INSTRUCTIONS FOR USE

Pro-Ject MaiA

Dear music lover,

thank you for purchasing a Pro-Ject Audio Systems´ integrated amplifier.

In order to achieve maximum performance and reliability you should study these instructions for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

Safety instructions

AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the

voltage in your area meets the voltage requirements printed on the power supply.

The power supply is used to connect/disconnect the unit from the mains. Make sure that the power

supply is easily accessible at all times. Never handle the device, the power supply while your hands are

wet or damp. Avoid letting liquids enter the device or the power supply. Never place any item

containing liquid, such as a flower vase on or near the device. Never spill any liquid on the device or

the power supply. Never place any naked flame sources, such as lighted candles on or near the device.

The product shall not be used in damp or wet locations, next to a bathtub, sink, swimming pool or any

other similar conditions.

Connectors

Make all connections except the connection to the headphone whilst the amplifier is disconnected

from the power supply.

Take care to connect the left and right channels correctly. The right channel is usually marked red, the

left channel black or white.

Never use any other power supply than the one supplied with the unit.

Line output

A power amplifier or active loudspeakers can be connected to the output socket marked Output.

Phono input

Connect the tonearm signal lead to the In 1 Phono of the amplifier. The earthing wire may be connected to

the screw terminal if you encounter hum problems when using the turntable.

Line inputs

Line level sources such as CD player, radio or TV can be connected to the input sockets marked In 2, In 3 or

In 4.

Digital inputs

Sources with a digital output such as TV satellite/cable receiver or a game console can be connected to the

digital inputs. Coaxial to In 5 and optical to In 6 and In 7.

Connecting to a Computer

Connect the USB-input In 8 USB of the MaiA (unit must be switched on) to a free USB-socket on your

computer and turn it on/make sure it is powered on. Select input 8USB.

* For Windows®operating systems an USB driver (supplied on CD) has to be installed. Mac OS®operating

systems do not need an additional driver.

Please note: Connection should be made to an USB-socket of your computer directly. Connecting to

USB-hubs or switches can cause problems.

24Bit/192kHz playback with Windows®operating systems

* For Windows®operating systems a 24Bit/192kHz USB driver (supplied on CD) has to be installed. Insert

the included CD into the drive of you PC and follow the instructions.

After installing the driver, some settings have to be checked/done.

For example - Windows 7®operating system:

Control Panel Hardware and Sound Sound Playback:

select Speaker/ MaiA USB 2.0 Audio Out

Properties Supported formats: make sure nothing is assigned

Level Sound: setting must be 100

Enhancements: disable all enhancements Advanced Default Format: set to studio quality 24/192

Mains power connection

Connect the low voltage plug from the power supply to the Power socket before connecting the power supply

to the mains.

Connection to the speakers

The output terminals accept loudspeaker cables terminated with 4mm Banana plugs, spades connectors

or naked wire.

Remote control

turns the unit on or back into standby

and adjust the sound volume

and select the inputs

Front panel controls

To switch on from standby or to standby

The push button on the left side of the front panel turns the unit on or back into standby (press and hold to

switch into standby mode). The blue LED above the stand-by push button shows that the unit is switched on.

Input selector

After the unit is powered on, pressing the buttons ◄ and ►next to the LEDs inputs indicators selects

desired input.

Volume

Adjust the volume to the desired level, using the large knob on the front panel.

Connecting a headphone

Connect the headphones to the ¼“ (6,3mm ) jack socket on the front of the unit.

Bluetooth connection

Make sure the antenna is attached to its connector In 9 BT on the back panel prior using bluetooth.

Bluetooth is active only once input 9 is selected.

Pairing with Android devices

Open Settings and tap on Bluetooth. Turn on Bluetooth and tap on Scan. Searched devices will show up.

Tap on "MaiA" (Enter "0000" if requested) and confirm by pressing power button on MaiA once the blue LED

of the input 9 is fast blinking. Once paired it will show "Connected to media Audio", now you can play music

from your Android device over Bluetooth to MaiA.

CH+

CH-

VOL+

VOL-

ON/OFF

VOL

Pairing with Apple devices

Tap on Settings, tap on Bluetooth, turn on Bluetooth, your device will automatically start searching for

available devices. Tap on "MaiA" and confirm by pressing power button on MaiA once the blue LED of the

input 9 is fast blinking.

MaiA can store up to 8 Bluetooth devices. If the memory is full then it is not possible to pair another

device. For erasing the memory turn off the unit > disconnect power supply > press and hold power

button > connect power supply > hold power button for 5 seconds > release power button. The blue

LED above the power button will blink for few seconds. Once the LED stops blinking, memory is

erased and you can turn on the unit.

Replacing batteries

Proceed as follows:

Unlock and slide open the battery case cover

Replace the battery.

Make sure the battery is the right way round !

Close the battery case cover

Battery type: 1 x CR2032 / 3V or 1 x CR2025 / 3V

Do not dispose the batteries as ordinary domestic refuse. Please dispose your exhausted batteries at

the appropriate collection sites - usually located at supermarkets and drugstores.

Technical specifications Pro-Ject MaiA

Power output : 2x 25W/37W at 8 ohms/4 ohms (both channels driven)

Frequency response : 20Hz - 20kHz (-0,3dB, -2,5dB)

Channel separation : > 65dB at 20kHz

Noise floor : > -90dB (A weighted)

THD : < 0,07% at 15W

Gain : 31dB (measured via line level input)

Line level inputs : 2 pair RCA + 1 jack 3.5mm

Line input sensitivity : 350mV

Line input impedance : 50kohms

Phono input : 1 pair RCA

Phono input sensitivity : suitable for MM, MI or high output MC cartridges

Phono input impedance : 47kohms

Phono input gain : 40dB

S/PDIF coaxial input : up to 24bit and 192kHz

S/PDIF optical input : up to 24bit and 96kHz

USB input : USB Audio Class 2 requires USB 2.0 or higher on computer

USB data transfer : Asynchronous

Digital to Analogue converter : Cirrus Logic CS4344 24bit/192kHz Multi-bit Delta Sigma type

Variable line level output : jack 3.5mm

Bluetooth music receiver codec : aptX, A2DP profile

Bluetooth range : 10 meters in direct visibility between source and receiver

Speakers connectors: 4mm banana plugs, spades connectors or naked wire

Outboard power supply : 20V/3A DC, suitable for your country's mains supply

Power consumption : max. 3A DC, <0.5W in standby

Replacement battery remote control : 1 x CR2032 / 3V or 1 x CR2025 / 3V

Dimensions W x H x D (D with sockets) : 206 x 36 x 150 (165)mm

Weight : 1250 g without power supply

Service

Should you encounter a problem which you are not able to alleviate or identify, please contact your dealer for

further advice. Only if the problem cannot be resolved there, the unit should be sent to the responsible

distributor in your country.

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions

for use. Modification or changes to any part of the product by unauthorized persons release the

manufacturer from any liability over and above the lawful rights of the customer.

Pro-Ject Audio Systems is a registered Trademark of H.

Lichtenegger.

This guide was produced by: Pro-Ject Audio Systems

The information was correct at the time of going to

press. The manufacturer reserves the right to make

changes to the technical specification without prior

notice as deemed necessary to uphold the ongoing

process of technical development.
