SJ100
OWNER’S MANUAL
Revision C
WHERE
PRECISION
DRIVES
PRODUCTION
SJ100
PVA
Revision C(2019)
2 of 26
This document is based on information available at the time of its publication. While
efforts have been made to ensure the contents of this manual are accurate, the
information contained herein does not purport to cover all specific details or variations in
hardware, or to provide for every possible contingency in connection with installation,
operation, or maintenance. Features may be described herein which are not present in
all hardware and software systems. Precision Valve and Automation, Inc. assumes no
obligation of notice to holders of this document with respect to changes subsequently
made.
Precision Valve and Automation, Inc. makes no representation or warranty, expressed,
implied, or statutory with respect to, and assumes no responsibility for the accuracy,
completeness, sufficiency, or usefulness of the information contained herein. No
warranties of merchantability or fitness for purpose shall apply.
This document, including the information contained herein, is the property of
Precision Valve and Automation, Inc. and is considered confidential and
proprietary information. It is delivered on the express condition that it not be
used, disclosed, or reproduced, in whole or in part, for any reason without prior
written consent of Precision Valve and Automation, Inc.
Copyright © 2019
Precision Valve and Automation, Inc.
All Rights Reserved.
SJ100
PVA
Revision C(2019)
3 of 26
Table of Contents
Introduction ............................................................................................. 5
Document History ............................................................................................... 5
Safety .................................................................................................................. 6
Theory of Operation............................................................................................7
Personal Protective Equipment ..........................................................................7
Waste Disposal.................................................................................................... 7
Setup........................................................................................................ 8
Overview .............................................................................................................8
Operation................................................................................................. 9
Install Jet nozzle .................................................................................................. 9
Set the Valve Stroke..........................................................................................10
Prime the Valve.................................................................................................11
Set Fluid Pressure..............................................................................................11
Set Jet Pressure.................................................................................................11
Shutdown..........................................................................................................11
Cleaning Procedure...........................................................................................12
Maintenance .......................................................................................... 13
Flush the System ...............................................................................................13
How to Use the Valve with Portal ........................................................... 14
Setup Mode....................................................................................................... 15
Valve Positions ..................................................................................................17
Select a Recipe ..................................................................................................18
PathMaster .......................................................................................................19
Exploded View........................................................................................ 20
Item Numbers and Descriptions ............................................................... 20
Spare Parts ............................................................................................. 21
Technical Specifications.......................................................................... 22
Troubleshooting ..................................................................................... 23
Notes ..................................................................................................... 24
SJ100
PVA
Revision C(2019)
5 of 26
Introduction
Before you operate this system, read the operation and setup manual. This will help you
to become familiar with the product and ensure successful operation.
If any questions or problems arise, contact PVA’s Technical Support department.
PVA Contact Information
Main Office PVA
One Mustang Drive
Cohoes, NY 12047
Tel +1-518-371-2684
Fax +1-518-371-2688
Website http://www.pva.net
Email mailto: info@pva.net
Technical Support
Tel +1-844-734-0209
Document History
Revision
Revision Date
Reason for Changes
Revision A
November 2017
Initial Release
Revision B
August 2018
Dwell Time Corrected
Revision C
September 2019
Operating Air Pressure Updated
NOTE: All photographs and CAD model representations in this document are a
“general representation” of the system and its components. The actual
appearance of the system and its components can differ based upon customer
specific configuration.
SJ100
PVA
Revision C(2019)
6 of 26
Safety
Certain warning symbols are affixed to the machine and correspond to notations in this
manual. Before operating the system, identify these warning labels and read the
notices described below. Not all labels may be used on any specific system.
Always wear approved safety glasses when you operate or work
near the workcell.
Before you operate the system, read and understand the manuals
provided with the unit.
Never put hands or tools in areas with this symbol when the
machine is in operation. A dangerous condition may exist.
Read and understand the manuals provided with the unit before
any repairs or maintenance is done. Only a qualified individual
should do service.
Use caution when there are pressurized vessels. Find and repair any
leaks immediately. Always wear appropriate safety equipment
when you work with pressurized vessels or vessels that contain
chemicals.
Shear hazard from moving parts. Avoid contact
Pinch hazard from moving parts. Avoid contact.
Do not remove protective guarding.
SJ100
PVA
Revision C(2019)
7 of 26
Theory of Operation
The SJ100 valve is a non-contact dispense valve that applies small shots of fluid as
individual dots or in rapid succession. Only three components come in contact with
fluid: the fluid body, needle, and nozzle. With this design you can dispense at speeds up
to 140Hz. The SJ100 is designed to dispense coatings and other low viscosity materials
with very fine control.
Personal Protective Equipment
Operators must use eye protection because material contents are under pressure.
Always wear gloves when handling materials and solvents. Refer to MSDS sheets on the
material being dispensed for other precautions.
Waste Disposal
Dispose of all used parts and materials in accordance with local laws and regulations.
SJ100
PVA
Revision C(2019)
8 of 26
Setup
Before you operate the valve, know the valve components. Do the steps instructed
below for safe and correct operation.
Overview
Figure 1: Pump Components
SJ100
PVA
Revision C(2019)
9 of 26
Operation
NOTE: Refer to Section 6 for part reference numbers.
NOTE: Use only compatible solvents and materials or the seals and O-rings will
be damaged.
Install Jet nozzle
1. Use Portal to set the jet valve to “Open” or set the air pressure to 0 psi.
2. Turn the nozzle retaining cap counterclockwise to remove it.
Figure 2: Remove the Retaining Cap
3. Install the jetting nozzle.
NOTE: Make sure the nozzle O-ring is installed on nozzle.
Figure 3: Jetting Nozzle with O-ring
4. Push the nozzle retaining cap up over the jetting nozzle and turn is clockwise to
install the nozzle.
SJ100
PVA
Revision C(2019)
10 of 26
Figure 4: Install the Nozzle
5. Use Portal to set the jet valve to “Close” or increase the jet pressure.
Set the Valve Stroke
Do the procedure below to adjust the micrometer and set the valve stroke as necessary.
1. Turn the micrometer counterclockwise to increase the valve stroke.
2. Turn the micrometer clockwise to decrease the valve stroke.
NOTE: A larger valve stroke will result in larger dot sizes. Nominal valve stroke
is recommended at 0.01” but will be material and application dependent.
Figure 5: Micrometer
