Prestigio Roadrunner 310 Manuale utente

Roadrunner310 EN - 1

Quick Start Guide

Prestigio Roadrunner 310

1. Packing List

1. Prestigio car DVR

4.USB cable

2.Suction mount

5.AV cable

3.Car charger

6.Quick start guide

7. Warranty Card

2. Device Overview

Mic

LED light (Charging)

Menu button

AV Port

EN - 2Roadrunner310

Quick Start Guide

Prestigio Roadrunner 310

Photo /Mode button

USB port

Up /Mic button

SD card slot

Down/SOS button

LED light (Night mode)

Speaker

Lens

Mount hole

Power Button

Reset button

Video/playback /ok button

LED light

LCD display

Note: When the device works not properly, press the reset button to

reset the device.

Getting started

3. Power on/Power off

Position the device in the vehicle using the suction mount and press

the Power button to turn it on. To power off the device press the

button again.

You can also connect the device to the car charger. It will

automatically turn on and start recording when the car engine starts.

When the engine stops, the device will automatically save the last file

and turn off.

4. Charging

Using the USB cable: connect the device to the USB port of a

computer/Laptop

Using the car changer: Connect the device to the car charger. The

device will start charging after the car engine is turned on. The device

will automatically turn on and start recording. When the engine stops,

the device will automatically save the last file and turn off.

Normally it takes approximately 2-3 hours to fully charge the device.

Operating the device while charging with the Car Charger may extend

the time of full charge.

Note:

Before using the device for the first time, please, connect it to the PC

or notebook using the USB cable provided to fully charge the Li-ion

battery. The battery is completely charged in 2-3 hours.

Roadrunner310 EN - 3

Quick Start Guide

Prestigio Roadrunner 310

5. Inserting the SD-card

Before starting video recording, please, insert a SD card (not included)

into the SD card slot in the device (need to open the battery door).

To extract the SD card slightly push it inside the device, and remove.

Note:

After inserting the SD card the device will automatically recognize it

as default storage and all the data will be saved on this card.

6. Recording

Connect the device to car charger, when the car engine is turned on

after 5 seconds, the device will start loop video recording. When the

car engine stops, the device will save the last file and turn off after 15

seconds

Notice:

1. Press OK button on loop video recording, the current file will be

saved and the device enters to standby mode.

2. When the SD card is full, the device will delete the first unlocked

video file automatically

7. Taking pictures

Press the Mode button to select the photo mode

Press OK button to take photos, Taken photos are saved on SD Card.

Press the Menu button in the photo mode, and then press up/down

button to set resolution and time.

Home screen

8. Main menu

The following symbols may be displayed on the screen:

Video recording mode

Picture mode

Storage card

sound recording mode

EN - 4Roadrunner310

Quick Start Guide

Prestigio Roadrunner 310

Settings

9. Video Menu settings

Turn on the device and make sure the Video mode is selected.

Note:

To select Video or Picture Mode press the Mode button. The

appropriate symbol will be displayed in the top left corner of the

screen.

Press Menu button to enter Settings. Press up/down button to select

the option and press OK button to enter the select mode, press

up/down button to select and press OK again to set the value.

The following options list is available in the Video menu:

Resolution: Select the video image size from 1280 x 720(30 fps),

848 x 480, 640 x 360.

Time Stamp: Select to turn the time stamp on or o

Motion Detect: In the standby mode, press Menu button to set the

function on, the device will start video recording automatically if it

detects a moving object and stop recording when there is no

movement detected.

Video time: Select one of the values to set the video cycle. Once the

Micro SD card is full, the device will automatically erase the oldest

unlocked files on the card and continue recording new ones.

Night Mode: select to turn the LED Auto set, off or on.

Note: LED effectiveness may be limited by luminosity around

Mic: Select to turn the microphone on or off.

10. Picture Menu settings

Turn on the device and make sure the Picture mode is selected.

Note:

The appropriate symbol will be displayed in the top left corner of the

screen.

Press Menu button to enter Settings. Press up/down button select the

option

The following options list is available in the Picture menu:

Size: Select the image size from VGA,1.3M,2M,3M

Time Stamp: Select to turn on or off.

Roadrunner310 EN - 5

Quick Start Guide

Prestigio Roadrunner 310

Shutter Sound: Select to turn on or off.

11.General settings

Press Twice Menu button to enter Settings, and then press up, down, ok

button to select Settings. The following settings are available:

Format: Select to format the SD Card.

Rotate 180: Select to rotate the screen direction in 180 degree.

G-sensor: Select to set the sensitive of G-sensor

Language: Select the desired language from the list.

Auto off: Make the device automatic power off when it is not in use.

LCD Auto Off: Select the time of the LCD automatic turn off when the

device start recording.

Sys Reset: Select to restore default system settings.

Light Freq: Change frequency to remove the blinking effect when

recording under artificial lighting.

Date Input: Install the current time.

TV Output: Select the TV output format, NTSC or PAL.

Date Format: Select the date display format, YYYY/MM/DD,

MM/DD/YYYY or DD/MM/YYYY

Key Tone: Select to turn on or off the key tone

Firmware Ver.: Display the current system version

12.Playback mode

Press OK button to enter playback mode. The last recorded file will be

displayed. Press the up/down button to view the files.

Press the OK button to play the files. Meantime, under play mode,

press up/down to FORWARD/BACKWARD(1/2，1/4) the file, then

press OK button to pause. Press the Menu button back to the

playback menu. To enter menu options press Menu button, the

following settings are available:

Delete: Select the file / files you want to delete.

Lock / Unlock: Select the file you want to lock or unlock.

Thumbnail: Select to enter the file thumbnail mode.

Volume: Select the playback volume.

13. USB connection

To download registered files on your PC/notebook, please, connect the

device to the PC or notebook via USB-cable provided. After connecting

EN - 6Roadrunner310

Quick Start Guide

Prestigio Roadrunner 310

the device to the PC the USB menu will be displayed, containing DV, PC

Cam and Disk Driver. Select Disk Driver and the device will appear in

“My computer” as the removable disk. All registered files are stored in

DCIM folder, videos are stored in AVI format, and the pictures are stored

in JPG format. You can now download the files from the device.

14. PC Camera Mode

Connect the device to a computer via USB. It will show DV/PC Cam/Disk

drive tarting up the device, Press up/down to select and then press OK to

enter PC CAM mode, then you can use the device as a PC Camera

15. Playback on TV

To playback the recorded files on TV connect the device to your TV with

the HDMI cable (not included in the package) and follow the TV

instructions or refer to your TV user manual.

Notes:

Please insert the SD card before recording. SD card is not included in

the package.

When the SD card is out of memory, it will automatically erase the

oldest files and start recording from the beginning (only if the Recycle

option is activated).

Safety precautions

Please observe all safety precautions before using Prestigio Roadrunner

310. Please follow all procedures outlined in this manual to correctly

operate the device.

Do not attempt to disassemble or alter any part of the device that is

not described in this guide.

Do not place the device in contact with water or any other liquids. The

device is NOT designed to be liquid proof of any sort.

In the event of liquid entry into interior of device, immediately

disconnect the device from the computer. Continuing use of the

device may result in fire or electrical shock. Please consult your

product distributor or the closest support center.

To avoid risk of electrical shock, do not connect or disconnect the

Roadrunner310 EN - 7

Quick Start Guide

Prestigio Roadrunner 310

device with wet hands.

Do not place the device near a heat source or directly expose it to

flame or heat.

Never place the device in vicinity of equipments generating strong

electromagnetic fields. Exposure to strong magnetic fields may cause

malfunctions or data corruption and loss.

Technical Specifications

Recording

1280 x 720(30fps), 848 x 480, 640 x 360 pixels

Video format

MOV

Picture format

JPG

Power source

Rechargeable battery

Interfaces

USB, SD card (Supports max 32GB, high-speed SD

card recommended)

Microphone

Built-in

Operating

temperature

0 °~ 45°C

Video Storage Capacity

Storage

card(G)

1280*7

(720P)

848*480

(WWGA)

640*480

(VGA)

1280 X

1024

(1.3M)

1600 X

1200

(2M)

3264 X

2448

(3 M)

16G

80 min

192 min

144 min

58240

photos

36960

photos

29280

photos

40 min

96 min

72 min

29120

photos

18480

photos

14640

photos

20 min

48 min

36 min

14560

photos

9240

photos

7320

photos

10 min

24 min

18 min

7280

photos

4620

photos

3660

photos

5 min

12 min

9 min

3640

photos

2310

photos

1830

photos

EN - 8Roadrunner310

Quick Start Guide

Prestigio Roadrunner 310

Disclaimer

If device has been damaged by liquid (for example, water, coffee or a

soft drink, etc.), the service for such liquid damage is not covered by the

Prestigio two (2) years limited warranty.

As the Prestigio products are constantly updated and improved, your

device’s software and hardware may have a slightly

different appearance or modified functionality than

presented in this Quick Start Guide.

Prestigio hereby states that this Roadrunner complies to

basic requirements and another relevant regulations given by the EU

directive1999/5/EC. Full version of the declaration of conformity is

available on http://www.prestigio.com/compliance.

Indice

Altri manuali Prestigio Telecamera da cruscotto

Prestigio

Prestigio RoadRunner 340 Manuale utente

Prestigio

Prestigio RoadRunner 140 Manuale utente

Prestigio

Prestigio ROADRUNNER 440GPS Manuale utente

Prestigio

Prestigio RoadRunner 526DL Manuale utente

Prestigio

Prestigio PCDVRR320 Manuale utente

Prestigio

Prestigio RoadRunner 420 Manuale utente

Prestigio

Prestigio RoadRunner 420DL Manuale utente

Prestigio

Prestigio PCDVRR300I Manuale utente

Prestigio

Prestigio RoadRunner 400GPS Manuale utente

Prestigio

Prestigio ROADRUNNER 480W Manuale utente

Prestigio

Prestigio RoadRunner 585GPS Manuale utente

Prestigio

Prestigio RoadRunner Manuale utente

Prestigio

Prestigio PCDVRR320 Manuale utente

Prestigio

Prestigio PCDVRR320 Manuale utente

Prestigio

Prestigio RoadRunner 519I Manuale utente

Prestigio

Prestigio RoadRunner 507 Manuale utente

Prestigio

Prestigio RoadRunner MIRROR Manuale utente

Prestigio

Prestigio RoadRunner 320 Manuale utente

Prestigio

Prestigio RoadRunner PCDVRR515 Manuale utente

Prestigio

Prestigio RoadRunner CUBE Manuale utente

Prestigio

Prestigio RoadRunner 155 Manuale utente

Prestigio

Prestigio Roadrunner 460W Manuale utente

Prestigio

Prestigio ROADRUNNER 430W Manuale utente

Prestigio

Prestigio RoadScanner 500WGPS Manuale utente

Manuali Telecamera da cruscotto popolari di altre marche

Cansonic

Cansonic UltraDuo Z2 Manuale utente

Gazer

Gazer F720 Manuale utente

HP f500g Manuale utente

Xblitz

Xblitz TANGO 4K Manuale utente

Rexing

Rexing M1 Manuale utente

Maka Technologies

Maka Technologies Marbella MXPro Manuale utente

NESA

NESA NRC-80DLM Istruzioni per l'installazione e il funzionamento

Kaiser Baas

Kaiser Baas R20 Manuale utente

Boyo

Boyo VTM43TC Manuale utente

Minolta

Minolta MNCD37 Manuale utente

Thinkware

Thinkware FA10 Manuale utente

Momento

Momento MD-5200 Manuale utente

BlackVue

BlackVue DR590X-1CH Manuale utente

HP F300 Manuale utente

CammSys

CammSys BlackSys BH-300 Manuale utente

Snooper

Snooper DVR-2HD Manuale utente

Lukas

Lukas Q900 Manuale utente

RVS

RVS 450C Manuale utente
