Guide refers to the above

models.

Open the box of the Managed Switch and carefully unpack it. The box should

containthefollowingitems:

ModelName

PackageItem

GS-4210-

8HP2T2S

GS-4210-

8HP2S

GS-4210-

16UP4C

GS-4210-

24UP4C

GS-4210-

24HP2C

TheManagedSwitch 

QuickInstallation

Guide 

RS-232 to RJ45

Console Cable 

Rubber Feet 

Two Rack-mounting

Bracketswith

AttachmentScrews



PowerCord 

SFPDustCaps 22442

If any item is found missing or damaged, please contact your local reseller for

replacement.

2. Requirements

zWorkstationsrunningWindows XP/2003/2008/Vista/7/8/10,MACOS Xorlater,

Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPprotocols.

zWorkstationsareinstalledwithEthernet NIC(NetworkInterfaceCard)

zSerial Port Connection(Terminal)

 The above Workstations come with COM Port (DB9) or USB-to-RS-232

converter.

 TheaboveWorkstationshavebeeninstalledwith terminal emulator, suchas

HyperTerminalincludedinWindowsXP/2003,puttyorteraterm.

Serial cable--OneendisattachedtotheRS-232serialport,whiletheother

endstotheRJ45typeconsoleportoftheManagedSwitch.

zEthernetPortConnection

Network cables --Usestandardnetwork(UTP)cableswithRJ45connectors.

 TheabovePCisinstalledwithWeb browser.

Note

It is recommended to use Internet Explorer 8.0 or above to access

theManagedSwitch.

If the Web interface of the Managed Switch is not accessible,

please turn off the anti-virus software or firewall and then try it

again.

3. Terminal Setup

TheManagedSwitchisequipped withaconsoleinterface for localswitchsetupand

maintenance. To congure the system, connect a serial cable to a COM port on a

PCornotebook computerandto theRJ45type oftheconsole portofthe Managed

Switch.

Managed Switch

PC / Workstation

with

Terminal Emulation Software

Serial Port

RS232 to RJ45 Cable

Console Port

RJ45

Figure 3-1: Managed Switch Console Connectivity

A terminal program is required to make the software connection to the Managed

Switch.

1. Run terminal program on the OS.

2.When the following screen appears, make sure that the COM port should be

conguredas:

zBaud:115200

zDatabits:8

zParity:None

zStopbits:1

zFlowcontrol:None

3.1 Logging on to the Console

Once the terminal is connected to the device, power on the Managed Switch and

the terminal will display “running testing procedures”. Then, the following message

asks to log in user name and password. The factory default user name and

passwordareshownasfollows,andtheloginscreeninFigure3-2appears.

Username:admin

Password:admin

Figure 3-2: Managed Switch Console Login Screen

The user can now enter commands to manage the Managed Switch. For a detailed

descriptionofthecommands,pleaserefertothefollowingchapters.

Note

1.For security reason, please change and memorize the new pass-

wordafterthisfirstsetup.

2.Only accept command in lowercase letter under console inter-

face.

3.2 ConguringIPAddressviatheConsole

TheManagedSwitchisshippedwithdefaultIPaddressasfollows:

IPAddress: 192.168.0.100

SubnetMask:255.255.255.0

To check the current IP address or modify a new IP address for the Switch, please

usetheproceduresasfollows:

ShowingthecurrentIPaddress

1.Atthe“GS-4210 Series#”prompt,enter“show ip”.

2.Thescreendisplays the currentIPAddress, SubnetMaskand Gatewayas shown

in Figure 3-3.

Figure 3-3: IP Information Screen

ConguringIPaddress

3.Atthe“GS-4210 Series#”prompt,enter“congure”.

4.At the “GS-4210 Series(cong)#” prompt, enter the following command and

press <Enter> as shown in Figure 3-4.

GS-4210Series(cong)# ip address 192.168.1.100 mask 255.255.255.0

GS-4210Series(cong)# ip default-gateway 192.168.1.254

ThepreviouscommandwouldapplythefollowingsettingsfortheSwitch.

IP Address: 192.168.1.100

Subnet Mask: 255.255.255.0

Gateway: 192.168.1.254

Figure 3-4: IP Address Screen

5.RepeatStep1tocheckiftheIPaddresshaschanged

If the IP is successfully congured, the Managed Switch will apply the new IP

address setting immediately. You can access the Web interface of the GS-4210

ManagedSwitchSeriesthroughthenewIPaddress.

3.3 StoringCurrentSwitchConguration

In the Managed switch, the running conguration le is stored in the RAM. In the

currentversion, therunning congurationsequence ofrunning-cong can besaved

fromthe RAMtoFLASHby writingthe command orcopying the running-cong

startup-cong command, so that the running conguration sequence becomes

thestartupcongurationle,whichisthecongurationsaved.

1.At the “GS-4210 Series#” prompt, enter “copy running-cong startup-

cong” as shown in Figure 3-5.

Figure 3-5: Storing Current Conguration Command Screen

Note

If you are not familiar with console command or the related para-

meter,enter“?”anytimeinconsoletogetthehelpdescription.

4. Starting Web Management

The following shows how to start up the Web Management of the Managed

Switch. Note the Managed Switch is congured through an Ethernet connection.

Please make sure the manager PC must be set to the same IP subnet address.

For example, the default IP address of the Managed Switch is 192.168.0.100,

then the manager PC should be set to 192.168.0.x (where x is a number

between1and254,except100),andthedefaultsubnetmaskis255.255.255.0.

PC / Workstation

with Web Browser

192.168.0.x

Managed Switch

RJ45/UTP Cable

IP Address:

192.168.0.100

Figure 4-1: IP Management Diagram

4.1 Logging in to the Managed Switch

1.Use Internet Explorer 8.0 or above Web browser and enter IP address

https://192.168.0.100toaccesstheWebinterface.
