Pulsar Pulsar ANALOGUE Manuale utente
ENGLISH
ANALOGUE WATCHES
■SCREW DOWN CROWN [for models with screw down crown]
1Turn Crown counterclockwise until you no
longer feel the threads turning.
2Crown can be pulled out.
Unlocking the crown
1Push Crown back in to normal position.
2Turn Crown clockwise while pressing it lightly
until tight.
Locking the crown
* When using the watch in water:
Before using the watch in water, be sure the crown is screwed in completely.
Do not operate the crown when the watch is wet or in water.
English
2
■HOW TO START THE MECHANICAL WATCH (Cal. Y621)
CROWN
1Pull out to the first click.
■TIME/CALENDAR SETTING FOR MODELS WITH DATE CALENDAR
To initially start your watch, swing it from side to side in a horizontal arc for
about 30 seconds.
* If the watch is worn daily, PULSAR’s automatic mechanism will wind the mainspring
automatically through normal wrist movement.
■TIME SETTING FOR MODELS WITHOUT CALENDAR
CROWN
1Pull out.
2Turn to set the time.
3Push back.
English
3
2Turn to show the previous day’s date.
3Pull out to the second click.
4Turn until the desired date appears.
* Turn Crown to advance Hour and Minute
hands.
5Turn to set the time.
6Push back in to normal position.
10
■TIME/CALENDAR SETTING FOR MODELS WITH DAY AND DATE CALENDAR
CROWN
1Pull out to the first click.
2Turn to show the previous day’s date.
3Turn in the opposite direction to show
the previous day of the week.
4Pull out to the second click.
5Turn until the desired date and day
appears.
WED
8
English
4
*Turn Crown to advance Hour and Minute hands.
6Turn to set the time.
7Push back in to normal position.
Notes on time setting:
1 When setting Minute hand of a quartz watch, advance it a few minutes ahead and
then turn it back to the exact time.
2 If your watch has three hands, pull out Crown all the way when Second hand points
at 12 o’clock. After adjusting the time, push Crown back in to normal position in
accordance with a time signal for “00” seconds.
Notes on calendar setting:
1The date will change gradually between 9:00 P.M. and 4:00 A.M. Therefore, do not
change the calendar during this time period. Otherwise, it may not change
properly. If it is necessary to set the calendar during that time period, first change
the time to any time outside it, set the calendar and then reset the correct time.
2 If your watch has a bilingual day calendar, choose the desired language. When the
day shifts automatically to the next day, the other language will appear temporarily.
3 When setting the hour hand, check that AM/PM is correctly set. The watch is so
designed that the calendar changes once in 24 hours.
Turn the hands past the 12 o’clock marker to determine whether the time is
set for the A.M. or P.M. period. If the calendar changes, the time is set for
the A.M. period. If it does not change, the time is set for the P.M. period.
English
5
WARNING
●Do not remove the battery from the watch.
●If it is necessary to take out the battery, keep it out of the reach of
children. If a child swallows it, consult a doctor immediately.
●Never short-circuit, tamper with or heat the battery, and never expose
it to fire. The battery may burst, become very hot or catch fire.
●As the battery is inserted at the factory to check the function and performance
of the watch, its actual life once in your possession may be less than the
specified period.
●When the battery expires, be sure to replace it as soon as possible to prevent
any malfunction.
●We recommend that you contact an AUTHORIZED PULSAR DEALER for
battery replacement.
English
6
CAUTION
●The battery is not rechargeable. Never attempt to recharge it, as this
may cause battery leakage or damage to the battery.
●Loss/gain (monthly rate) is less than 15 seconds (20 seconds for some
calibres) at normal temperature range (5°C ~ 35°C)(41°F ~ 95°F).
English
7
WATER RESISTANCE
●Non-water resistant
• If the watch becomes wet, have it checked by an AUTHORIZED
PULSAR DEALER or SERVICE CENTER.
●Water resistant 5/10/15/20 bar
• Before using in water, be sure the crown is pushed in completely.
• Do not operate the crown when the watch is wet or in water.
If used in sea water, rinse the watch in fresh water and dry it
completely.
• When taking a shower with the water resistant 5 bar watch, or
taking a bath with the water resistant 10, 15 or 20 bar watch, be
sure to observe the following:
* Do not operate the crown when the watch is wet with soapy water
or shampoo.
* If the watch is left in warm water, a slight time loss or gain may
be caused. This condition, however, will be corrected when the
watch returns to normal temperature.
10/15/20
bar WR
5 bar WR
English
8
* Pressure in bar is a test pressure and should not be considered as corresponding
to actual diving depth since swimming movement tends to increase the pressure
at a given depth. Care should also be taken on diving into water.
** We recommend that you wear a PULSAR Diver’s Watch for scuba diving.
TEMPERATURES
+60°C
-10°C
[for analogue quartz
watch only]
Your watch works with
stable accuracy within a
temperature range of 5°
The watch will be
adversely affected by
strong magnetism. Keep
it away from close contact
with magnetic objects. (In
MAGNETISM
NS
CARE OF CASE AND BRACELET
To prevent possible rusting
of the case and bracelet
caused by dust, moisture
and perspiration, wipe
them periodically with a
soft dry cloth.
C and 35°C (41°F and 95°F).
Temperatures over 60°C or 140°F
(50°C or 122°F for some calibres)
may cause battery leakage or shorten
the battery life.
Do not leave your watch in very low
temperatures below –10°C or +14°
F (-5°C or +23°F for some calibres)
for a long time since the cold may
cause a slight time loss or gain.
However, the above conditions will
be corrected when the watch returns
to normal temperature.
the case of a quartz watch, normal
accuracy will return if the watch is
moved away from the magnetic field)
English
9
SHOCKS & VIBRATION
Light activities will not
affect your watch, but be
careful not to drop your
watch or hit it against hard
surfaces, as this may
cause damage.
PERIODIC CHECK
It is recommended that the
watch be checked once
every 2 to 3 years. Have
your watch checked by an
AUTHORIZED PULSAR
2 - 3
Years
CHEMICALS
Be careful not to expose
the watch to solvents,
mercury, cosmetic spray,
detergents, adhesives or
paints. Otherwise, the
PRECAUTION REGARDING
CASE BACK PROTECTIVE FILM
If your watch has a
protective film and/or a
sticker on the case back,
be sure to peel them off
before using your watch.
case, bracelet, etc. may become
discolored, deteriorated or damaged.
DEALER or SERVICE CENTER to
ensure that the case, crown, gasket
and crystal seal remain intact.
