Pyle PLWV104 2R Manuale utente

Video1 input (yellow)

FUSE 2A

12V

BATTERY

CAR AUDIO(DVD OR VCD)

Video2 input( yellow)

Audio1 input (white)

Audio2 input (red)

Filter

Red

Black

WIRING DIAGRAM

PLVW1042R

WARNING:

HAZARD DO NOT OPERATE THIS

UNIT UNLESS VEHICLE ISPARKED

IN SAFE ANDLEGAL AREA

Instruction Manual

10.4 TFTLCD COLOR MONITOR

Pannel

POWER

SEL +

-

Remark:MODE,UP/DOWN,VOLUME,MUTE are not available

for this model.

Contents and specifications can be subjected to change

without prior notice.

Accessories

Remote control

Cautions

Never connect the car adaptor to cigarette lighters for

such as trucks or buses which use 24V DC power.

Do not expose the monitor to high humidity,dust,steam,

oily smoke,direct sunlight etc.

For your safety,turn power OFF when not in use and

unplug the adaptor.

Never attempt your own maintenance.Consult your TV

dealer or the company.

Avoid dropping and strong impact.

For your safety,the driver should not watch the Monitor

or operate the controls while driving.

WARNING:

DO NOT WATCH MONITOR WHILE VEHICLE IN MOTION.

IT CAN BE HAZARDOUS.

Screen Size: 10inch 4:3TFT

System: PAL/NTSC

Power source/Consumption: DC12V+/-20%, 1250mA

Video Input: Composition Video signal

Storage Temperature: -10 ~ +85

Display Method : Color LCD

Resolution(HxV): 1024(H) x 768(V)

Back light: Cold Cathode Filament Tube

Monitor dimension: 286x280x35mm

Specifications

MD

L/R

U/D

AV

TFT-LCD

MONITOR REMOTE

Power on /off

Color +

Color -

Contrast +

Volume+

Volume-

Brightness+

Mute

Mode

Up/down

Left/right

Video1 /video2

1.Sensor for remote 2. Adjustment (-)

3.SEL 4.Adjustment (+)

5.POWER

1 2 3 4 5

1xRemote control

1xinstruction manual 1xMetal Bracket

Brightness-

Contrast -
