Pyle view PLVWH1 Manuale utente
PLVWH1
WIRELESS INFRARED SURROUND HEADPHONE
1
The PLVWH1 is a true wireless headphone system which uses latest
high frequency modulation infrared technology. You can enjoy music
by simply connecting the supplied infrared transmitter to any of your
audio/video equipment through either a line output jack or a headphone
jack. This system is easy to set up within your car. It provides you with
ultimate personal listening freedom.
Features
An optical transmission system with high frequency modulation
guarantees excellent nd surround sound quality and wide effective
transmission range.
The well designed transmitter and headphone with built-in receiver are
omnidirectional in sending and receiving audio signals within a 7 meter
radius, which are generally not susceptible to be blocked by objects
between them.
True surround sound, elegant design and rich finish of the system add
into the beauty of your expesive automobile entertainment systems.
The signal input level is automatically adjusted by the built-in Automatic
Input Level control Circuit (ALC).
Since this system uses infrared ray, if the headphones/receivers are
placed too far from the transmitter,a hissing noise may increase. This is
a characteristic of infrared systems and does not mean that the system
is defective Do not use this system in the open air under direct sunlight as
the infrared system will not work properly.
Overview
Precautions
* Operate the transmitter on 12V 100mA. Operate the headphone
system on3V DC (size AAAbatteries x 2).
* Turn off the power of the transmitter and the system is not in use.
* Do not open the cabinet. Refer servicing to qualified personnel
only.
* Do not leave the system in a location near heat sources such as
radiators or airducts, or in a place subject to direct sunlight,
excessive dust, moisture, rain, mechanical vibrantion, or shock.
* Do not use alcohol, benzine or thinner to clean the cabinet.
Headphone
1. Infrared sensors
2. Power Switch
3. Stereo / mono
4. Volume Controls
5. Battery Compartment Door
6. Ear pad
7. Adjustableheadband
IR Stereo Headphone
1. Open the battery compartment door on the right of the
headphone.
2. Insert two size AAAbatteries with correct polarity.
3. Close the battery compartment.
2
3
5. Receiving Positions
The headphon/Receiver receives audio signals omni-directionally
and in line-of-sight within certain effective ranges.
For best reception, use th headphone. within 5 meters from the emitter
of the transmitter.
1. Turn on the audio/video equipment
connected to thetransmitter. 2. Turn on the power switch for
headphone.
3. Adjust volume control on the
left side. Do not cover the sensors
while adjusting volumes.
4. Turn on the stereo switch for
stereo effect. For Mono
audio/video equipment, turn
the switch to the mono position.
Specifications:
* POWER REQUIREMENTS: 3VDC (1.5V AA x 2)
* TYPE: OPEN AIR DYNAMIC
* DRIVE UNIT: 40 mm MYLAR CONE
* IMPEDANCE: 32 OHM +-6.4 OHM
* FREQUENCYRESPONSE: 20 Hz ~ 23 KHz
* S.P.L.: 98 dB / NOM. DEV
* DISTORTION: 1 PERCENT THD AT NOM. DEV.
* BATTERY LIFE (AT 10mv OUTPUT): ABOUT 48 HOURS
WEIGHT: ABOUT 170 gr. (EXCLUDING BATTERIES)
How to use
