* SoundStation VTX 1000 integration not available in all countries.

Contact your Polycom representative for availability.

Audio

G.722.1 Annex C (based on Polycom

Siren™ 14)

•14 kHz crystal clear, wideband audio, while only using 24-48 Kbps

of bandwidth, depending on the data rate of the call

•Eliminates fatigue associated with straining to hear every word

•Near CD-quality sound for dynamic audio performance

•Superb clarity to hear the subtleties of every word

•Rated the best audio algorithm in the industry; outperforming

MPEG4 in all tests

•Included with every VSX system

•For more detailed information, see www.polycom.com/siren14

Polycom StereoSurround™ •2 channels of 14 kHz crystal clear audio

•Superb clarity to hear the subtleties of every word

•Easily decipher multiple, simultaneous conversations

•Distinguish which side of the room people are talking from, just

like in a real meeting

SoundStation VTX 1000® Integration* •Use the SoundStation VTX 1000 as the microphone for the video

system, as well as a standalone audio conferencing phone, and

eliminates the VSX tabletop microphone array

•Add POTS voice-only callers to a video conference with the

SoundStation VTX 1000

•Maximize the value of audio and video equipment investments

when used together

•Remarkable voice pickup range with the SoundStation VTX 1000

microphones - you can additionally use the SoundStation VTX

1000 extension microphones for even greater pickup

•Video dial, mute, call hangup and call redial from the

SoundStation VTX 1000 keypad

•Upgrade an audio call between SoundStation VTX 1000

integrated with your VSX to video by simply pressing one button

•Supports StereoSurround

VSX Microphone Array •360° audio pickup

•Padded feet filter out table-top noise

•Sensitive enough to pick up whispers, smart enough to eliminate

unwanted background noise

•Versatile and attractive design for table top, wall or ceiling mount

•Only one VSX microphone array needed to support

StereoSurround

•Gated enhanced stereo pickup

Audio Error Concealment •Reduced audio drop-out on noisy networks

•Smooth, consistent verbal communications without interruptions

•Corrects audio from any system seamlessly

•Activates automatically, only when needed

Direct POTS Connection •Easily add a telephone to any video call

•Users on a cell phone can call directly into the video conference

•Expands the usability of the system to include IP, ISDN, SIP or

POTS callers

Polycom

VSX™ 7000e

Features and Benefits

Video

H.264 Video •Use less bandwidth to conduct video calls of equal quality

compared to calls using the H.263 standard

•Unparalleled video quality for lower line rate applications

•More bandwidth is available for other business

•Cost savings to any organization

•Supported at data rates from 64Kbps to 768Kbps

Pro-Motion™ H.263 •Full-screen, TV-like video quality with fluid, precise motion

handling

•Greater image detail with 50/60 fields per second

•Most natural video communications experience possible

Single Monitor XGA Support •Use a XGA display for main display

•Clearly see both the presenter and the content on a single display

up to XGA resolution

•Flexibility in configuration, allowing users the display of their

choice

•Supports up to 1024 x 768 resolution

Support for 16:9 or 4:3 Format •User selectable display format

•16:9 aspect ratio with Dual Monitor Emulation is perfect for plasma

displays

•High resolution graphics displays for content presentation

•Option to zoom video to fit the 16:9 display

Video Error Concealment •Reduced video drop-out on noisy networks

•Smooth, continuous video without interruptions

•Maintain active face-to-face contact

•Accomplish meeting objectives without worrying about the video

integrity

•Activates automatically, only when needed

Content Sharing

People+Content™, H.239 •Polycom People+Content or standards based H.239 ensures

interoperability in the industry

•Dual images allows the far end to see the presentation and the

speaker at the same time

•ImageShare II is available for easy control and table top

connection of laptops or connect directly to the codec

•Perfect for outside speakers/visitors to be able to easily add

content to a video conference; just plug in a PC directly to the

7000e and start sharing!

People+Content IP •Simply input the IP address of your VSX 7000e into a small utility

and PC content is easily shown to all conference participants

•This feature can be used by anyone in the conference, even

voice-only participants!

Adjustable Bandwidth for Content •Choose the amount of bandwidth to dedicate to Content or People

•Options include 90% Content/ 10% People; 50% Content/ 50%

People; 10% Content/ 90% People

•User adjustable setting can be accessed both during a call and

outside of a call

Dedicated VCR/DVD Connection •Ability to use line level inputs for other devices

•Easily play VCR/DVD movies/images during a video conference

•Adds another dimension to the conference, making it like “being

there”

•By setting it to content input you can see both the speaker and the

DVD/VCR image

Multiple Content Sources

•Second camera source (i.e. doc camera/VCR/DVD) images can

be seen as content, along with people

•Now all sources of content (PC, 2nd camera, VCR, etc.) can show

up on the second screen/monitor – they never displace the

person/group speaking

•Supplement video conference with multiple types of content

including pictures, documents, audio files, presentations

•Flexible bandwidth settings for adjusting people and content

User Interface

Support for API Control Commands

•Custom control touch panel integration including AMX®or

Crestron®is made easy with extensive support for API command

set

•Integrator’s Reference Manual for VSX Series details over 200

commands for special applications

•Sample control templates are available for touch panel integration

that provides basic functionality right out of the box

Calendar & Call Scheduler •Quick and easy access to a monthly calendar with current date

and time posting

•Schedule individual or repeat meetings to dial automatically

•Create and save multipoint team meetings

Customizable Home Page •Display only the necessary buttons

•Unique design to meet your organization’s needs

•Simplified graphical interface for novice users

•Easy to understand icon driven menu navigation decreases

learning curve

•Kiosk Mode allows you to create a look and feel that suits your

application

•Leads to increased use of video

Dual Monitor Emulation •Use Dual Monitor Emulation for the most efficient use of a single

display

•View near and far video windows at the same time

•Alternate layout views supporting near end, far end and content

User Selectable Camera Icons •Use icons that represent your industry

•Intuitive icons match the input device

•Custom name gives the icon clear meaning

•Selection – 5 libraries to choose from

•Decreases learning curve

Display Configuration Choices •Allows you to configure displays for your application

•Single or dual displays

•XGA or NTSC / PAL

•4x3 or 16x9 formats

•Decide what shows on each display, near end, far end, or content

Platform Versatility

Integration with Microsoft® Live

Communications Server (LCS) via SIP •Integrates directly with Microsoft collaboration infrastructure

•Registers and authenticates with Microsoft LCS 2005

•VSX users can be added to Microsoft Communicator

•Presence information sent to LCS indicating video buddies'

availability

•You can use your Buddy list to launch calls from the VSX 7000e

user interface

Supports up to (3) Microphone Arrays •Maximum coverage for extended rooms

•Polycom StereoSurround support makes installing stereo even

easier

•Great audio pickup from every corner of the room

•Each participant is near a microphone

•Pin-point accuracy on the active speaker with multiple microphone

arrays

•Ceiling Microphone Array can be seamlessly incorporated;

provides coverage up to 40ft in diameter

Internal Multipoint Software

•Optional upgrade easily done with a software key

•Conduct meetings beyond just point-to-point

•Increase productivity by including key people on the call

•Adding sites during a call can lead to quick decision making

•Supports up to 4 video and 1 voice call in a single conference

Secure FTP, Telnet and Web •VSX systems are the most secure video conferencing solutions in

the industry

•Now, all access to the VSX system can be secured including

accessing the VSX system via web-browser as well as secure

telnet and ftp access via SSH for secure system administration

and application connectivity

Advanced Encryption Standard (AES) •Communications are confidential and secure

•Authentication by the National Institutes of Standards means it's

credible

•Built-in, no extra hardware required

H.460 NAT/Firewall Traversal •Standards compliance for traversing NATs and Firewalls

•Session border controller (V2IU) is only needed at the central

location and all VSX systems with H.460 can communicate

through the single V2IU

•Uses H.460.18 for signaling traversal and call establishment and

H.460.19 for media traversal

IP (H.323 and SIP), ISDN or Serial

Connectivity

•IP is standard and you choose the H.320 interface best for your

application

•Choose the right option for your specific network connection

•Supports UPnP and NAT for automatic setup of conferences

conducted through firewalls

•Wide range of IP QoS services to insure call quality and integrity

•Optional H.320 interfaces include Quad BRI, PRI, V.35, RS-449

and RS-530

Multiple Use RS-232 Ports •(2) RS-232 ports

•Camera control, Polycom or others

•Transparent data pass-thru in H.320 or H.323

•Peripheral options from Polycom Custom Products

E-Mail dialing format when dialing across

IP security boundaries •Easy and intuitive E-mail video dialing

•Operates with Polycom's V2IU™ Firewall Traversal Appliance

•Deployable to wide range of customers, suppliers and partners

Interoperability

Part of Polycom’s Unified Collaborative

Communications •Remote management through Global Management System™

•MGC Click & View™ offers a variety of layout templates for a

multi-point call right from the system’s handheld remote

•Extended conferencing with Polycom PathNavigator™

•Schedule, invite participants and manage conferences easily with

Polycom Conference Suite

•Expand meeting capabilities by adding voice-only participants

using the SoundStation VTX 1000 conference phone

•Use the Polycom SE200 for management, scheduling and

gatekeeping

Configurable MTU packet size •Allows administrators to set the MTU packet size, based on needs

of their network

•Optimizes packet size minimizing overhead and network

congestion

•Default setting is 1260

Standards-based •Solid, reliable platform

•Qualified by independent test labs

•Interoperates with other vendor's systems

•Easy to install even in a multi-vendor environment

Baseline Mode •Set your system to baseline mode, H.261 and G.711, for

maximum interoperability with legacy video conferencing systems

•Accessible via web, FTP or on-screen UI for easy access by the

network administrator

•Can be turned on and off as needed

Polycom trademarks are the property of Polycom, Inc. in the U.S. and various countries. All other trademarks are the property of

their respective owners. All prices are US MSRP. Specifications and pricing subject to change without notice.

Altri manuali per VSX 7000e Series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Polycom Sistema di conferenza

Polycom

Polycom RealPresence Group Series Manuale utente

Polycom

Polycom RealPresence Medialign 255 Manuale utente

Polycom

Polycom VSX VSX 6000 Manuale utente

Polycom

Polycom RMX 1500 Manuale di servizio

Polycom

Polycom RealPresence RMX 4000 Scheda tecnica

Polycom

Polycom ViewStation EX4000, FX4000, VS4000 Manuale utente

Polycom

Polycom Real-Time Media Conferencing Platform RMX... Manuale utente

Polycom

Polycom IPOWER 9000 Manuale utente

Polycom

Polycom VIEWSTATION EX Manuale di servizio

Polycom

Polycom HDX Desktop Systems Manuale utente

Polycom

Polycom QDX 6000 System Manuale utente

Polycom

Polycom CX5500 Manuale utente

Polycom

Polycom CX5100 Manuale utente

Polycom

Polycom Viewstation 128 Manuale utente

Polycom

Polycom HDX Series Manuale utente

Polycom

Polycom RMX DOC2557C Istruzioni per l'installazione

Polycom

Polycom HDX 9000 Series Manuale utente

Polycom

Polycom VSX 3000 Manuale utente

Polycom

Polycom VSX 3000 Manuale di servizio

Polycom

Polycom iPower 680 Manuale utente

Polycom

Polycom RealPresence Group Series Istruzioni per il montaggio

Polycom

Polycom SoundStation IP 7000 Manuale utente

Polycom

Polycom HDX Desktop Systems Guida di riferimento rapido

Polycom

Polycom V500 Manuale di servizio

Manuali Sistema di conferenza popolari di altre marche

Kramer

Kramer VIA GO Manuale utente

AVT

AVT MAGIC AC1 Go Manuale utente

ProSoft Technology

ProSoft Technology AN-X4-AB-DHRIO Manuale utente

Sony

Sony PCS-I150 Manuale utente

Middle Atlantic Products

Middle Atlantic Products VTC Series Manuale utente

Prentke Romich Company

Prentke Romich Company Vanguard Plus Guida

Speakerbus

Speakerbus iD 712 Manuale utente

Trelleborg

Trelleborg SafePilot CAT PRO Manuale utente

Sennheiser

Sennheiser ADN Manuale utente

ADTRAN

ADTRAN NetVanta 7100 Manuale utente

AINA

AINA PTT Voice Responder Manuale utente

Yamaha

Yamaha ProjectPhone PJP-100H Manuale utente

vissonic

vissonic VLI Series Manuale utente

Panasonic

Panasonic KX-VC500 Manuale utente

Poly

Poly Trio 8300 Manuale utente

Crestron

Crestron Mercury CCS-UCA-SMK Disegno dimensionale

Inmarsat

Inmarsat mini M Manuale utente

Tenveo

Tenveo ALL-IN-ONE Manuale utente
