Plantronics BackBeat 903+ Manuale utente

LEARN

BackBeat™903+

Bluetooth®Headphones

TAKE A GOOD LOOK

CALL BUTTON

• Takeacallorendit (1 tap)

• Redial(2 taps)

• Initiatephone’svoice-dialing(2-second

press until tone is heard)

• ReconnectlostBluetoothconnection

(1 tap if the headphones don’t automatically

reconnect)

• CancelmissedcallLED(1 tap)

• Rejectacall(2-second press)

• Transfercallto/fromphone 

(during call, 2-second press)

• Enable/disableon-a-callLED(while

powered on, 2-second press Call and

Volume up buttons)

MICRO USB CHARGING PORT

• UsewiththeACcharger:

1 hour before ﬁrst use

3 hours (100% charge)

• Donotuseheadphoneswhilecharging

VOLUME/TRACKING BUTTONS

• Volumeup/down(1 tap per level change)

• Trackforward/back(2-second press per

track change)

• Enable/disableOpenMic™(3-second press

Call and Volume down buttons)

LED

• Charging(solid red)

• Fullycharged(brief solid blue ﬂash)

• Lowbattery(2 red ﬂashes every

15 minutes)

• Onacall(blue ﬂash every 2 seconds

while on a call)

• Missedcall(3 purple ﬂashes repeating

for 5 minutes or until cancelled)

• Pairingmode(repeating red/blue

ﬂashes)

MUSIC BUTTON

• Play/pause (1 tap)

• Bassboost(2-second press)

• Mutemusicorcall(1 tap)

• UseOpenMic™topausemusic

andactivatemic(1 tap)

POWER/PAIRING BUTTON

• On/off(2-second press to turn

on, 4-second press to turn off)

• Activatepairingmodeafter

initialsetup(press until

red/blue LED ﬂashes)

• Checkbatterylevel(1 tap)

Besafe!Pleasereadthesafety

guideforimportantsafety,charging,

batteryandregulatoryinformation

beforeusingyournewheadphones.

CONNECT TO YOUR PHONE

“Pairing” connects your

headphones to your phone.

It is a one-time process

unless your phone loses

the connection or you want

to pair to a new phone.

1. READY

Activate the Bluetooth feature

on your device, then get it to

add / search for / discover new

Bluetooth devices.

Phoneshavedifferentmenus

toselectfrom:

iPhone: Settings > General >

Bluetooth > On

(starts the search for devices)

BlackBerry®smartphone:

Settings/options >

Bluetooth: On >

Search for devices

2. SET

Firsttime,rightoutofthebox:

With headphones turned off,

activate Bluetooth pairing mode

by pressing Power/Pairing button

for 2 seconds. The LED ﬂashes

red/blue to indicate pairing mode.

Pairingnewphone/reconnecting

original:

With headphones turned off, press

Power/Pairing button until the LED

ﬂashes red/blue.

3. CONNECT

Select “PLT_BB903+” from the list

of Bluetooth devices shown on

your device.

If device asks for a passcode, enter

four zeros (0000). You may see

**** on screen.

Some devices also ask to conﬁrm

connection after pairing.

The headphones’ LED will

stop ﬂashing red/blue once

successfully paired/connected.

You can now make a call using

your device’s keypad or voice-

dialing feature.

PLT_BB903+

ADJUST THE FIT

For the best sound performance and a secure, comfortable

ﬁt, be sure to adjust the headphones to rest gently in your

ear and drape around the back of your neck.

1. Drape the stereo cable behind your neck.

2. Guide one earpiece behind your ear and secure the

eartip inside your ear using the telescoping/swivel

adjustments.

3. Repeat step 2 with the other earpiece and continue

to adjust the ﬁt in each ear until both eartips rest

comfortably and securely in your ears.

LISTEN TO THE VOICE

WHAT YOU’LL HEAR WHEN YOU’LL HEAR IT

Listeningtime:(5hrs,

4hrs,3hrs,2hrs,1hr)

After 2-second press of the Power button to turn on power

or after a short press during music play

Batterylow When you have approximately 30 minutes left before the

battery must be recharged

Rechargebattery When you have approximately 10 minutes left before the

battery must be recharged

Connected After pressing the Power button to turn on power or to

reconnect a dropped Bluetooth connection

Incomingcall As an incoming call rings to your phone

Trackforward/back After 2-second press of either track forward + or track

backward – button

Muteon After tapping the Music button during a call

Muteoff When on mute during a call, after tapping the Music

button

Lostconnection When the phone loses the Bluetooth connection with the

headphones

These headphones whisper various

status alerts when you power on/off,

run low on listening time, or lose/

reconnect the Bluetooth connection

to your phone.

TIPS

Make calls with voice dialing:

Your headphones can work with

your phone’s voice dialing feature.

Press the Call button for 2 seconds

and listen for the low tone. Your phone

may prompt you by saying something

like “Name Please.” Check your phone’s

documentation for details.

Hear what’s going on around you:

Your headphones use the OpenMic™

feature to pause the music when

you want to hear your surroundings

or have a quick chat with someone

nearby. To use this feature, tap the

Music button once, then tap it again

when you are ﬁnished and want to

resume music play.

To disable this feature, press the

Call and Volume down buttons for 3

seconds (you will hear a low-high-low

set of tones). To re-enable it, press the

Call and Volume down buttons for 3

seconds (you will hear a high-low-high

set of tones).

Check the battery level:

If you are on a call or listening to

music and hear 3 high tones then you

have under 10 minutes of listening

time remaining.

At other times, you can check the

battery level by tapping the Power

button. The headphones will say

how many hours of useage remain.

The LED also ﬂashes red to show

the battery level.

1 ﬂash = more than 2/3 full

2 ﬂashes = 1/3 – 2/3 full

3 ﬂashes = less than 1/3 full

Stay near your device:

Bluetooth has a working “range” of up

to 10 meters (33 feet) between the

device and headphones before audio

degrades and the connection is lost.

For best audio reception, keep your

device on the left side of your body.

Know how to reconnect:

Your headphones try to reconnect

a lost Bluetooth connection. If they

can’t, then tap the Call button once

or manually reconnect via the device’s

Bluetooth menu.

SPECIFICATIONS

Talk/listeningtime Up to 7 hours

Standbytime Up to 7 days

Operatingdistance(range) Up to 10 meters (33 feet) from device

Headphonesweight 34 grams

Headphonesdimensions L x W x H = 330 mm x 20 mm (at widest point of

earpiece) x 57 mm

Chargeconnector Micro USB charging

Batterytype Rechargeable, non-replaceable Lithium ion polymer

Chargetime(maximum) 3 hours

Powerrequirements 5V DC – 180 mA

Bluetoothversion 2.1 + Enhanced Data Rate (EDR) and eSCO data packet

transfer

Bluetoothproles Supports Advanced Audio Distribution (A2DP), Audio/

Video Remote Control (AVRCP), Hands-free (HFP) v1.5

and Headset (HSP) v1.1

Operating,storageand

chargingtemperature

0 – 40°C (32°F – 104°F)

NEED MORE HELP?

Plantronics Ltd

Wootton Bassett, UK

Tel: 0800 410014

+44 (0)1793 842443*

Czech Republic

+44 (0)1793 842443*

Danmark

Tel: 80 88 46 10

Plantronics GmbH

Hürth, Deutschland

Kundenservice:

Deutschland 0800 9323 400

Österreich 0800 242 500

Schweiz 0800 932 340

Για περισσότερες

πληροφορίες:

+44 (0)1793 842443*

Plantronics Iberia, S.L.

Madrid, España

Tel: 902 41 51 91

Finland

Tel: 0800 117095

Plantronics Sarl

Noisy-le-Grand

France

Tel: 0800 945770

Plantronics BV

Regus House

Harcourt Centre

Harcourt Road

Dublin 2, Ireland

Service ROI: 1800 551 896

:רתאב רקב ,ףסונ עדימל

+44 (0)1793 842443*

További információk:

+44 (0)1793 842443*

Plantronics Acoustics

Italia Srl, Milano, Italia

Numero Verde: 800 950934

Plantronics B.V.

Hoofddorp, Nederland

NL 0800 7526876

BE 0800 39202

LUX 800 24870

Norge

Tel: 80011336

Aby uzyskać więcej informacji:

+44 (0)1793 842443*

Portugal

Tel: 0800 84 45 17

Pentru informaţii

+44 (0)1793 842443*

Дополнительная

информация:

+44 (0)1793 842443*

Sverige

Tel: 0200 21 46 81

Daha fazla bilgi için:

+44 (0)1793 842443*

ﬂ

*Support in English www.plantronics.com

Safety information:

see the separate “For Your Safety” booklet

2-year limited warranty details:

www.plantronics.com/warranty

NEED MORE HELP?

Plantronics B.V.

Scorpius 140

2132 LR Hoofddorp

Netherlands

www.plantronics.com

are trademarks or registered trademarks of Plantronics, Inc. Bluetooth is a registered

trademark of Bluetooth SIG, Inc. and any use by Plantronics is under license. iPhone is

a trademark of Apple, Inc., registered in the U.S. and other countries. Blackberry is the

property of Research In Motion Limited and is registered and/or used in the U.S. and

countries around the world. All other trademarks are the property of their respective

owners. Patents US D619561; China ZL200930192537.2; EM 001142582-002; Taiwan

D135150; Patents Pending

AM84445-03 (11/10)

AE11

EEE Yönetmeliğine Uygundur
