Polaroid P-500 - Color Manuale utente

P-500 Digital Photo Printer

User Guide

Table of Contents

User’s Guide

P–500

Table of Contents

Kit Contents 1

Things You Should Know 2

Printer Features 3

Control buttons 3

Display panel 3

Side panel 3

Inserting the Shoulder Strap 4

Loading the Film Pack 4

Printing Digital Photos 6

Inserting the memory card 6

Setting the Print Queue 6

Tagging Images 8

Editing the Print Queue 10

Clearing the Print Queue 10

Troubleshooting 11

Printer does not function at all 11

Printer does not print when I press Print 11

Some images printed, but then the

printer stopped 11

There is a problem with the memory card 12

There is a problem with the print queue 12

The printer is inoperable 12

Display Panel Messages 13

General 13

Memory Card 13

Film Errors 14

FCC Notice 15

Precautions 16

Printer Precautions 16

Film Precautions 16

Polaroid Customer Support 17

One Year Limited Warranty 17

EMC Statement (Europe) 17

Specifications 18

P500_UGTOC_Final.fm Page 1 Wednesday, October 18, 2000 12:22 PM

Kit Contents

User’s Guide

P–500

Kit Contents

The

Polaroid P-500 Digital Photo Printer

prints photos taken with your digital camera.

P-500

Digital Photo Printer

b Shoulder Strap

c User’s Guide, Quick Reference/Label,

Registration Card

d Polaroid 500 Instant Film

Select

copy

count

Press

OK.

Print.

Press

print.

Insert

memory

card.

Turn on

printer.

Select


number

Press

OK to

move to

copies field.

Select

continue.

Select

Cancel

to ignore.

Press OK

to confirm.

Press Print

to print all.

Note: DPOF and Lock

tags are removed

after printing.

Select 


Select 

copies

Film

count

Print

queue

Activity

indicator

To Select Images and Copies To Print Tagged Images

(when printer asks:

"Print tagged Files?")

Power

Status

P500_UG_Final.fm Page 1 Wednesday, October 18, 2000 4:21 PM

Things You Should Know

User’s Guide

P–500

Things You Should Know

•

About removable memory cards

. The P-500

prints photos taken with most digital cameras

using CompactFlash Type I & II or SmartMe-

dia

memory cards. The P-500 supports JPEG

image ﬁles created by most digital cameras.

•

About the print queue

.The print queue is the

sequence of images you select for printing.

•

About DPOF

. Your digital camera may have an

advanced feature that allows you to tag

selected images for printing. When you trans-

fer the memory card to the P-500, you can print

the tagged images without having to set the

print queue. This guide refers to this feature as

DPOF

(digital print order format). Your camera

manual may use another term such as

print set

direct print select

. See

Tagging Images

on (page 8).

•

About Lock.

Your digital camera may have a

lock feature that allows you to protect images

from being deleted. When using

Lock

, an icon

such as a key or check mark identiﬁes these

images. You may use the lock feature to tag

images for printing with the P-500. If both DPOF

and locked images are on the memory card,

locked tags are ignored. See

Tagging

Images

on (page 8).

•For best quality photos, set your camera to the

highest resolution when taking pictures.

•For best results, use the printer at tempera-

tures above

F (13°C)

•Fill out and mail in your registration card. Sign

up for a free online account to create and store

images at:

www.PolaroidDigital.com.

P500_UG_Final.fm Page 2 Wednesday, October 18, 2000 4:21 PM

Printer Features

User’s Guide

P–500

Printer Features

Control buttons

a On/Off

b Arrows/Select

c OK/Conﬁrm

d Print

Display panel

The display panel

indicates printer status.

e Image number

f Copy count

g Film

count

h Power indicator

i Print queue

Side panel

j Card eject button

k Memory card slot

l Film compartment door

abc d

feg

klj

P500_UG_Final.fm Page 3 Wednesday, October 18, 2000 4:21 PM

Inserting the Shoulder Strap

User’s Guide

P–500

Inserting the Shoulder Strap

Insert strap as shown.

Push through and attach to other end.

Loading the Film Pack

Your printer uses Polaroid 500 instant

ﬁlm. The ﬁlm pack contains the bat-

tery power for the printer.

Open the ﬁlm compartment as

shown.

P500_UG_Final.fm Page 4 Wednesday, October 18, 2000 4:21 PM

Loading the Film Pack

User’s Guide

P–500

Slide the ﬁlm pack carefully, ﬁlm-side up,

within the metal guides as shown.

Close the ﬁlm compartment door.

Press and hold . The ﬁlm cover ejects.

Each time the ﬁlm door opens, the ﬁlm

count resets to 10. If you insert a par-

tially used ﬁlm pack, the count will be

inaccurate.

You should have enough battery power to print a

full ﬁlm pack. When the power level shows only

the two smallest bars you have a limited time

to print your images.

To conserve battery life, the printer shuts down

after several seconds of inactivity. To reactivate

the printer press and hold . The printer

retains your selections.

P500_UG_Final.fm Page 5 Wednesday, October 18, 2000 4:21 PM

Printing Digital Photos

User’s Guide

P–500

Printing Digital Photos

Inserting the memory card

Use the printer display panel to select images

and that you want to print before or after insert-

ing the memory card.

Slide open the memory card slot door. Insert

the card, label-side up, into the slot.

Note

: SmartMedia requires an adapter. Insert

the card into the adapter, and then the

adapter into the printer

Setting the Print Queue

Press and hold .

Note

: The printer detects DPOF or Locked

images, if any are present, and sets the

print queue. To ignore this feature

select

Cancel

. For more information

see

Tagging Images on page 8

The Image Number (

) displays

000

a b

P500_UG_Final.fm Page 6 Wednesday, October 18, 2000 4:21 PM

Printing Digital Photos

User’s Guide

P–500

The ﬁlm count (

) displays the frames avail-

able. You can program as many images as

there are frames.

Select the image number you want.

Press .

The Copies (

) ﬁeld becomes active.

Choose the number of copies you want.

The default number is 1.

Press .

The print queue (

) displays the image num-

ber. As you select more images, the ﬁlm count

shows the remaining frames available. You can

queue more than four images, however the

print queue displays the last images entered.

Press .

Each photo prints in several seconds.

Printing continues until the queue or the ﬁlm

pack is empty.

P500_UG_Final.fm Page 7 Wednesday, October 18, 2000 4:21 PM

Printing Digital Photos

User’s Guide

P–500

Tagging Images

You can select images for printing without set-

ting the print queue using your digital camera’s

DPOF or Lock feature. Refer to your camera

manual for details.

Note

: If you want multiple copies of a locked

image, set the print queue.

Using your camera’s LCD (liquid crystal dis-

play), tag the images you want to print with

either the DPOF or Lock feature.

Remove the memory card from your camera.

Slide open the memory card slot door. Insert

the card, label-side up, into the slot.

Note

SmartMedia requires an adapter. Insert

the card into the adapter, and then the

adapter into the printer

Press and hold .

The printer detects tagged image ﬁles.

The P-500 alerts you that it detects DPOF or

Locked images. You may continue with, or

ignore, this method of printing. The default

setting is to continue to print tagged images.

P500_UG_Final.fm Page 8 Wednesday, October 18, 2000 4:21 PM
