PMP561LTB
MegaphoneSpeakerwithLEDLights
Built-in Rechargeable Battery, LED Lights,
SirenAlarm Mode &Adjustable Volume Control
www.PyleUSA.com
PMP561LTB
Megaphone Speaker with LED Lights
Built-in Rechargeable Battery, LED Lights, Siren Alarm Mode
& Adjustable Volume Control
This user manual contains important information for safe operation and
optimal megaphone performance. Please carefully read and follow safety
notes and instructions. Save this manual for future reference. Make sure that it
is available to all persons using this device.
SAFETY
This megaphone is intended to be used only as described in this user manual.
Any other use or use under other operating conditions is considered to be
improper and may result in personal injury or device damage. Please use the
megaphone as described and under supervision if used by children or minors.
• Ensure that plastic bags, packaging, etc.
• Never let children unattended use electrical devices.
Shoulder Strap
Clip-on Brackets
Press-to-talk Button
PA Talk Trigger Switch
PA Mode Selector
LED Light
AUX / MP3
2
*Important Note*: Before operating the
megaphone, ensure you hit the correct
switch to the proper position when
CHARGING/OPERATING Mode.
www.PyleUSA.com
www.PyleUSA.com
OPERATING INSTRUCTIONS
• Insert (8) x 'C' Batteries
• Use the sliding switch to choose PA Modes
Speak:
While in 'Speak Mode', speak through the microphone mouthpiece while
holding the 'Press-to-Talk' button on the detachable handheld differential
mic. The user also has the ability to use the 'PA Talk Trigger Switch' on the
megaphone's handheld pistol grip.
Siren:
Slide the switch over to 'Siren' and an automatic, continuous alarm siren plays.
Switch to another mode to discontinue the alarm siren play.
• Adjust volume control located on the right hand side of the removable
differential microphone.
• Press the trigger or use the External Microphone, speak directly to loud
your voice
• Turn on the LED light switch by sliding the switch with light icon
Battery Charging
1. The megaphone features a removable rechargeable battery, that plugs-in
directly into the USB wall power outlet for charging. Once connected to the
wall power outlet, the battery will begin charging automatically, after you
set the battery to "Charge Mode" (average time for full-charge: 8.5 hours).
A Red light will be lit while charging and turns Green when fully charged.
3
www.PyleUSA.comwww.PyleUSA.com
www.PyleUSA.com
2. *Important Note*: Before charging the battery, ensure you hit the switch
to "DC CHARGING" -- as located on the battery, to enable Charge Mode.
3. Once fully charged, insert the battery into the megaphone by opening the
end cap in the rear of the megaphone. Be sure to slide the battery into the
compartment properly, ensuring the power connection cable is exposed.
4. Once the battery is inserted, connect the battery power cable connector
into the megaphone power input -- ensure you set the battery to "Power
Output" Mode.
5. *Important Note*: Before operating the megaphone, ensure you hit the
switch to "DC OUTPUT" -- as located on the battery, to enable Power
Output Mode.
4
www.PyleUSA.com
www.PyleUSA.com
PMP561LTB
Megaphone Speaker with LED Lights
Built-in Rechargeable Battery, LED Lights, Siren Alarm Mode
& Adjustable Volume Control
Features:
• (2) Megaphone Modes: Talk + Siren Alarm
• Convenient Coiled-Cord Handheld Microphone
• Built-in Switch Activated LED Lights
• Adjustable Volume Control
• Rechargeable Battery for Wireless PA Speaker Portability
• Battery Charges via Included USB Wall Power Adapter
*or Optional Battery Powered: Requires (8) x ‘C’ Batteries, Not Included
• Simple Button Control Operation
• High-Powered Audio Reproduction
• Wide Bell Diameter for Extended Projection
• Ergonomic Pistol Grip & Lightweight Chassis
• Power Supply Jack: DC 12V Adapter Connector
• Used by U.S. Service Personnel & Armed Forces
• Perfect for Outdoor Events & Crowd Control
What's in the Box:
• Megaphone Speaker
• Rechargeable Battery
• USB Wall Adapter
Technical Specs:
• MAX Power Output: 50 Watt
• Audio Projection Range: Over 1,200+ Yards
• Sound Processor: Dynamic Piezo Driver
• LED Power Light Control: ON/OFF
• Sound Level: 105db (40cm)
• Rechargeable Battery: 11.1V Lithium-iOn, 1500mAh (16.6Wh, 166g)
• Megaphone Dimensions (Diameter x Length): 9.0'' x 13.8'' -inches
5
