Pulsar AS01 Manuale utente

CAL. AS01

Solar Watch

ENGLISH

lHour, minute and second hands

l Solar charging function

l Energy depletion forewarning function

English

DISPLAY AND CROWN

a: Normal position

b: First click position

Hour hand

Minute hand

Second hand

CROWN

a b

English

SCREW DOWN CROWN

[for models with screw down crown]

Locking the crown

1Turn Crown counterclockwise until you no

longer feel the threads turning.

2Crown can be pulled out.

1Push Crown back in to normal position.

2Turn Crown clockwise while pressing it

lightly until tight.

Unlocking the crown

English

HOW TO CHARGE AND START THE WATCH

When you start the watch or when the energy

in the rechargeable battery is reduced to an

extremely low level, charge it sufciently by

exposing the watch to light.

NOTE

• It is not necessary to charge the watch fully. It is important, however, to charge

the watch sufﬁciently, especially in case of initial charge.

English

GUIDELINES FOR CHARGING TIME

Time required (approx.)

Illumination

(Lux) Light source Environment A

(Hours)

B k

(Hours)

(Minutes)

700 Fluorescent lamp Inside office -35 100

3,000 30W 20 cm 60 425

10,000 Sunlight

Cloudy weather 20 1.5 8

100,000 Fine weather 5

15 minutes

<Reference> Condition A: Time required for full charge

Condition B: Time required for steady operation

Condition C: Time required for 1 day’s charge

kThe values in this column represent the charging times required until the second

hand moves constantly at 1-second intervals after the watch starts operating with

the second hand moving at 2-second intervals.

The above table provides only general guidelines.

English

• Even if the watch is not charged for the time speciﬁed in the column, the second

hand may temporarily move at 1-second intervals. But it will soon resume moving

at 2-second intervals, and therefore, charge the watch for more than the speciﬁed

period.

• When the watch is fully charged, it will continue to operate for about 4 months.

• When charging the watch, do not place it too close to a hot light source

such as a photoash light, spotlight or incandescent light as this can

greatly raise the watch temperature.

• When charging the watch by sunlight, do not leave it exposed to the sun

for a long time, on the dashboard of a car, etc.. as this can greatly raise

the watch temperature.

• Make sure the watch temperature does not exceed 50°C while charging,

to avoid damage to the parts inside.

CAUTION

English

HOW TO SET TIME

CROWN

Pull out to the first click postition

when the second hand is at the 12

o'clock position.

Turn to set the hour and minute

hands.

Push back simultaneously with a time

signal.

When settin g the mi nute han d,

advance it 4 to 5 minutes ahead of the

desired time and then turn it back to

the exact minute(s) .

English

ENERGY DEPLETION FOREWARNING FUNCTION

lWhen the energy stored in the rechargeable battery is reduced to

an extremely low level, the second hand starts moving at 2-second

intervals instead of the normal 1-second intervals.

lIn that case, recharge the watch as soon as possible by exposing it to

light. Otherwise, the watch may stop operating in about 1 day.

u To prevent the energy depletion

• When you wear the watch, try not to keep it covered by your

clothes.

• When the watch is not in use, leave it in a bright place as long

as possible.

* Make sure that the watch temperature does not exceed 50°C.

English

NOTES ON POWER SUPPLY

CAUTION

lNever insert a conventional silver oxide battery in your watch

as it may explode, generate an intense heat or catch re. The

watch is designed not to operate even if the battery is installed

in it.

lThis watch is provided with a rechargeable battery for exclusive

use with the watch. Unlike conventional battery-powered watches,

therefore, battery replacement is not necessary.

lThe solar cell is a clean energy source, having no adverse effect on the

natural environment.

English

TO PRESERVE THE QUALITY OF YOUR WATCH

WATER RESISTANCE

lNon-water resistant

lWater resistance (5 bar)*

If “WATER RESISTANT 5 BAR”

is inscribed on the case back,

your watch is designed and

manufactured to withstand up

to 5 bar and is suitable for swimming, yachting

and taking a shower.

If “WATER RESISTANT 10 BAR”,

“WATER RESISTANT 15 BAR” or

“WATER RESISTANT 20 BAR” is

inscribed on the case back, your

Water resistance (10 bar/15 bar/20

bar)*

watch is designed and manufactured to withstand

up to 10 bar/15 bar/20 bar and is suitable for taking

a bath, shallow diving, but not for scuba diving.

We recommend that you wear a PULSAR Diver’s

watch for scuba diving.

If “WATER RESISTANT” is not

inscribed on the case back, your

watch is not water resistant, and

care should be taken not to get

If “ WATER RESISTA NT ” is

inscribed on the ca se back,

your watc h i s designe d and

manufactured to withstand up

to 3 bar, such as ac cidental

contact with splashes of water or rain, but it

is not designed for swimming or diving.

lWater resistance (3 bar)

it wet as water may damage the movement. If

the watch becomes wet, we suggest that you

have it checked by an AUTHORIZED PULSAR

DEALER or SERVICE CENTER.
