Pyle PLCM9200 Manuale utente
Owner's Manual
PLCM9200
Die Cast
License Plate Mount
Rearview Camera
PLCM9200
9.2" TFT/LCD Mirror Monitor with License Plate
mount Rearview Backup Color Camera
Front Panel
Remote control
Power ON/OFF
Analog variable increase
Menu button
V1/V2 conversion
Analog variable decrease
Switch for mode
PLCM9200
1
2
3
5
6
4
1.
2. Analog variable increase
3. Menu
4. Analog variable decrease
5. Exchange between V1/V2
6.
Press MENU to display the adjustments in this order.
Brightness-->Color-->Contrast-->Volume-->...
Power on/off
Remote window
BACKUP CAMERA SYSTEMS
FEATURES:
Monitor:
License Plate Mount Back up Rearview Color Camera
Black Zinc Aluminum Die Cast Chrome
Distance Scale Line
True Color Reproduction
Low Lux Performance of 0.2 LUX Night Vision
Total Pixels: 656 x 492
Resolution: 420 TV Lines
Viewing Angle: 170 Degree
Auto White Balance
Waterproof (Ip67), Fog Resistant
Low Lighting Capable
Video Output: 1.0V PP-75 Ohm
Power Supply: DC 12V 200mA
17 Foot male to male RCA Video Cable
Dimension: 10"W x 1.3"H x 1.26"D
Camera:
Connection:
6M
Video (out)
Monitor
Backup light power
Red: +12V (in)
Black: GND (in)
Camera
PLCM9200
9.2" TFT (16:9) Wide Screen
Universal Clip on Existing Mirrors
Wireless Remote Control
Resolution: 800 x RGB X 480
Power Consumption: 7W
PAL/NTSC Auto Switch
Dual Video inputs
Anti Glare Mirror
Camera
(Green) reverse car
(Red) battery +12V
(Black) grounding
(Yellow) video 1 input
(Yellow) video 2 input
Player
PLCM9200
