POSEIDON EBS MkII Manuale utente
Poseidon EBS MkII / Sea Air EBS MkII
User Manual
VERSION 1.3
S.A.R S.A.R
Poseidon EBS MkII / Sea Air EBS MkII Manual Page 1
S.A.R S.A.R
The Poseidon EBS MkII / Sea Air EBS MkII
This Poseidon EBS MkII/Sea Air EBS MkII (Emergency Breathing System) is a
Category A Escape device Compressed air system.
Before use always check position 10-12 on page 5 and 6 in this manual.
Complete service of the Poseidon EBS should be made every 24th month or if the
EBS is used in training purpose the complete service should be made every 6th
month by Poseidon Diving System AB or approved service station/person.
The Poseidon EBS is intended for use only as an emergency device to assist aircrew
members or passengers in making an emergency egress from a submerged aircraft.
Due to its limited air volume, it is not intended egressing from depths greater than
10 meters.
Poseidon article number 0140-010.
Manufactured by Poseidon Diving Systems AB.
All part in the EBS are individually tested according to EN250 Cold.
The EBS unit is tested and aproved according to CAP1034.
Poseidon Diving Systems AB
Åkeredsvägen 1, SE-421 63 Västra Frölunda, Sweden
Phone: +46 31 734 29 00
www.poseidon.com
WARNING:
Retain this manual for your reference. Review this manual periodically.
Improper use, or misuse, of this device could result in serious injury or
even death.
Text, photographs and gures copyright © 2008-2017 by Poseidon Diving Systems AB. ALL RIGHTS RESERVED.
Manual Version 1.3 - November 2017. Valid from production date november 2017.
Poseidon EBS MkII / Sea Air EBS MkII Manual Page 2
S.A.R S.A.R
Functional overview
Cylinder valve
1st stage regulator
Cylinder, 0.29 liter bottle
Pressure gauge
Mouthpiece
2nd stage regulator
Nose Clip
Low Pressure Hose
Serial number and date
Cylinder valve in position OPEN
Turning the valve handle counter clockwise until stop.
Purge button
Nose Clip Holder
Poseidon EBS MkII / Sea Air EBS MkII Manual Page 3
S.A.R S.A.R
Assembly
Inspect the o-ring on the 1st stage tank thread and make sure that
sealing surfaces are clean and that the o-ring is lubricated with approved
Poseidon product (art no 8516).
Mount the 1st stage on the 0,29 liter bottle tight and rmly (rec. 60 Nm).
WARNING:
Before assembly, make sure all components are intact and without any
visible damage. Do not use if there is any sign of damage to the equip-
ment. Repair of any component should only be performed by a service
technician that is authorized to service/repair the equipment. Do not try
to repair any component without proper training.
Inspect the O-ring
2.
3.
1. Assemble
Turn to fasten
Poseidon EBS MkII / Sea Air EBS MkII Manual Page 4
S.A.R S.A.R
Filling instructions
If the pressure is 200 bar or more - go to position 11 on page 6.
Recomended lling pressure is 200 bar/ 2900 psi.
Maximum lling pressure is 232 bar/ 3364 psi.
Use Poseidon lling adapter art no 0800-015.
2. Remove the blanking plug from the 1st stage.
Inspect the O-ring and attach the lling adapter to the 7/16” HP port where the
blanking plug was mounted. Make sure the lling adapter is rmly attached.
Attach the lling hose to the G5/8” thread on the lling adapter.
3. When the lling hose is rmly attached to the lling adapter, slowly open the
valve on the 1st stage by turning the valve handle counter clockwise.
4. Slowly open the lling source valve and make sure
there are no leakage. Fill the Poseidon EBS to 200 bar/ 2900 psi.
Maximum lling pressure is 232 bar/ 3364 psi.
1. Close the cylinder valve. Press the purge-button on the 2nd stage to ensure
that the breathing apparatus is depressurized before the lling process begins.
WARNING:
Before you start lling the bottle, make sure you are well familiarized
with these instructions.
Maximum pressure of 232 bar/ 3364 psi.
Failure to follow these instructions may lead to injury or death.
G 5/8”
5. When the Poseidon EBS if lled, close the valve on the lling source.
Purge button
Poseidon EBS MkII / Sea Air EBS MkII Manual Page 5
S.A.R S.A.R
6. Close the valve on the Poseidon EBS
7. Release the pressure by using the purge button on the 2nd stage.
8. Unscrew the lling adapter/hose from the Poseidon EBS.
9. Mount the blanking plug in to the 7/16” HP port of the 1st stage and make sure
it’s rmly attached. Before mounting the blanking plug, inspect the o-ring to
make sure it’s without any aws, make sure the o-ring is lubricated and that all
sealing surfaces are clean and undamaged.
10. Open the valve [1] on the Poseidon EBS and check the pressure. If pressure is
150 bar/ 2176 psi [2] it’s OK to use. If the pressure is below 150 bar / 2176 psi,
start the lling procedure from pos 1 on page 4.
2.
1.
Poseidon EBS MkII / Sea Air EBS MkII Manual Page 6
S.A.R S.A.R
13. The Poseidon EBS MkII/Sea Air EBS MkII
is now ready for use.
WARNING:
Before use, make sure all components are intact and without any visible
damage. Do not use if there is any sign of damage to the equipment.
Repair of any component should only be performed by a service techni-
cian that is authorized to service/repair the equipment. Do not try to
repair any component without proper training.
12. Spray the mouthpiece with GUARDIAN SUPERIOR™ disinfection,
Art.no 0050-127 (or other Poseidon approved product).
Use 2-3 sprays and wipe with a cloth or piece of paper.
11. Attach the Nose Clip in correct position on Nose Clip Holder.
Poseidon EBS MkII / Sea Air EBS MkII Manual Page 7
S.A.R S.A.R
Xstream EBS 1st stage regulator
Cylinder, capacity 0.29 liter
Working pressure 200 bar / 2900 psi.
Cyklon 2nd stage regulator
Nose Clip
Low Pressure Hose
Spare parts list
Part no. Description
13910 Filling hose, 300-200 bar incl safety valve 225 bar
13983 Cylinder, Black 0,29 Liter, UNF 5/8”-18, 200 bar/2900 psi
Pressure gauge
Low Pressure Hose 24”
Mouthpiece
Desinfection, Guardian Superior 100 ml
Nose clip
Filling adapter Poseidon EBS 7/16” - G5/8”
Lubricant, tube 10 grams
O-ring HP port, Presure gauge and blanking plug
O-ring 1:st stage tank thread
O-ring LP port (hose connection)
13912
13913
13914
13915
13916
13918
13917
13919
13984
13921
13922 O-ring, Nose Clip Holder
Components
www.poseidon.com
Nose Clip Holder
