MOUNT CATEGORY  CEILING MOUNTS

Universal Flat-Panel Ceiling Mounts

FLAT-PANEL CEILING MOUNTS

ECM-3763S adapts to 1.5” NPT (not included)

and ts a single 37”-63” display

ECM-3763D adapts to 2” NPT (not included)

and ts two 37”-63” displays back-to-back

The Elliptical Ceiling Mount Series is the latest

mounting innovation from Premier Mounts.

Designed from the ground up as universal ceiling

mounts, the Elliptical Series do not require any

additional adapters or accessories to accommodate

displays from 37”-63”.

It features multiple cable management ports for

improved cable routing as well as an aesthetic de-

sign that is best-in-class. Pop-on covers hide all

mounting hardware and integrated power outlet

makes wiring your displays a breeze.

Backed by Premier Mounts’industry-leading

Lifetime Warranty for true peace of mind.

• Fits most 37”-63” at panel displays

• ECM-3763S mounts a single display

• ECM-3763D mounts two displays back-to-back

• 15° continuous tilt

• Cable management/concealment

• No exposed holes, mounting screws or hardware

• Adapts to 1.5”NPT (single) or 2”NPT (back-to-back)

• ECM-3763D includes an integrated power outlet

• Adapters for signal converters, le servers and A/V

equipment mount directly to frame

• Color: Black

Dimensions are in inches and millimeters [mm].

800.368.9700 | www.mounts.com

3130 East Miraloma Ave. , Anaheim, CA 92806

TOP VIEW

SIDE VIEW

FRONT VIEW

9.982

253.54

21.682

550.71

36.000

914.40

24.889

632.18

19.924

506.06

36.000

914.40

9.982

253.55

Part Number: ECM-3763S

Part Number: ECM-3763D
