PowerClass®
coaxial speakers
INTRODUCTION
Thank you for your purchase of this
PowerClass
®Coaxial Loudspeaker system from
PrecisionPower™
. Our engineers have combined state of the art materials such as
foamed polypropylene cones and vapor-deposit titanium dome tweeters with
cutting-edge industrial design to achieve competition-ready performance levels.
PRACTICE SAFE SOUNDTM
Continuous exposure to sound pressure levels over 100dB may cause permanent
hearing loss. High powered automotive sound systems can generate sound
pressure levels in excess of 130dB. When playing your system at high levels,
please use hearing protection and prevent long term exposure.
Model Number: _____________________
Date of Purchase: ___________________
WHAT’S INTHE BOX
Your new
Precision
PowerTM PC coaxial speaker kit includes all the necessary
mounting hardware and cables for a basic installation:
Quantity Description
1 Installation and Operation Manual
2 PC coaxial speakers
1 Mounting template
2 Grills
INSTALLATION
The performance of your new
Precision
PowerTM Coaxial Loudspeaker system is
directly proportional to the quality of installation.Care taken during the installation
process will be rewarded with years of satisfying performance. If you are unsure
about your installation capabilities, please refer to your local Authorized
Precision
PowerTM Dealer for technical assistance. If you decide to install the
speaker system yourself, please read the entire owner’s guide before beginning
your installation.
1
TOOLS OF THE TRADE
Listed below are tools you may wish to have on hand before starting your
installation. Having the proper tools will make the installation much easier. Some
of these tools are necessities, some will just make the job easier.
• Marking Pen • Electric Drill
• 1/4” Drill Bit • Phillips Screwdriver
• 1/8” Drill Bit • Volt/Ohm Meter (optional)
• 3/8” Drill Bit • Assorted Tin Snips
• Hole Saw Arbor • Wire Cutters
• 4-3/4” Hole Saw (5-1/4” woofer install) • Wire Crimpers
• 5-3/4” Hole Saw (6-1/2” woofer install) • Wire Strippers
• Razor Knife (optional)
FINDING SPEAKER MOUNTING LOCATIONS
Choosing the correct speaker locations can have a significant effect on the sound
quality of the system.Care is needed to ensure that the location you have chosen
will not affect any of the mechanical or electrical operations of the vehicle.There
are many different considerations for choosing the locations that best suit your
needs. The locations must be large enough for the speakers to fit without
interfering with other vehicle parts such as window mechanisms, etc. If minimal
intrusion in your vehicle is desired, factory speaker locations may be the ticket for
you. Placing the speaker in the factory location can often give you very desirable
results. Alternative locations to consider include mounting in customized kick
panels, rear decks, or side panels.
DOOR MOUNTING
When considering possible speaker locations in the doors, be sure to check the
operation of the window mechanism and all other moving parts inside the door.
Most vehicles use a stabilizer stop bar in between the door and the door jamb.
This bar prevents the door from opening too far, but may intrude into the speaker
mounting area when the door is closed.Many do-it-yourself installers overlook this
and check for speaker clearance only when the door is fully open.
REAR DECK MOUNTING
In rear deck installations, check the operation of the trunk suspension springs or
tension bars. These tension bars can move when opening and closing the trunk
and can exert a great deal of force against anything that obstructs their
movement, such as a speaker basket or motor assembly. In addition, try to avoid
locating the speakers too close to the back edge of the rear deck. Installing the
rearmost screws may not be possible without the removal of the rear window.
2
INSTALLING THE SPEAKER
Step 1: Determine where the speaker will be mounted. Make sure there is a flat
area large enough for the speaker to fit properly. An uneven mounting
surface can damage the driver and limit the bass performance of your PC
component system.
Step 2: Check to make sure the mounting location you have chosen for the
speaker will not interfere with the operation of the vehicle.
Step 3: Using the supplied template guide, mark the hole with a pen.
Step 4: [Skip this step if using correctly sized factory locations] Cut the hole for the
speaker.A hole can be cut either with a pair of metal tin snips, razor knife, air
saw, or with a hole saw corresponding to the size of the woofer listed below.
• 4-3/4” Hole Saw (5-1/4” woofer installation)
• 5-3/4” Hole Saw (6-1/2” woofer installation)
WARNING:Window mechanisms and electrical wires and other expensive car
parts have a nasty habit of hiding where you least expect. CHECK BEFORE
YOU DRILL!
Step 5: Run the speaker wire to the speakers. Make sure to keep wires away
from sharp metal or other edges. When passing through metal, use a
protective grommet.
Step 6: Using the plastic grille ring as a template, mark the mounting holes with
a pen.
Step 7: Pre-drill mounting holes using a 1/8” drill bit.
WARNING:Window mechanisms and electrical wires and other expensive car
parts have a nasty habit of hiding where you least expect. CHECK BEFORE
YOU DRILL!
3
SPECIFICATIONS
Model PC 650C PC 690C
Nominal Impedance 4 ohms 4 ohms
Power
Continuous/Peak 60/120 watts 75/150 watts
Frequency Response 90Hz - 20kHz 70Hz - 20kHz
Sensitivity
(2.83V @ 1w/1m) 90 dB 91 dB
Mounting Depth 2-15/16” 3-7/16”
Model PC 525C PC 570C
Nominal Impedance 4 ohms 4 ohms
Power
Continuous/Peak 50/100 watts 50/100 watts
Frequency Response 100Hz - 30kHz 80Hz - 20kHz
Sensitivity
(2.83V @ 1w/1m) 90 dB 91 dB
Mounting Depth 2-7/8” 2-7/8”
4
Warranty
LIMITED TWO YEAR CONSUMER WARRANTY:
Directed Electronics, Inc.promises to the original purchaser, to replace this product should
it prove to be defective in workmanship or material under normal use, for a period of two
years from the date of purchase from the dealer as indicated by the date code marking of
the product PROVIDED the product was installed by an authorized Directed dealer. During
this two-year period, there will be no charge for this replacement PROVIDED the unit is
returned to Directed, shipping pre-paid. If the unit is installed by anyone other than an
authorized Directed dealer, the warranty period will be one year from the date of purchase
by the dealer as indicated by the date code marking of the product. This warranty is non-
transferable and does not apply to any unit that has been modified or used in a manner
contrary to its intended purpose, and does not cover damage to the unit caused by
installation or removal of the unit. During this one-year period, there will be no charge for
this replacement PROVIDED the unit is returned to Directed, shipping pre-paid. This
warranty is void if the product has been damaged by accident or unreasonable use,
neglect, improper service or other causes not arising out of defects in materials or
construction. Units which are found to be damaged by abuse resulting in thermally
damaged voice coils are not covered by this warranty but may be replaced at the
absolute/sole discretion of Directed. ALL WARRANTIES INCLUDING BUT NOT LIMITED
TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF
MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, AND WARRANTY OF
NON-INFRINGEMENT OF INTELLECTUAL PROPERTY ARE EXPRESSLY EXCLUDED
TO THE MAXIMUM EXTENT ALLOWED BY LAW, AND DIRECTED NEITHER
ASSUMES NOR AUTHORIZES ANY PERSON TO ASSUME FOR IT ANY LIABILITY IN
CONNECTION WITH THE SALE OF THE PRODUCT. DIRECTED HAS ABSOLUTELY
NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS
AUTHORIZED DEALERS OR INSTALLERS. Unit must be returned to Directed, postage
pre-paid, with bill of sale or other dated proof of purchase bearing the following information:
consumer's name, telephone number, and address, authorized dealer's name and
address, and product description. Note: This warranty does not cover labor costs for the
removal and reinstallation of the unit. IN ORDER FOR THIS WARRANTY TO BE VALID,
YOUR UNIT MUST BE SHIPPED WITH PROOF OF INSTALLATION BY AN
AUTHORIZED DIRECTED DEALER. ALL UNITS RECEIVED BY DIRECTED FOR
WARRANTY REPAIRWITHOUT PROOF OF DIRECTED DEALER INSTALLATIONWILL
BE COVERED BY THE LIMITED 1 YEAR PARTS AND LABOR WARRANTY. Note: This
warranty does not cover labor costs for the removal and reinstallation of the unit. BY
PURCHASING THIS PRODUCT, THE CONSUMER AGREES AND CONSENTS THAT
ALL DISPUTES BETWEEN THE CONSUMER AND DIRECTED SHALL BE RESOLVED
IN ACCORDANCE WITH CALIFORNIA LAWS IN SAN DIEGO COUNTY, CALIFORNIA.
© 2003 Directed Electronics, Inc. All rights reserved. G38016/21/31/36 12-03
