Modification Instruction 63 / 2020
MI_2063: Removal and Installation Pressure Control Valve
iVario Pro 2-S/L/XL P 30 min. Standard 15.11.2020
3 / 140
MI_2063_Removal_and_Installation_Pressure_Control_Valve_S
1 MI_2063: Removal and Installation Pressure Control Valve
General information
This manual describes the removal and installation of the pressure control valve
based on unit size XL. The work steps can also be used for other unit sizes with
pressure.
The illustrations in this manual are examples only and may differ from the unit.
Safety instructions
CAUTION
Sharp edges on the housing
Risk of cuts on the housing when working in the unit.
Wear protective gloves.
NOTICE
The pan lid must be closed for both removal and installation.
nClose the pan lid before you disconnect the power supply.
Required component
Component: Article number:
Pressure control valve 2-S P 87.01.837S
Pressure control valve L / XL P 87.01.836S
Removing the maintenance cover
aThe unit is disconnected from the power.
