Polycom RealPresence Group Series Istruzioni per il montaggio

Place a Video Call

Entering a Name or Number

1Select from the Home screen, or just start

entering the number on the remote control.

2Enter the IP address, SIP address, or H.323

name. Include the dots in an IP address. To

enter text, use the onscreen keyboard.

3Select Call or press on the remote control.

Using Contacts

1Select > Place a Call > Contacts.

2Highlight the contact you want to call. You can

navigate to the contact or use the Search field.

3Select Call or press on the remote control.

Using Recent Calls

1Select > Place a Call > Recent Calls.

2Highlight the entry you want to call.

3Select Call or press on the remote control.

Using Speed Dial

To call a speed dial contact from the Home screen,

highlight it and press on the remote control.

Using the Calendar

If your system is configured to use the Calendar

widget, you can join a video meeting by clicking the

meeting in the Calendar.

Answer a Call

Select Answer or press on the remote control.

End a Call

1Press on the remote control.

2If prompted, confirm that you want to hang up.

Mute Your Microphone

Press on the remote control or on the table

microphone.

Enter letters or numbers

In camera control mode, move the

camera to a stored preset

In camera control mode, press and

hold a number to store a preset

Place or answer a call

For more information about setting up and using the system, refer to the Support pages at support.polycom.com.

Decrease the speaker volume

Display the Menu screen

Press Menu, then Select, to turn the

last used Content source on or off

Zoom the camera out

Mute a microphone

Delete letters or numbers or go

back to a previous screen

End or reject a call

Select button - Select

highlighted menu item

Navigate through menu items using

the Up, Down, Left, and Right buttons;

pan/tilt the camera

Return to the Home screen

Zoom the camera in

Increase the speaker volume

Quick Tips for the Polycom RealPresence Group Series

Generate touch (DTMF) tones

Quick Tips

for the

Polycom®RealPresence®

Group Series

www.polycom.com |3725-63709-001/A | November 2012

sociated with Polycom’s products are trademarks and/or service marks of

Polycom, Inc., and are registered and/or common-law marks in the United

States and various other countries.

Power the System On and Off

•To power on the system, press on the remote

control or the power sensor on the front of the

system.

•To power off the system, press and hold on

the remote control or the power sensor on the

front of the system for 3 seconds. Wait 15 seconds

before you unplug the power cord.

Tips and Tricks

•Make sure you know the name or number of the

site you want to call.

•Connect and test any additional equipment before

the meeting.

•Avoid wearing bright colors, all-light or all-dark

clothing, or “busy” patterns. Light pastels and

muted colors look the best on the screen.

•Adjust your camera so that the far site can see you.

Fill the screen with people rather than with the

table, chairs, walls, lights, or floor.

•Adjust your microphone so that the far site can

hear you. Mute the microphone before moving it so

that the far site doesn't hear you moving it.

•Make sure that you can see and hear the far-site

participants.

•Introduce all participants when the meeting starts.

•Speak in your normal voice without shouting. Use

natural gestures when you speak.

•Don’t tap on the microphone or rustle papers near

the microphone. In a multipoint call, mute your

microphone when you are not speaking.

Place a Multipoint Call

•Place a call, then press on the remote

control or select , and then select Add a Call

to place a call to the next site. Repeat until all

sites are connected.

•Call a group from the Contacts.

•Call one or more sites, and then ask those sites

to call additional sites.

Adjust the Volume

Press or on the remote control.

Add to the Favorites List

•In the local interface, go to Place a Call >

Contacts. Select Search and use the onscreen

keyboard to find the desired entry. Highlight the

entry and select Favorite.

•In the web interface, go to the Manage Favorites

page. Click Add from Directory, and then search

for the person to add and select Save.

•You can also create a Favorite in the web

interface. On the Manage Favorites page, click

Create New Favorite, and then complete the

fields and click Save.

Select or Adjust a Camera

•While in a call, select > Cameras and select

either Your Cameras or Their Cameras. The

menu disappears and a message displays,

telling you which camera you are controlling.

•To switch between Your Cameras and Their

Cameras without accessing the menu, press

Select on the remote control while in a call.

•To pan or tilt the selected camera, press the left,

right, up, and down navigation buttons on the

remote control.

•To control cameras without accessing the menu,

press or .
