Protech Systems PMB-891LF Manuale utente

Ver. Q3

Packing Checklist

Jumper Setting

PMB-891LF

11 15

REMOVE

Intel®3rd Gen.

Core™i7/i5/i3

& Pentium®

(LGA1155)

DIMM2 DIMM3

ATX_PWR2

DIMM4

ATX_PWR1

121

120

240

121

120

240

121

120

240

121

120

240

CPU_FAN1 14

SYS_FAN4

AUDIO1

LAN1_USB1 LAN2_USB1

JPS2USB1 LPT1

COM1VGA1

Intel®

PCH Q77

DIMM1

SP1

DIO1

JLPC1

JDP1

JDP2

JP11

JP9

COM4

PCI_E1PCI_E3

PCI1PCI2PCI3

IR1

COM2

10 5

COM3

10 5

SYS_FAN3

APS1

FP2

USBDOM1

USB1

JP13

JP5

JP6

FP1

SYS_FAN2

SYS_FAN1

109

1 2

109

1 2

19 20

Battery

SATA2

SATA4

SATA5

USB2

SATA1

SATA3

SATA6

JP10 SIO

JP12

PCI4

JP2

RI (default)

12V

COM3 RI & Voltage

Selection

Normal

Auto

Gating

(default)

COM2 Auto Detect

Selection

Intel®3rd

Gen. Core™

(default)

Intel®2nd

Gen. Core™

CPU Selection

(default)

12V

5VRI

COM4 RI & Voltage

Selection

RS232/422/485

(COM2) Selection

RS422RS232

9 10

1 2

9 10

1 2

9 10

1 2

RS485

(default)

Normal

(default)

Clear

CMOS

Clear CMOS Data

Selection

LAN1 LED

11 12

1 2

LAN2 LED

11 12

1 2

LAN Link LED

Selection

18 17

2 1

Front Panel

Selection

ATX

Power

Button

Reset

Button

Power

LED

HDD

LED

PMB-891LF

Quick

Reference

Guide

If you discover any item below damaged or lost,

please contact your vendor.

PMB-891LF x 1

This Quick Reference Guide x 1

Manual/Driver CD x 1

Jumper (2.0 mm) x 3

SATA Cable (460 mm) x 1

I/O Shield x 1

CAUTION! Danger of explosion if the battery is incorrectly replaced. Replace only with

the same/equivalent type recommended by the manufacturer. Dispose of used batteries

according to the manufacturer’s instructions.

I/O View

Intel®3rd Gen. Core™ i7/i5/i3 & Pentium® ATX Motherboard

PMB-891LF

Front View

PCI-E (4x)

LAN & USB Port

Mini-DIN & USB

PCI-E (16x)

COM2

Audio Port

COM3

DDR3 DIMM

Power Connector

DIO

COM4

USB Connector

System Fan

SATA Connector

Display Port Intel®LGA1155

Intel®PCH Q77

PCI

System Fan

USB 3.0

Connector

CPU Fan

VGA, COM & Printer Port
