PSD-CAM INSTALLATION INSTRUCTIONS

PSD-CAM (Qty 1) M8 x 10mm Set

Screw (Qty 2)

1. Place each PSD-CAM shelf over the end of the support poles (Figure 1).

2. Use one (1) M8 x 10mm set screw and attach it in the hole that is located to the rear of each

collar (Figure 2).

3. Use a 5/32” Allen Wrench (supplied) to tighten the set screws (Figure 2).

Figure 1 Figure 2 Figure 3

M10 x 12MM

Set Screws

5/32” Allen

Wrench

PSD-EXT

Support Poles
